Strontium Ferrite magnetic nano-powder is being studied to be applied in magnetic 3D printer filament. Here we report on a study of the time dependence of its magnetic properties to better understand the permanent magnetic moment per unit volume of a nanocomposite containing the material [1,2,3]. Samples were made by loading up to 30 mg of OP-71 from Dowa Electronics Materials Company in a cylindrical custom design powder sample holder. Isotropic and anisotropic samples were made by loading the material in 0 field or in a field of 22,000 Oe. After loading the powder, the samples were compacted by compressing the powder along the cylindrical access. The typical samples were cylinders with a diameter of 2.5 mm and a length of 3 mm. The magnetic hysteresis curves of the samples were measured with a biaxial MicroSense Vibrating Sample Magnetometer (VSM) as a function of the field angle. For the isotropic samples, the average coercivity and the Mr/Ms were approximately constant as a function of the field angle for the Mx signal and were respectively 3402.35 Oe and 0.49. The shape of the Mx-hysteresis curves was independent of the field angle. For the anisotropic samples, the coercivities were around 3455 Oe (Mx curves). The Mr/Ms of the anisotropic samples depends on the field angle and varies from 0.41 along the hard axis to 0.64 along the easy axis. The coercivity of the My curves is around 4373 Oe. The coercivity of the anisotropic data seems to be larger than that of the isotropic sample due to the orientation of the crystallites. The time dependence of the Mx /Ms and My/Ms signals after a field step from saturation were measured for both the isotropic and anisotropic samples. The time derivative of the magnetization normalized on the Ms (S) depend on the field magnitude and shows a maximum. For the Mx signal this maximum coincides with the sample’s coercivity. The S(H) for the anisotropic curve for the My signal is shifted to larger fields as shown in the graph below. This work was supported in part by NSF through an DMR-MRI Grant under Award 1726970.References: [1] reference of strontium ferrite, maybe original philips patent. [2] R. Street, J. C. Wooley, Proc. Phys. Soc. London, Sect. A 62 (1949) 562. [3] L. Neel , Ann. Geophys. 5 (1949) 99.

MMM 2020

Time Dependence of Magnetic Moment of Strontium-Ferrite Powder Measured by Biaxial VSM

The 15th Joint MMM-INTERMAG Conference (2022 Joint) is sponsored jointly by AIP Publishing and the IEEE Magnetics Society. Members of the international scientific and engineering communities interested in recent developments in fundamental and applied magnetism are invited to attend and contribute to the technical sessions. The technical program will include invited and contributed papers in oral and poster sessions, invited symposia, a plenary session, and an evening session, with about 1500 presentations overall. This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

The 2022 Joint Conference will offer both in-person and prerecorded on-demand content.

For tickets to the event, please register at the following link: https://magnetism.org/register

Please register for the Joint MMM-Intermag conference to join the event.

2022 Joint MMM-INTERMAG

This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

poster

The 65th Annual Conference on Magnetism and Magnetic Materials (MMM 2020) was held in a virtual form. The COVID-19 pandemic, with its associated uncertainty about international travel and the ability to gather in large groups, meant that the Steering Committee decided to cancel the face-to-face meeting that had been planned in Palm Beach, Florida November 2-6, 2020.

We were reluctant to give up the benefits of meeting face-to-face, and know that shifting to a virtual conference is a significant change for this community. Nevertheless, we are first and foremost concerned about the health and safety of all our Conference participants and their loved ones on returning home after travelling.

The MMM 2020 Steering Committee was working exceptionally hard, along with our sponsors, the IEEE Magnetics Society and AIP Publishing, to make this event serve the needs of our participants, who live in time zones all around the globe, in the best possible way.

You need a ticket to explore this event.

If you have already registered for MMM 2020, and you have already created an account, then you
just need to login (above).

If you have already registered for MMM 2020, but you have not yet created an account, then you
need to click on &quot;create an account&quot; (above) and then login.

Forgot your password? Go to
https://www.underline.io/log-in

If you have not yet registered for MMM 2020 but would like to do so, go to
https://magnetism.org/register

Still need help? Contact our team!


