The demonstration of efficient manipulation of the antiferromagnetic (AF) order parameter has highlighted its highly attractive properties for spintronics, including lack of magnetic stray fields, robustness against magnetic field perturbations and intrinsic dynamics in the THz regime [1, 2, 3]. Specific functionalities often depend sensitively on the magnetic domain structure [4]. In fully compensated AFs with no demagnetizing fields, magnetoelastic effects are expected to dominate [5,6]. We report direct imaging and analysis of AF domains in patterned epitaxial CuMnAs thin films. A pronounced effect of patterned edges on the domain orientation and domain wall width is demonstrated, which extends over several microns. A local alignment of the Néel vector with microtwin line defects is observed, which, combined with the edge effect, leads to the formation of lens-shaped domains oriented perpendicular to the patterned edges. We observe magneto-structural reconfigurations in which defect lines and surrounding AF domains grow together over the timescale of weeks at room temperature and over minutes 30K above room temperature.References: [1] P. Wadley, B. Howells, J. Zelezny et al., Science., Vol. 351, p. 587 (2016) [2] X.Z. Chen, R. Zarzuela, J. Zhang et al., Physics Review Letters., Vol. 120, p. 207204 (2018) [3] P. Nemec, M. Fiebig, T. Kampfrath and A.V. Kimel, Nature Physics., Vol. 14, p. 229 (2018) [4] A.L. Ross et al., Nano Letters, Vol. 20(1), p. 306 (2020) [5] O. Gomonay and V. Loktev, Journal of Magnetism and Magnetic Materials., Vol. 242(2), p. 1418 (2002) [6] O. Gomonay, V. Baltz, A. Brataas and Y. Tserkovnyak, Nature Physics., Vol. 14, p. 213 (2018)

MMM 2020

Antiferromagnetic Domain Structure in CuMnAs Devices
