In this work, we report on THz emission from FeMnPt-based synthetic antiferromagnetic structures (SAF), originating from the anomalous Hall effect (AHE) [1][2]. The peak amplitude of the THz emission is almost doubled as compared to the respective single layer with the same equivalent thickness. In addition, we demonstrate by both simulation and experiment that the THz emission provides a powerful tool to probe the magnetization reversal process of individual ferromagnetic layers in the SAF structure – an important building block for all types of spintronic devices. By measuring the polarization of the THz wave, we are able to determine the magnetization directions of the individual magnetic layers which are not possible or difficult to obtain by using other magnetic characterization techniques. Fig. 1 shows the shematic of the FeMnPt SAF structure under an in-plane external field. A femtosecond laser pulse is used to excite the sample, thereby generating the THz emission. Fig. 2 shows the temperoal profile of the THz emmission from both the FeMnPt SAF (solide-line: 0 Oe; dashed-line: 200 Oe) and a single layer FeMnPt (dotted-line). At zero field, The AHE in both layers of the SAF contributes to the THz emission, leading to a larger THz amplitude, which is almost doubled that of the single layer. By correalting the simulated and experimental results, the direction of magnetizaion in each FM layer during field sweeping can be determined becasue the THz emission is propotional to the dedection of mangetization in each FM layer. Our results show that THz emission provides a powerful tool to understand the magnetic reversal of SAFs.References: [1] Q. Zhang, Z. Luo, H. Li, et al., Physical Review Applied, vol.12, p.054027, (2019) [2] Q. Zhang, Y. Yang, Z. Luo, et al., Physical Review Applied, vol.13, p.054016, (2020)

MMM 2020

Terahertz Emission From an Exchange-Coupled Synthetic Antiferromagnet

The 65th Annual Conference on Magnetism and Magnetic Materials (MMM 2020) was held in a virtual form. The COVID-19 pandemic, with its associated uncertainty about international travel and the ability to gather in large groups, meant that the Steering Committee decided to cancel the face-to-face meeting that had been planned in Palm Beach, Florida November 2-6, 2020.

We were reluctant to give up the benefits of meeting face-to-face, and know that shifting to a virtual conference is a significant change for this community. Nevertheless, we are first and foremost concerned about the health and safety of all our Conference participants and their loved ones on returning home after travelling.

The MMM 2020 Steering Committee was working exceptionally hard, along with our sponsors, the IEEE Magnetics Society and AIP Publishing, to make this event serve the needs of our participants, who live in time zones all around the globe, in the best possible way.

You need a ticket to explore this event.

If you have already registered for MMM 2020, and you have already created an account, then you
just need to login (above).

If you have already registered for MMM 2020, but you have not yet created an account, then you
need to click on &quot;create an account&quot; (above) and then login.

Forgot your password? Go to
https://www.underline.io/log-in

If you have not yet registered for MMM 2020 but would like to do so, go to
https://magnetism.org/register

Still need help? Contact our team!


poster

The rare earth nitride series of intrinsic ferromagnetic semiconductors offers a rich selection of spin-orbit systems in which to study electrical transport and magnetic phenomenon, the various Hall effects being one of the many meeting places of these[1,2]. The central member of the series GdN (8S7/2) has a strong spin only magnetisation and relatively simple band structure, dominated by the Gd 5d conduction band and N 2p valence band. Electron doping is routinely achieved via the inclusion of nitrogen vacancies. Here we report on 'anomalous' Hall effect data in heavily doped GdN, which show an apparent change of sign of the dominant charge carrier as the sample is cooled through the ferromagnetic transition, while the anomalous Hall effect retains the negative sign of electron doped GdN. We will discuss these in the context of the calculated band structures of stoichiometric and heavily doped GdN.References: [1] W. F. Holmes-Hewett, R. G. Buckley, B. J. Ruck, F. Natali and H. J. Trodahl, 4f conduction in the magnetic semiconductor NdN, Phys. Rev. B. 100, 195119 (2019) [2] W. F. Holmes-Hewett, F. H. Ullstad, B. J. Ruck, F. Natali and H. J. Trodahl, Anomalous Hall effect in SmN: Influence of orbital magnetism and 4f band conduction, Phys. Rev. B. 98, 235201 (2018)