Increasingly impressive demonstrations of voltage-controlled magnetism have been achieved recently, highlighting the potential for low-power data processing and storage devices. Magnetoionic approaches appear particularly promising, electrolyte- and ionic-conductor-based devices being shown capable of on/off voltage control of ferromagnetism and voltage tuning of magnetic anisotropy [1-3]. A clear limitation, however, is that such demonstrations involve either electrically tuning a known ferromagnet, or electrically inducing ferromagnetism from another magnetic state, e.g., antiferromagnetic. In this work, we report proof-of-principle that ferromagnetism can be voltage-induced even from a diamagnetic, i.e., zero-spin state, suggesting that useful magnetic phases could be electrically-induced in “non-magnetic” materials [4]. We use ionic-liquid-gated diamagnetic semiconducting FeS2 as a model system, showing that as little as +1 V gate bias induces a highly reversible insulator-metal transition, driven by electrostatic inversion of the surface from a p-type semiconductor to an n-type metal. Anomalous Hall effect measurements then reveal the onset of robust electrically-tunable surface ferromagnetism at Curie temperatures up to 25 K, with intriguing high temperature spin correlations. Density-functional-theory-based modelling explains the induced magnetism in terms of Stoner-type ferromagnetism induced solely via filling of a narrow Fe eg band. Work supported primarily by the NSF MRSEC.References: [1] Navarro-Senent, Quintana, Menendez, Pellicer, Sort, APL Mater. 7, 030701 (2019) [2] Molinari, Hahn, Kruk, Adv. Mater. 31, 1806662 (2019) [3] Leighton, Nat. Mater. 18, 13, (2019) [4] Walter, Voigt, Day-Roberts, Heltemes, Fernandes, Birol and Leighton, in press (2020)

Voltage-induced Ferromagnetism in Diamagnetic FeS2

Manipulating magnetization of ferromagnetic material with small amount of energy is of contemporary interest in field of Spintronics.There are various ways in which manipulation of magnetization can be done such as,1) Using spin polarized current [1] 2) Electric field controlled [2] 3) SAW based technique [3],4) Heat current controlled [4],among all currently available techniques Electric Field controlled is ultra-low power [5].All the effects in nature also have a reciprocal effect based on the Onsager reciprocity e.g. the inverse of spin transfer torque effect viz. spin pumping can be used for converting magnetization oscillations into spin current.Here we have experimentally demonstrated the Inverse of VCMA effect by which magnetization oscillations produce charge voltage. To demonstrate the inverse-VCMA effect [6],we fabricated a two port device as shown schematically in Fig.1 We deposited stack on Si/SiO2 substrate: Ta(5)/Ru(5)/Ta(5)/Ru(5)/Ta(9)/COFEB(1)/CoFe(0.2)/Ir(0.1)/MgO(2.4)/Ta(5)/Ru(7). We then fabricated tunnel junctions of dimension 3umx80um with contacts. A CPW was fabricated on the top,which was electrically insulated from the bottom pillar. The patterning of the device was done by e-beam lithography and Ar-ion milling. We measured the S-parameters of the device using a (VNA). The magnetic field was swept along different directions by varying θ and φ. The measurement of S21 signal corresponds to the direct VCMA effect.Applying signal to port 1 oscillates magnetization of FM by the VCMA effect and signal is induced in the port 2 by induction.The measurement of S12 corresponds to the inverse of VCMA effect as shown in Fig.2. On applying oscillating voltage to port 2,creates oscillating field on the FM.The oscillation of the magnetization of the FM induces voltage in the port 1 by the inverse-VCMA effect.Both the S12 & S21 signal are largest at the FMR frequency.We observed that the Onsager reciprocity relation S12(B)=S21(-B) is satisfied.The angular dependence of the S-parameters confirmed that the signals arise from inverse VCMA effect. We would like to thank IIT Bombay NanoFabrication facility for supportReferences: [1] J.C.Slonczewski JMMM volume 159, Issues 1–2 (1996). [2] T. Maruyama, et.al., Nat. Nanotechnology. 2008, 406(2009). [3] Swapnil Bhuktare et.al., Appl. Phys.Lett. 114, 052402 (2019). [4] Arnab Bose et.al, PhysRevB.98.184412 (2018). [5] T. Nozaki et.al., Nat. Physics. 2298 (2012). [6] Ambika Shanker Shukla et.al. Science Advances (accepted) 2020.

