Since the discovery, the experimental observation of skyrmions in thin films has raised its demand among researchers.[1, 3, 4] So far, their applicability has been investigated for logic devices, nanooscillators, memory devices, stochastic computation, neuromorphic computation[5, 6] and many more. This work is focused on study of dynamics of skyrmionic structures to produce consequences for neuromorphic computation. When a complex chiral structure is allowed to pass through narrow channels, unzipping of the structure generates number of codes at the terminal depending upon the spin-polarized current. The dynamics is studied in single layer as well as on synthetic antiferromagnet and is observed to be almost similar in both isotropic and anisotropic DMI systems. This functional device can be realized analogous to biological synapse. Subsequently, another nanodevice is proposed to demonstrate how the antiskyrmionic codes in a ferromagnetic layout can be used to store memory of stimuli by recycling of codes and send reaction pulses to the reaction spot. Apart from that, it requires external circuitry along with MTJ sensors to monitor the device operation. However, we focus on micromagnetic simulations using OOMMF.[2] The potentiation and depression processes that take place in a biological synapse could be realized in the reaction centre. The conversion of long-term memory into short-term memory under stress can be realized like that happens in biological system. This device encounters no memory loss in its complete operation since all the codes generated are conserved in the system by PMA barriers at the edges. Hence, the proposed model may contribute in development of highly integrated and energy efficient neuromorphic computing systems for adaptive learning.References: [1] A. Fert, V. Cros, and J. Sampaio. Skyrmions on the track. Nat. Nanotechnol. 8, 152–156 (2013). [2] M. J. Donahue, and D. G. Porter, OOMMF User’s Guide, Version 1.0, Interagency Report. NO.NISTIR 6376, 158 (1999). [3] A. N. Bogdanov, and U. K. Rößler, Chiral symmetry breaking in magnetic thin films and multilayers. Phys. Rev. Lett. 87, 037203 (2001). [4] T. H. R. Skyrme et al Proc. Royal Soc. A 260, 127–138 (1961). [5] Huang et al 2017. Web. doi:10.1103/PhysRevB.96.144412. [6] S. Li et al 2017 Nanotechnology 28 31LT01.