Anomalous Hall effects in rare earth nitrides

Spin polarization in nonmagnetic materials originates from the break of inversion crystalline symmetry that could occur globally or locally. Centrosymmetric (CS) nonmagnetic materials with hidden spin polarization induced by non-CS site symmetries and spin-orbit coupling are promising candidates for spintronic applications, in light of the zero net spin polarization and modulatable spin effects hidden in the local structures. There is, however, an open issue regarding the possible spin splitting induced by broken inversion symmetry at the sample surface. Therefore, it is critical to perform combined experimental and theoretical studies on centrosymmetric TMDC materials such as 2H-MoTe2 to explore the mechanism of the hidden spin polarization. 2H-MoTe2 crystallizes in a trigonal prismatic arrangement with an in-plane lattice constant of 3.517 Å and an out-of-plane lattice constant of 13.962 Å. The unit cell of it is centrosymmetry, but the monolayer has non-centrosymmetric structure. With the virtue of low detection depth of spin-ARPES (<6 Å with He-I), a large spin splitting of 236 meV and opposite spin polarizations up to 80% along out-of-plane direction (z axis) in K and K′ valleys were observed, consist with the density functional theory (DFT) calculations. We further found from the DFT calculations that a medium dipole field mimicked the surface symmetry breaking in ARPES measurements induces negligible variation of spin polarization, confirming that the measured spin effects originate from the intrinsic hidden spin polarization in 2H-MoTe2. The large spin splitting and net spin polarization found in spin-ARPES experiments also suggest that the hidden spin effects in inversion symmetric layered compounds can be used to generate large spin splitting on the surfaces in the absence of strong dipole field. Our combinatorial experimental and theoretical studies clarify the existence of hidden spin polarization in the centrosymmetric materials and opens the way of designing novel functional materials with coexisting hidden spin polarization and other hidden effects, such as hidden orbital polarization and hidden Berry curvature, for the energy efficient spintronics applications.

Direct observation of hidden spin polarization in 2H-MoTe2

Magnetic impurities in metals spin polarize their surroundings. This Ruderman-Kittel-Kasuya-Yosida (RKKY) polarization has been fundamental in the understanding of interactions in magnetic atoms and layers. When the impurity is heavy and magnetic, its large atomic spin-orbit coupling unquenches the orbital momentum. This is the case of lanthanide atoms, which have a significant orbital momentum responsible for their strong magnetocrystalline anisotropy. Recent utilization of this atomic spin-orbit coupling in spintronics include the perpendicular magnetic anisotropy of thulium iron garnet (TIG) films [1-4], the voltage-controlled magnetic anisotropy of interfacial rare-earth ions [5-6], and double compensation points of ferrimagnets [7]. In this presentation, we study lanthanide impurities in simple metals. The lanthanide orbital momentum couples to conduction electrons via the so-called skew scattering and induces a rotational current [8]. The predicted current has an orbital momentum density very similar to the RKKY one, with an algebraic decay and oscillations at twice the Fermi wavenumber. In addition to the charge density profile, we compute the observable effects, namely the Oersted magnetic field and Knight shift.References: [1] M. Kubota, A. Tsukazaki, F. Kagawa, K. Shibuya, Y. Tokunaga, M. Kawasaki, and Y. Tokura, APEX 5, 103002 (2012). [2] C. Tang, P. Sellappan, Y. Liu, Y. Xu, J. E. Garay, and J. Shi, Phys. Rev. B 94, 140403(R) (2016). [3] C. N. Wu, C. C. Tseng, Y. T. Fanchiang, C. K. Cheng, K. Y. Lin, S. L. Yeh, S. R. Yang, C. T. Wu, T. Liu, M. Wu, M. Hong, and J. Kwo, Sci. Rep. 8, 11087 (2018). [4] C. O. Avci, A. Quindeau, C.-F. Pai, M. Mann, L. Caretta, A. S. Tang, M. C. Onbasli, C. A. Ross, and G. S. D. Beach, , Nat. Mat. 16, 309 (2017). [5] A. O. Leon, A. B. Cahaya, and G. E. W. Bauer, Phys. Rev. Lett. 120, 027201 (2018). [6] AO Leon, GEW Bauer, accepted by Journal of Physics: Condensed Matter. [7] M. Imai, H. Chudo, M. Ono, K. Harii, M. Matsuo, Y. Ohnuma, S. Maekawa, and E. Saitoh, Appl. Phys. Lett. 114, 162402 (2019). [8] A. B. Cahaya, A. O. Leon, M. Rahimi Aliabad, G. E. W. Bauer, arXiv:2006.13024

