The BaTiO3 (BTO)/CoFe multiferroic material interface is an example of an interface which displays voltage-controlled magnetic anisotropy (VCMA), a valuable property in the operation of multiferroic tunnel junctions in an STT-MRAM device. Through first principles calculations, it is possible to predict trends in film magnetic anisotropy energy (MAE) and enumerate the individual physical mechanisms contributing to ferroelectric control of MAE in the CoFe film. For CoFe of up to 2 atomic layers on BTO, MAE can be modulated by ferroelectric switching through Fe-O orbital interations in BaO-terminated interfaces, and Ti-Fe orbital interactions in TiO2-terminated interfaces. A difference in interface termination produces a difference of MAE in CoFe films of up to 9 atomic layers. The inclusion of a 5d transition metal capping layer (Hf, Ta, W, Re, Os, Ir, Pt, or Au) on top of the CoFe layer exerts a significant effect on both MAE and the ferroelectric switching effect, in particular inducing a discernible ferroelectric switching control even in thicker CoFe films. This points to the additional, if counterintuitive, contribution of CoFe 3d top interface (or surface) states and their interactions with partially filled 5d orbitals of the capping layer atoms.References: A. P. Chen and Y. P. Feng, ACS Appl. Mater. Interfaces., Vol. 12, p25383-25389 (2020) A. P. Chen, W. Lin, J.-S. Chen, and Y. P. Feng, in preparation.

MMM 2020

Free Layer Magnetic Anisotropy Control in the Multiferroic Tunnel Junction: a Computational Study on Materials Interfaces
