Electrical writing and readout of antiferromagnetic insulators is a key prerequisite in view of using this class of materials in applications. Only recently, this has been demonstrated in insulating AFM/heavy metal bilayers by utilizing the transverse spin Hall magnetoresistance effect (SMR) as the readout. In the electrical measurement, a steplike signal resulting from a magnetic SMR contribution was reported in NiO1 and α-Fe2O32, while non-magnetic contributions due to artifacts in the heavy metal layer were found to mimic the signal expected from the magnetic switching.3,4 These results have generated a debate on the magnitude of the magnetic contributions, the reliability of the SMR readout mechanism and even on the possibility of switching domains in AFMs electrically. In our work5 we use a table-top approach to demonstrate stable and reversible current-induced switching of large-area antiferromagnetic domains in NiO/Pt by direct imaging in a Kerr microscope.6 Concurrent transport and magneto-optical imaging measurements allow us to correlate the AFM domain switching fraction and magneto-transport signal response. We establish a procedure to subtract the non-magnetic contributions and extract the magnetic SMR response from the transverse resistance signal. The disentanglement of magnetic and non-magnetic contributions clarifies the presence of a significant SMR response, associated with the switching of the antiferromagnetic domains. We thus highlight the possibility to deduce details of the antiferromagnetic switching from simple transport measurements.References: 1 L. Baldrati, O. Gomonay, A. Ross, Phys. Rev. Lett. 123, 177201 (2019). 2 Y. Cheng, S. Yu, M. Zhu, Phys. Rev. Lett. 124, 027202 (2020). 3 A. Churikova, D. Bono, B. Neltner, Appl. Phys. Lett. 116, 022410 (2020). 4 C.C. Chiang, S.Y. Huang, D. Qu, Phys. Rev. Lett. 123, 227203 (2019). 5 F. Schreiber, L. Baldrati, C. Schmitt, Appl. Phys. Lett. 117, 082401 (2020). 6 J. Xu, C. Zhou, M. Jia, Phys. Rev. B 100, 134413 (2019).

MMM 2020

Concurrent magneto-optical imaging and magneto-transport readout of electrical switching of insulating antiferromagnetic thin films

The 65th Annual Conference on Magnetism and Magnetic Materials (MMM 2020) was held in a virtual form. The COVID-19 pandemic, with its associated uncertainty about international travel and the ability to gather in large groups, meant that the Steering Committee decided to cancel the face-to-face meeting that had been planned in Palm Beach, Florida November 2-6, 2020.

We were reluctant to give up the benefits of meeting face-to-face, and know that shifting to a virtual conference is a significant change for this community. Nevertheless, we are first and foremost concerned about the health and safety of all our Conference participants and their loved ones on returning home after travelling.

The MMM 2020 Steering Committee was working exceptionally hard, along with our sponsors, the IEEE Magnetics Society and AIP Publishing, to make this event serve the needs of our participants, who live in time zones all around the globe, in the best possible way.

You need a ticket to explore this event.

If you have already registered for MMM 2020, and you have already created an account, then you
just need to login (above).

If you have already registered for MMM 2020, but you have not yet created an account, then you
need to click on &quot;create an account&quot; (above) and then login.

Forgot your password? Go to
https://www.underline.io/log-in

If you have not yet registered for MMM 2020 but would like to do so, go to
https://magnetism.org/register

Still need help? Contact our team!


technical paper

Current induced spin-orbit torque (SOT) has been extensively investigated as a promising mechanism to switch magnetization electrically, which potentially allows higher energy efficiency in information technologies [1]. Metallic antiferromagnets (AFM) have been demonstrated to be an efficient source of SOT [2]. However, the relationship between the magnetic structure and SOT of AFM has been frequently overlooked, which not only clouds the origin of SOT in AFM but also hampers the engineering efforts for application development. Here we demonstrate that the magnetic structure of AFM IrMn has a strong influence on its SOT generation [3-4]. We fabricate epitaxial IrMn thin films of three phases, which have distinct crystal and magnetic structures, as shown in Fig. 1(a) and 1(b). The magnetic structures of the three phases have been carefully studied using the neutron diffraction technique. Using spin-torque ferromagnetic resonance technique (ST-FMR) [Fig. 1(c)] and IrMn/permalloy (Py) bilayers, we show that the measured SOT efficiencies () of L10-IrMn, L12-IrMn3 and γ-IrMn3 are 0.61±0.01, 1.01±0.03 and 0.80±0.01, respectively, as displayed in Fig. 1(d). These values are substantially larger than that of the polycrystalline IrMn, which is only 0.083±0.002. By altering the direction of electric current in the crystal lattice of L10-IrMn, we observe a 4-fold rotation symmetry in both the SOT efficiency and the in-plane magnetic anisotropy, as shown in Fig. 1(e). Fig. 1(f) shows that 4-fold symmetry disappears when a thin Cu spacer is inserted between L10-IrMn and Py while the measured SOT efficiency decreases to 0.22±0.03. These results suggest a magnetic structure enhanced SOT efficiency in L10-IrMn, which consists of a large isotropic bulk contribution and a comparable anisotropic interfacial contribution [3]. Moreover, we observe an anomalous out-of-plane damping-like torque in both L10-IrMn and L12-IrMn3 [4], as shown by the red curves in both Fig. 1(g) and 1(h). The microscopic origin of this torque appears to be an out-of-plane spin polarization. This is consistent with the intrinsic effects of the a laterally broken magnetic mirror symmetry () that is present commonly in both L10-IrMn and L12-IrMn3. We attribute the absence of this anomalous SOT in γ-IrMn3 to the lack of magnetic asymmetry due to a disordered magnetic structure.References: [1] A. Manchon et al, Rev. Mod. Phys. 91, 035004 (2019). [2] W. Zhang et al, Phys. Rev. Lett. 113, 196602 (2014). [3] J. Zhou et al, Sci. Adv. 5, eaau6696 (2019). [4] J. Zhou et al, Phys. Rev. B 101, 184403 (2020).