Rotational currents around lanthanide dopants in simple metals

The signature of magnetism without having a ferromagnet in the sample stack is both novel and fascinating from fundamental research point of view. It is possible to alter the electronic states of non-ferromagnetic materials (Cu, Mn, Sc, Pt) to overcome the Stoner criterion and make them ferromagnetic at room temperature1,2. In this context it is desired to quantify the magnetic moment at the interface of such non-FM/OSC. We have studied the Cu/C60 heterostructure and quantified the magnetic moment induced in Cu using X-ray magnetic circular dichroism (XMCD) sum rules. The multilayer of Cu/C60 were prepared on Si (100) substrate without breaking the vacuum using DC magnetron sputtering and thermal evaporation for Cu and C60, respectively. SQUID magnetometry on sample S1:(Si(100)/Ta(5nm)/C60(8nm)/Cu(1.8nm)/C60(4nm)/Ta(2nm)) and S2:(Si(100)/Ta(5nm)/C60(16nm)/[Cu(1.8nm)/C60(8nm)]x2/Ta(2nm)) exhibit a clear ferromagnetic hysteresis even in the absence of any ferromagnetic element in the sample stack. The induced magnetic moment in the samples is corroborated to the charge transfer and the molecular coupling between the metal (Cu) and carbon. The origin of the charge state of C60 to a reconstructed interface is due to (4 4) 7-atom vacancy holes in the surface3. The possible reason of this induced magnetic moment is hybridization between dcu and pC60 orbitals1. In order to evaluate the spinterfacial magnetic moment, XMCD has been performed on the samples. Figure1 shows the XAS and XMCD spectra of the samples. The XAS spectra do not exactly match with Cu. The reason behind such misalignment is the hybridization between Cu and C60. Due to the charge transfer at the reconstructed Cu/C60 interface the density of state of Cu has been modified and exhibits ~ 0.01 μB /atom magnetic moment4. Our understanding of the interface between the NM/OSC heterostructures may bring the new insights to the field of organic spintronics.References: 1. F. Al Ma'Mari et.al., Nature 524, 69 (2015). 2. F. Al Ma’Mari et al., PNAS, 1620216114 (2017). 3. W.W.Pai et.al., PRL 104, 036103 (2010). 4. P. Sharangi et al., (unpublished)

Quantifying induced moment in non-magnetic Cu – C60 interfaces via x-ray magnetic circular dichroism