Inverse of Voltage Controlled Magnetic Anisotropy (VCMA) effect

Recently, we experimentally demonstrated that the nucleation and annihilation of µm-sized skyrmions in Pt/Co/AlOx trilayers can be controlled by tuning the perpendicular magnetic anisotropy with electric field gating [1]. Here, we show our present efforts to extend this concept to smaller skyrmions, down to 50 nm lateral size. Two trilayer systems, in which sub-100 nm skyrmions were observed at room temperature, were studied: Pt/Co/MgO [2] and Pt/Co/TbOx. The stacks were patterned by electron beam lithography and ion beam etching into stripes (1 – 50 µm width) then covered with a 10 nm thick ZrO2 dielectric layer and a 6 nm thick Pt top electrode to form capacitor-like structures, Fig (a). Using Magnetic Force Microscopy, Fig (b-c), we show that in both stacks, starting from a stable skyrmion network, a positive electric field (EF) leads to the increase of the PMA and to the annihilation of the skyrmion phase. We attribute this to the EF-induced migration of oxygen towards the top Co interface. This result is confirmed by the variation of the hysteresis loops taken with polar Magneto-Optical Kerr Effect, Fig (d). This new state persists after removing the EF i.e. EF-gating leads to a non-volatile effect. In the Pt/Co/MgO trilayer, the application of a negative EF shows no effect on the magnetic anisotropy, preventing us to renucleate the skyrmions. This irreversible process is probably due to the stabilization of the stochiometric MgO phase induced by oxygen ion migration towards the Co/MgO interface when a positive gating is applied. On the contrary, for Pt/Co/TbOx trilayers, the application of a negative EF triggered the oxygen ion migration away from the top Co interface. This allows us to tune reversibly the magnetic anisotropy, and therefore to reproducibly nucleate and annihilate 50 nm size skyrmions. This is an easily integrable and energetically efficient solution that might ease the use of magnetic skyrmions as information carriers in future spintronic devices.References: [1] Schott et al., Nano Lett 17, 3006 (2017) [2] Boulle et al., Nat Nano 11, 449 (2016)

Tuning magnetic anisotropy and skyrmion stability with electric field

Magneto-ionics has emerged as a promising approach to manipulate magnetic properties in magnetic heterostructures, energy-efficiently. While this has led to exciting magneto-ionically controlled functionalities in primarily oxygen-based systems, such as perpendicular magnetic anisotropy, magnetization, exchange interaction, and superconductivity, there are challenges in oxygen-based magneto-ionics, in terms of switching speed and reversibility [1-3]. There have been keen interests in exploring other ionic systems which may overcome these issues [4]. Here we explore the use of α-Co(OH)2 for hydroxide-based magneto-ionics, which undergoes a reversible paramagnet to ferromagnet transition under electrolyte gating. The α-Co(OH)2 films are grown by electrochemical methods. Grazing incidence x-ray diffraction (XRD) confirmed the formation of α-Co(OH)2 without traces of any other hydroxide or oxide phase. After voltage application in an electrolyte-gating configuration, a ferromagnetic signal can be induced in the paramagnetic as-grown sample under negative voltage due to the reduction of α-Co(OH)2 into metallic Co (Fig. 1). Magneto-electric experiments revealed that the turn-on voltage, i.e. minimum voltage needed to generate the ferromagnetic response, is as low as -2V, among the lowest turns-on voltages reported for propylene carbonate gated experiments [5]. Its paramagnetic character can be fully recovered by reversing the applied voltage polarity. This reversible transition is due to the ionic diffusion of hydroxyl groups into the employed electrolyte. By tuning the voltage magnitude and sample area we demonstrate that the speed of the induced ionic effect can be drastically boosted, up to a factor 60 at -8V (Fig. 2). This work opens new avenues in exploring the benefits of layered materials and hydroxyl groups towards fast magneto-ionic processes. This work has been supported in part by the SRC/NIST SMART Center, the NSF (ECCS-1933527), NSF-REU (DMR-1659532) and NSF-MRI (DMR-1828420).References: [1] U. Bauer et al., Nat. Mater., 14, 174 (2015). [2] D. A. Gilbert et al., Nat Commun 7, 12264, (2016). [3] P. D. Murray et al., ACS Appl. Mater. Interfaces 12, 4741 (2020). [4] A. J. Tan et al., Nat. Mater. 18, 35 (2019). [5] C. Navarro-Senent et al., APL Mater. 7, 030701 (2019).