Large spin-orbit torque efficiency and magnetic symmetry effect in the antiferromagnet IrMn INVITED

Physics in nanometer-thick metallic films has been attracting many researchers because of abundant spintronics nature. In ultrathin films, some physical properties, such as the spin-charge conversion [1] and ferromagnetism [2], are gate-tunable. To extend further potential of ultrathin metallic films in spintronics, we demonstrate ferromagnetic resonance (FMR) in a 1 nm-thick ultrathin Co film [3], which exhibits sufficiently small FMR resonance field and narrow FMR linewidth simultaneously, for future realization of tunable magnon excitation. We prepared SiO2 (capping layer)/Co (tCo )/SiO2 (Sample A), where tCo was set to be 1, 2, 3 and 5 nm, and SiO2 (capping layer)/Co (1 nm)/Ta (3 nm)/SiO2 (Sample B). The Co was grown by using magnetron sputtering. The sample was placed in the center of an electron spin resonance (ESR) cavity (TE011) and FMR spectra were measured. The external dc magnetic field (Hex) and ac magnetic field (hrf) were applied along the in-plane direction of the film as shown in Fig. 1. Figure 2 shows comparison of the FMR spectra between Sample A (tCo = 1 nm) and Sample B. Whereas the thickness of the Co of both samples are the same, the clear FMR signal was observed only from Sample B, where the half-width at half-maximum and the resonance field were comparable to that of the bulk Co system. The results directly indicate that the insertion of 3 nm-thick Ta plays a dominant role for generating FMR in the ultrathin Co film. Furthermore, the narrow linewidth and the low resonance field indicate that the ultrathin Co film simultaneously possesses uniform and strong magnetization, which has not been achieved previously [4,5]. The successful detection of FMR from ultrathin Co enables efficient magnon excitation that is gate-tunable. More detailed discussion will be given in the presentation.References: [1] S. Dushenko, M. Shiraishi et al., Nat. Commun. 9, 3118 (2018). [2] D. Chiba et al., Nat. Mater. 10, 853 (2011). [3] S. Yoshii, M. Shiraishi et al., submitted. [4] S. T. Purcell et al., J. Appl. Phys. 69, 5640 (1991) [5] R. Gieniusz et al., J. Magn. Magn. Mater. 272-276, E911 (2004)

Realization of Ferromagnetic Resonance in 1nm Co ultrathin film

There is increased interest in conductive ferromagnetic materials and structures due to their higher moments and compatibility with semiconductor fabrication methods and technology. They offer enhancement in resonance frequencies and higher permeabilities in composites and nano-structures for applications in telecommunications and wave absorption [1,2]. The electromagnetic wave interaction with conductive ferromagnetic structures in these applications is complex due to coupling of both electric and magnetic fields with the magnetic material. This leads to non-uniform electromagnetic fields with different skin depths (both non-magnetic and magnetic). Early theoretical work focused on simple and saturated magnetic structures, excited in the linear region with uniform fields and involved solving the linearised system of Maxwell's equations and the Landau-Liftshitz equation for simplicity. This included planar structures [3], thin-films [4], and infinite cylinders [5]. Practical confined 2-D and 3-D magnetic structures found, for example, in composites have complex ground states and magnetic pinning, multi-layered with dielectrics, and experience non-uniform internal electromagnetic fields that yield complex precession and resonance modes that are not well understood. In this work, we solved the coupled system of Maxwell's and Landau-Lifshitz-Gilbert equations using a stable algorithm based on the finite-difference time-domain (FDTD) method to study the transient electromagnetic wave propagation and resonance in infinitely long cobalt nano-prisms with square cross-section of sides 50-1000 nm, excited by a 70 GHz plane wave [6]. The simulations revealed a curling exchange resonance mode excited by the induced axial current for prism sizes less than 100 nm. Larger prisms exhibited confined edge and corner resonance modes due to local power absorption and skin effects. The magnetic skin depth at resonance was estimated to be 50 nm from the calculated local power absorption spectra (see Fig. 1).References: [1] Y. Shirakata; N. Hidaka, M. Ishitsuka, A. Teramoto, and T. Ohmi, IEEE Trans. Magn. 44, 2100 (2008). [2] Y-B. Feng, T. Qiu, C-Y. Shen, and X-Y. Li, IEEE Trans. Magn. 42, 363 (2006). [3] W. S. Ament and G. T. Rado, Phys. Rev. 97, 1558 (1955). [4] J. W. Hartwell, Proc. IEEE 56, 23 (1968). [5] L. Kraus, Czech. J. Phys. B 32, 1264 (1982). [6] M. M. Aziz and C. McKeever, Phys. Rev. Applied 13, 034073 (2020).