Mn-Ga alloys show promise for spintronic applications based on their tunable saturation magnetization (Ms) and goldilocks region perpendicular magnetic anisotropy (Ku).1 Thin films with perpendicular magnetic anisotropy have potential as low-dimensional highly reliable spintronic devises.2-5 The task remains to optimize magnetic properties for applications as a function of composition and dimensionality. In this study we attempt to understand the impact of composition on magnetic properties of Mn-Ga systems in the D022 structure. Density Functional Theory (DFT) calculations are used to study the role of vacancies on Ms and Ku of Mn-Ga family of alloys. While the DFT calculations capture the general trends seen in experiments, they are unable to quantitatively predict Ms and Ku with sufficient accuracy. This is attributed to the inherent complexities in the thin film growth of Mn-Ga systems, where the variations in Ms and Ku show a strong dependence on the growth variables. Machine Learning (ML) is implemented as a low-cost alternative to DFT, where we train and validate data-driven models based on Ms and Ku data compiled from surveying experimental literature. The ML models enable rapid predictions of Ms and Ku for previously unexplored compositions. New compositions are identified with implications in emerging spintronics applications.References: 1) H. Kurt, K. Rode, M. Venkatesan, P. Stamenov, PHYSICAL REVIEW B 83, 020405(R) (2011) 2) S. Iwasaki and K. Ouchi, IEEE Trans. Magn. 14, 849 (1978) 3) P. F. Carcia, J. Appl. Phys. 63, 5066 (1988) 4) T. Seki, T. Shima, K. Takanashi, Y. Takanashi, E. 82, 2461 (2003) 5) S. N. Piramanayagam, J. Appl. Phys. 102, 011301 (2007).

Density Functional Theory and Machine Learning Guided Study of Mn-Ga Alloys with Targeted Magnetic Properties

Magnon spin Nernst effect (SNE) has recently been proposed as a bulk effect in antiferromagnetic insulators without considering diffusions and boundaries1,2. However, real experiments3 deal with situations far from the ideal bulk picture in that: 1) the system is finite and shares imperfect boundaries with the detecting leads; 2) both the electrons in the leads and the magnons are diffusive; 3) the thermal power rather than the temperature gradient is calibrated. To properly accommodate these complexities, we formulate a diffusive theory of the SNE of antiferromagnetic magnons under a realistic device geometry. By solving the coupled spin diffusion equations of magnons and electrons with a finite spin transmission across the boundaries, we find that the detectable signal can be much larger than that predicted by the bulk picture. The diffusive effects also lead to a different phase diagram of the SNE compared to the bulk theory without diffusion. Counterintuitively, we also find that the diffusive magnon SNE exhibits an even symmetry with respect to a perpendicular magnetic field.References: 1. R. Cheng, S. Okamoto and D. Xiao, Phys. Rev. Lett., Vol. 117, 217202 (2016) 2. V. A. Zyuzin and A. A. Kovalev, Phys. Rev. Lett., Vol. 117, 217203 (2016) 3. Y. Shiomi, R. Takashima and E. Saitoh, Phys. Rev. B, Vol. 96, 134425 (2017)

Diffusive spin Nernst effect of antiferromagnetic magnons

Topological spin textures, such as skyrmions, have attracted intense interest in recent years. Magnetic skyrmions have been studied almost exclusively in bulk ferromagnets (FM) or FM multilayers. Antiferromagnets (AF) have also been predicted to harbor topological spin textures such as AF skyrmions. Topological Hall effect has been a primary indicator of spin textures in magnetic materials. We observe unambiguous evidence of topological Hall effect in Pt/Cr2O3 bilayers grown on Al2O3(0001) and Al2O3(11-20), where Cr2O3 epitaxial film is an antiferromagnetic insulator[1]. Although Cr2O3 is insulating, the topological magnetic textures can be detected through a novel phenomenon: “spin-Hall topological Hall effect” (SH-THE), similar to what recently observed topological Hall effect in Pt/Tm3Fe5O12 bilayers[2]. The Pt/Cr2O3 bilayers exhibit clear topological Hall resistivity for Cr2O3 thicknesses below 6 nm near and above room temperature, which is above the Néel temperature of Cr2O3, revealing the key role of thermal fluctuations in the formation of spin textures[3]. The similarity of topological Hall signals in (0001) and (11-20)-oriented Cr2O3 films indicates that the emergence of spin textures is insensitive to crystalline orientation. This first observational evidence of topological Hall effect in HM/AFI bilayers significantly expands our materials base to include the large family of AF insulators for the exploration of AF-based skyrmion technology.References: [1]. Yang Cheng, Sisheng Yu, Menglin Zhu, Jinwoo Hwang and Fengyuan Yang, “Evidence of Topological Hall Effect in Pt/Antiferromagnetic-Insulator Bilayers,” Phys. Rev. Lett. 123, 237206. [2]. A. S. Ahmed, A. J. Lee, N. Bagués, B. A. McCullian, A. M. A. Thabt, A. Perrine, P.-K. Wu, J. R. Rowland, M. Randeria, P. C. Hammel, D. W. McComb, and F.. Y. Yang, “Spin-Hall topological Hall effect in highly tunable Pt/ferrimagnetic-insulator bilayers,” Nano Lett., 19, 5683 (2019). [3]. Wenbo Wang, Matthew W Daniels, Zhaoliang Liao, Yifan Zhao, Jun Wang, Gertjan Koster, Guus Rijnders, Cui-Zu Chang, Di Xiao and Weida Wu, "Spin chirality fluctuation in two-dimensional ferromagnets with perpendicular magnetic anisotropy" Nat. Mater. 2019, 18, 1054.