Hydroxide-based Magneto-Ionics: paramagnetic-to-ferromagnetic transition in electrolyte-gated α-Co(OH)2

Unlike the common expectation that superconducting spintronics and long-range triplet (LRT) proximity effects require complex ferromagnetic multilayers, relying on noncollinear/spiral magnetization or half-metals, we propose a new platform compatible with commercial spintronics. Recently, we have experimentally demonstrated that interfacial spin-orbit coupling (SOC) and symmetry-filtering in all-epitaxial V/MgO/Fe junctions, cooled below the critical temperature of vanadium, provide a thousand-fold increase in tunneling anisotropic magnetoresistance, supporting the LRT formation [1]. Here we report the converse effect: transformation of the magnetocrystalline anisotropy of a Fe(001) layer driven by the superconductivity of an underlying V layer through a spin-orbit coupled MgO interface [2]. We attribute this to an additional contribution to the free energy of the ferromagnet arising from the controlled generation of triplet Cooper pairs, which depends on the relative angle between the exchange field of the ferromagnet and the spin-orbit field. This observation offers the ability to fundamentally tune magnetic anisotropies using superconductivity - a key step in designing future cryogenic magnetic memories.References: [1] I. Martínez et al; Phys. Rev. Appl. 13, 014030 (2020). [2] C. González-Ruano et al; accepted for publication as Rapid Communication in Phys. Rev. B, Cond Mat. ArXiv https://arxiv.org/abs/2006.02118

Superconductivity-induced change in magnetic anisotropy in epitaxial ferromagnet-superconductor hybrids with spin-orbit interaction

Atomistic simulations play a huge part in our understanding of static and dynamic magnetic states in current state-of-the-art research. Motivated by the recent interest in magnetic Heusler alloys, a model based on the LLG equation was developed for investigating magnetisation dynamics in near-compensated ferrimagnets. These materials, including Mn2RuxGa (MRG), are predicted and often experimentally verified to possess key properties, including THz resonance frequencies and high spin-polarisation at the Fermi level [1, 2]. Another hot topic of study are magnetic skyrmions, topological defects in the spin texture of non-centrosymmetric crystals with chiral interactions. There is much interest in the dynamics of skyrmions, with fast skyrmionic magnetic storage one potential application [3, 4]. In this work, the stability of skyrmion states in a 1D ferrimagnet was investigated as a function of material parameters such as anisotropy and Dzyaloshinskii-Moriya interaction (DMI), see Fig. 1. Additionally, skyrmion propagation speed and breathing mode frequency [5] are investigated under the influence of an external magnetic field and/or spin-polarised current. The model has also been applied as a computationally efficient method to obtain magnon frequency dispersions. By applying a perturbing field pulse and taking the Fourier Transform of the resulting dynamics, the entire magnon dispersion can be obtained. A simple example for a 1D ferrimagnetic chain with Heisenberg exchange, DMI and uniaxial anisotropy is shown in Fig. 2. MRG shows compensation of its ferrimagnetic moment at room temperature and as a result is predicted to support sustained spin oscillations in the THz region [6]. Our simple model, once adjusted to accommodate the symmetry and dimensionality of the real material, will represent an efficient method to theoretically investigate the existence of such oscillations and of potential chiral ground states.References: [1] H. Van Leuken and R.A. De Groot, Physical review letters., Vol. 74(7), p.1171 (1995) [2] S. Lenne et al., arXiv preprint arXiv:1903.04432. (2019) [3] W. Legrand et al., Nano letters., Vol. 17(4), pp.2703-2712 (2017) [4] A. Fert, N. Reyren and V. Cros, Nature Reviews Materials., Vol. 2(7), p.17031 (2017) [5] Y. Onose et al., Physical review letters., Vol. 109(3), p.037603 (2012) [6] R. E. Troncoso et al., Physical Review B., Vol. 99(5), p.054433 (2019)

