A recent progress of NanoBridge (NB) technology is reviewed for embedded nonvolatile field-programmable gate array (FPGA) and memory (NVM) applications. The NB is a kind type of electrochemical resistive-change device using Cu ion migration from Cu interconnects into electrolyte. The NBs are integrated in a standard Cu-BEOL with keeping a PDK and an appropriate ON-conductance is tuned by programming currents depending on the applications. For a routing switch in the FPGA, two NBs are connected in series and each conductance is tuned to ~1mS to transfer signals and realize 78% area reduction compared with a conventional SRAM-FPGA. For the NVM application, that is tuned to ~0.2mS, which has 150oC over 10years retention with 30% change of the conductance, which is potentially applicable for automobile applications.

IRPS 2022 Main Conference

NanoBridge Technology: Nonvolatile FPGA and Memory Applications

nanobridge

fpga