Evidence of Topological Hall Effect in Pt/Antiferromagnetic-Insulator Bilayers

Curvilinear magnetism is of great fundamental and practical interest whose rapid development is inspired by novel experimental technologies and wide potential applications [1]. A general approach for description of curvilinear ferromagnets [2] has been recently developed and used for thin wires and shells uncovering magnetochiral effects in statics and dynamics [1,3]. Besides intensive research of ferromagnetic materials, their antiferromagnetically ordered (AFM) counterparts are promising candidates for spintronics applications by their low sensitivity to external fields and ultra high eigenfrequencies [4]. Here, we present a general approach for description of AFM textures in curvilinear spin chains [5]. We show that the magnetic dipole-dipole interaction in these systems can be reduced to a hard-axis anisotropy along the chain. Lagrangian of the curvilinear AFM spin chain in continuum limit corresponds to the biaxial chiral helimagnet. Helix geometry shows existence of two equilibrium magnetic states depending on values of curvature and torsion: (i) homogeneous state in the local reference frame, it is typical for helices with the curvature larger than torsion; and (ii) periodic state is quasi-homogeneous in the laboratory reference frame. For specific case of the AFM flat chain there is the only ground state, with the order parameter being oriented perpendicular to the chain plane. We show that in curvilinear system transverse and longitudinal magnon modes in the AFM helix and ring are coupled due to geometry-induced Dzyaloshinskii–Moriya interaction.References: [1] R. Streubel, J. Lee, D. Makarov et al, J. Phys. D, 49, 363001, (2016); A. Fernández-Pacheco et al, Nat. Comm., Vol. 8, p. 15756 (2017). [2] Y. Gaididei, V. P. Kravchuk, D. D. Sheka, Phys. Rev. Lett. 112, 257203 (2014); D. D. Sheka, V. P. Kravchuk, Y. Gaididei, J. Phys. A, Vol. 48, p. 125202 (2015). [3] O. V. Pylypovskyi, D. D. Sheka, V. P. Kravchuk et al, Sci. Rep. Vol. 6, p. 23316 (2016); O. V. Pylypovskyi, D. Makarov, V. P. Kravchuk et al, Phys. Rev. Applied, Vol. 10, p. 064057 (2018) [4] V. Balz, A. Manchon, M. Tsoi et al, Rev. Mod. Phys., Vol. 90, p. 015005 (2018) [5] D. Y. Kononenko, O. V. Pylypovskyi, K. V. Yershov et al., arXiv:2005.05835 (2020)