Fully-Vector Simulation Framework for the Investigation of Magnetisation Dynamics and Skyrmions

Assessment of local magnetization in 3D objects is indispensable to performance estimation of magnetic recording processes and electric power devices. It was shown that an elementary Stoner-Wohlfarth-like hysteresis operator may be constructed using two-node Hopfield neural network (HNN) having internal positive feedback [1]. The approach was further utilized to simulate vector hysteresis in arbitrary 2D geometries ([2, 3]). This paper presents an approach using which local magnetization in 3D objects exhibiting hysteresis may be assessed. It utilizes a four-node tetrahedron-shaped HNN (Fig. 1.a) with activation functions “f” constructed using a weighted superposition of a step and sigmoidal functions in accordance with the M-H curve squareness. Vector orientation of the activation function a neuron is assumed to be along the unit vector ev initiated from the tetrahedron center point to the vertex corresponding to that neuron (Fig. 1.b). Feedback kij between any two neurons is given by: Kij=kcopl (evi . evj), where kcopl is a constant identified by the material coercivity. Given an applied field H orientated along the unit vector eH, activation function outputs of the tetrahedron HNN implicitly settles in accordance with the minimum of the energy E: E=- ∑i= 1 to 4 (HeH . f evi + ½ ∑j=1 to 4, j≠i kij fi fj ). (1) Overall vector magnetization of the tetrahedron M eM is given by: M eM = ∑i = 1 to 4 fi evi . (2) Geometrical (shape) configuration of the tetrahedron affects the internal mutual node feedback factors and consequently the overall vector magnetization components. To demonstrate the applicability of the approach, an ellipsoid whose diameters were in the ratio of 2:1:1 was constructed using 120 tetrahedra. Main M-H curve of the material was assumed and corresponding activation function specifics and kcopl factor were consequently set (Figs. 1 and 2). More theoretical and computational details are given in the paper.References: [1] A.A. Adly and S.K. Abd-El-Hafiz, Journal of Advanced Research, Vol. 4, p. 403 (2013). [2] A.A. Adly and S.K. Abd-El-Hafiz, Journal of the Applied Computational Electromagnetics Society, Vol. 31, p. 765 (2016). [3] A.A. Adly and S.K. Abd-El-Hafiz, Journal of Magnetism and Magnetic Materials, Vol. 434, p. 151 (2017).

Utilizing Four-Node Tetrahedra-Shaped Hopfield Neural Network Configurations in the Local Magnetization Assessment of 3D Objects Exhibiting Hysteresis

We discuss localized spin modes in the model of monoaxial chiral helimagnet. Folllowing the idea suggested in Ref. [1] we address the so-called phase of forced ferromagnetism, where in the ground state all spins align with an external magnetic field applied along the chiral axis [2]. Our analysis shows that the intrinsic localized modes, or discrete breathers, exist and the Dzyaloshinskii-Moryia (DM) interaction does not hinder their emergence. We consider the spin Hamiltonian including the Heisenberg exchange coupling, the easy-plane anisotropy, the Zeeman coupling with an external magnetic field directed along the chiral axis, and the Dzyaloshinskii-Moryia interaction term along the chiral axis. It is supposed that the external field exceeds a critical value to stabilize the forced ferromagnetic phase. By using equations of motion for spin operators of a finite chain we find an approximate analytical solution of the discrete breather, establish necessary conditions for the breather frequency and the easy-plane anisotropy strength. The discrete breather accumulates not only magnon density but a topological charge. The topological charge depends on the balance between a scale of breather localization and a pitch of the spiral determined by the DM interaction. We calculate the energy of the discrete breather. It includes a part that may be obtained in the continuum limit and a pinning part that takes into account discreteness of the spin chain. The work is supported by the RFFI grant (project 20-02-00213)References: [1] R.F. Wallis, D.L. Mills and A.D. Boardman, Physical Review B, Vol. 52, p. R3828, (1995). [2] J. Kishine, A.S. Ovchinnikov, Solid State Physics, Vol. 66, Pp. 1-130, (2015).

