Usually negligible thermoelectric effects in superconductors can be increased using the simultaneous effects of spin splitting and spin filtering. These superconductor-ferromagnetic hybrids have been predicted to have thermal electric efficiencies (zT ~ 1.8) far exceeding any other cryogenic thermoelectric materials. Confirmation of these predictions requires controlled S-F interfaces, the generation of temperature gradients, and precise local cryogenic thermometry. S-F heterostructures have been fabricated using a combination of lithography, thermal evaporation, and magnetron sputtering, providing precise control over interfaces, materials, and geometries. Heaters and resistive thermometers, patterned via focused ion beam assisted platinum deposition have been calibrated and optimized for thermal transport measurements at cryogenic temperatures. Finally, the Seebeck coefficient of S-F heterostructures has been measured in the presence of a magnetic field. This measurement framework and measurement set the stage for additional studies of the effects of dimensionality, ferromagnet polarization, and interface quality.References: P. Machon, M. Eschrig, and W. Belzig, “Nonlocal thermoelectric effects and nonlocal onsager relations in a three-terminal proximity-coupled superconductor-ferromagnet device,” Phys. Rev. Lett., vol. 110, p. 47002, 2013. P. Machon, M. Eschrig, and W. Belzig, “Giant thermoelectric effects in a proximity couple superconductor- ferromagnet device,” New J. Phys., vol. 16, p. 073002, 2014.