Effects of Geometry on Curvilinear Spin Chains

The demonstration of efficient manipulation of the antiferromagnetic (AF) order parameter has highlighted its highly attractive properties for spintronics, including lack of magnetic stray fields, robustness against magnetic field perturbations and intrinsic dynamics in the THz regime [1, 2, 3]. Specific functionalities often depend sensitively on the magnetic domain structure [4]. In fully compensated AFs with no demagnetizing fields, magnetoelastic effects are expected to dominate [5,6]. We report direct imaging and analysis of AF domains in patterned epitaxial CuMnAs thin films. A pronounced effect of patterned edges on the domain orientation and domain wall width is demonstrated, which extends over several microns. A local alignment of the Néel vector with microtwin line defects is observed, which, combined with the edge effect, leads to the formation of lens-shaped domains oriented perpendicular to the patterned edges. We observe magneto-structural reconfigurations in which defect lines and surrounding AF domains grow together over the timescale of weeks at room temperature and over minutes 30K above room temperature.References: [1] P. Wadley, B. Howells, J. Zelezny et al., Science., Vol. 351, p. 587 (2016) [2] X.Z. Chen, R. Zarzuela, J. Zhang et al., Physics Review Letters., Vol. 120, p. 207204 (2018) [3] P. Nemec, M. Fiebig, T. Kampfrath and A.V. Kimel, Nature Physics., Vol. 14, p. 229 (2018) [4] A.L. Ross et al., Nano Letters, Vol. 20(1), p. 306 (2020) [5] O. Gomonay and V. Loktev, Journal of Magnetism and Magnetic Materials., Vol. 242(2), p. 1418 (2002) [6] O. Gomonay, V. Baltz, A. Brataas and Y. Tserkovnyak, Nature Physics., Vol. 14, p. 213 (2018)

Antiferromagnetic Domain Structure in CuMnAs Devices

Non-collinear antiferromagnets such as D019-Mn3Sn have attracted much attention owing to their large anomalous Hall effect (AHE) originating from non-vanishing Berry curvature [1-5]. We recently reported a growth of epitaxial D019-Mn3Sn thin films with various orientations by sputtering, where anisotropic AHE was observed [5]. To realize functional devices harnessing the unique features of this material system, it is necessary to clarify the correlation of the physical properties with various factors of thin film. Here, we study the correlation between AHE and crystal structure of Mn-Sn alloy film by changing post-annealing temperature (Ta) and Mn-Sn composition. We prepare two series of Mn3+xSn1-x thin films which are deposited on MgO(110) substrate by sputtering. The first series have a fixed x = +0.06 and Ta is changed from 300 to 600oC. The second series have various x (-0.35 ~ +0.32) with a fixed Ta = 500oC. Crystal structures are characterized by X-ray diffraction (XRD). Transport measurement is performed for microfabricated Hall devices. From XRD measurement, we find that dominant phase of Mn-Sn changes from Mn1.75Sn to D019-Mn3Sn as Ta increases (series 1), and changes from Mn3Sn2 to D019-Mn3Sn as x increases (series 2) in the studied range. Transport measurement for the series 1 reveals that appearance of AHE coincides with the formation of D019-Mn3Sn and the magnitude increases with Ta [Fig. 1]. Meanwhile, for the series 2, the largest AHE is obtained at around the stoichiometric composition [Fig. 2]. We here note that the two series are prepared at different times, leading to different magnitude of AHE. From a comparison with XRD results, we find that magnitude of AHE is well explained by multiple factors of crystalline structure including proportion of D019-Mn3Sn crystallite, crystalline orientation, and the order parameter. The obtained results provide an important insight to deepen the physics of non-collinear antiferromagnet and to realize new-functional devices. This work is partly supported by JSPS Kakenhi No. 19H05622 and No. 19J13405.References: [1] S. Nakastuji, N. Kiyohara and T. Higo, Nature, Vol. 527, p.212 (2015). [2] A. K. Nayak, J. E. Fischer and S. S. P. Parkin, Sci. Adv., Vol. 15, p.e1501870 (2016). [3] T. Higo, D. Qu and S. Nakatsuji, Appl. Phys. Lett., Vol. 113, p.202402 (2018). [4] T. Ikeda, M. Tsunoda and Y. Ando, Appl. Phys. Lett., Vol. 113, p.222405 (2018). [5] J. Yoon, Y. Takeuchi and H. Ohno, Appl. Phys. Express, Vol. 13, p.013001 (2020).