Discrete Magnetic Breathers In Monoaxial Chiral Helimagnet

Thin films with high saturation magnetization deposited on semiconducting substrates have the potential to enable monolithic microwave integrated circuits (MMICs) operating at higher frequencies than conventional devices based on ferrites [1]. The ability to control the anisotropy in these films is a key requirement for use in high frequency devices. To demonstrate this ability, heterostructures of 2.5 nm Ru/50 nm FM/2.5 nm Ru, (FM = Co or Fe60Co40), were deposited by magnetron sputtering on native-oxide coated silicon substrates. The samples were deposited in the presence of a 20 mT in-plane bias field. The Ru underlayer is known to reduce the interfacial perpendicular anisotropy in transition metal films compared to SiO2 [2] and the Ru overlayer protects the film from oxidizing in air. In addition to quasistatic magnetization reversal curves broadband ferromagnetic resonance measurements (FMR) and in-plane angle dependent FMR at 20GHz were used to determine the magnetic properties of the samples. This includes the saturation magnetization, the gyromagnetic ratio and the field induced in-plane anisotropy. We find that the bias field produces an easy axis along the bias field direction characterized by a uniaxial anisotropy field of 2.9 ± 0.1 mT for Co and 3.1 ± 0.1 mT for Fe60Co40. We also find a low effective damping parameter of 9.8 × 10-3 in Co and 3.4× 10-3 in Fe60Co40.References: 1. Y. D. Zhang, S. H. Wang, J. I. Xiao et al., IEEE Trans. Mag. 37, 4 (2001). 2. J. B. Mohammado, G. Mankey, C. K. A. Mewes et al., J. Appl. Phys. 125, 023901 (2019).

Field Induced Uniaxial Anisotropy in Ferromagnetic Thin Films

Recently, there has been a significant amount of interest in the areas of ultrafast magnetism and spintronics due to the search of faster methods to process and magnetically record information [1]. One of the most promising materials in the field of ultrafast magnetism and spintronics are heterostructures consisting of ferromagnetic and antiferromagnetic layers. In such structures, spin-polarized current can be excited by femtosecond laser pulses [2]. One example of such materials is an intermetallic superlattice of exchange-bonded nanolayers TbCo2/FeCo, in which interlayer interaction shows ferrimagnetic pattern. Such structure possesses giant magnetostriction, a large coefficient of magnetomechanical coupling, controlled magnetic anisotropy and spin reorientation transitions, which can be generated by a magnetic field [3]. In this paper we investigated the spin-polarized photocurrent in a TbCo2/FeCo superlattice by the THz time domain spectroscopy. The sample was grown on a SiO2 substrate by cathode sputtering in magnetic field, which resulted in an in-plane anisotropy [4]. Optical pump beam illuminates the structure through the substrate and is focused on the superlattice. This allowed to excite spin-polarized currents in the superlattice, which generated an electromagnetic field in the THz range. The generated THz radiation was detected by electro-optical sampling [5]. The generation of THz radiation from a spintronic emitter based on TbCo2/FeCo in the range from 0.1 to 3 THz was shown. The total phase change of the THz signal after switching the magnetization of the spintronic emitter was observed (Fig.1). The change of THz phase took place at the application of coercive field with the value ~ 10 mT. The work is supported by State Task for Universities FSFZ-0706-2020-0022 and RFBR (#18-52-16021)References: 1. Stanciu C. D. et al., Physical review letters, Vol. 99, p. 047601. (2007) 2. Huisman T. J. et al. Applied physics letters, Vol. 110, p. 072402.(2017) 3. A. Klimov et al, IEEE Trans. Magn., Vol. 42, p. 3090-3092 (2006). 4. N.Tiercelin et al. Journ of Mag. & Mag. Mat., Vol 249, p. 519-523 (2002). 5. Kovalev, S. P., G. Kh Kitaeva., JOSA B, Vol.30, p. 2650-2656 (2013)