Electromagnetic Wave Absorption and Resonance in Infinite Cobalt Nano-Prisms

A novel magnetic cooling device (MCD) that comprises thermoelectric (TE) and magnetocaloric (MC) materials is proposed, partially based on the previous work [1]. A sandwich structure, as shown in Fig. 1, has a MC material (MCM) in the center and two TE materials at the outer parts. The presence of the TE materials in the MCD guides the heat flow direction and enhances heat pulsation. In this case, the usage of a TE material that combines large TE with small MC responses within a similar temperature region enhances not only magnetic flux density but also heat exchange efficiency. In this study, we demonstrate that MnP thin films with integrated TE and MC functionalities are an excellent candidate for the proposed MCD. The MnP films were grown on Si substrates at 300, 400 and 500°C [2], and both the MC and TE effects were investigated systematically. The 400 oC sample shows the optimal TE and MC responses. A large TE effect is observed in the temperature region 250 – 400 K. The large power factor of 24.06 μW m-1 K-2 is achieved at room temperature. In this temperature region, the film shows a small MC effect (~1.23 J/kgK at 5T) but a strong magnetic response that gives rise to the enhanced TE effect. These properties would enable the MCD to operate at high frequency.References: [1] A. Kitanovski, and P. W. Egolf, Int. J. Refrig. 33.3,449464(2010). [2] A. T. Duong, T. M. H.Nguyen, , D. L. Nguyen, R. Das, H. T. Nguyen, B. T. Phan, and S. Cho, J. Magn. Magn. Mater. 482,287291(2019).

Novel MnP thin films with integrated thermoelectric and thermomagnetic functionalities for energy-efficient solid state refrigeration

Magnetorheological elastomers are smart materials that can deform and change shape based on the application of a magnetic field. These magnetic elastomers perform best in soft robotics and biomedical applications when they have increased anisotropy, or different properties along different axes. To increase this anisotropy, one can utilize hard magnetic particulate, magnetic annealing, and fused deposition modeling (FDM), also known as 3D printing. Hard magnets can be oriented using an external alignment field, and strontium ferrite is specifically interesting because it costs less than other rare-earth magnets (or materials). FDM is usually a final step in creating anisotropy in a sample (1), and it allows magnetorheological elastomers components to be more accessible for other applications. Our thermoplastic magnetic elastomer composite is created using solvent-casting techniques with 15 vol% SrFe12O19 particulate. The material is then extruded into FDM filaments using a Filastuder. During the extrusion process, some filament is magnetically annealed in an axial applied field created by NdFeB magnets, while other filament extruded without magnetic annealing acts as the control. Mechanical stress vs. strain curves of the extruded filaments are acquired using an MTS tensile testing machine. Magnetic hysteresis loops are measured using a vibrating sample magnetometer (VSM). In order to determine the relative level of magnetic anisotropy within the samples due to these factors, hysteresis loops with the field applied parallel and perpendicular to the axis of extrusion are compared to one another. Magnetoactive testing is used to measure the mechanical deflection angle as a function of the strength of a transverse applied magnetic field. Understanding the mechanical, magnetic, and magnetoactive properties of this magnetorheological elastomer provides insight into how magnetic anisotropy can be controlled by a combination of hard magnetic particulate, magnetic annealing, and FDM for optimized performance.References: 1. Patton, et. al., “Manipulating magnetic anisotropy in fused filament fabricated parts via macroscopic shape, mesoscopic infill orientation, and infill percentage.” Additive Manufacturing, Vol. 27, pp. 482-488 (2019).

Thermoplastic Elastomers with Strontium Ferrite Particulate and Magnetic Annealing used for Fused Deposition Modeling

The design of the materials showing first-order magnetic transitions (FOMTs) with smallest possible thermomagnetic hysteresis stimulates considerable research interest because hysteresis can be detrimental for certain applications, such as solid-state caloric cooling [1]. The overwhelming majority of materials with a reasonably small hysteresis contain transition metals, and their behavior is closely associated with the itinerant-electron metamagnetism of the transition metals present in the system [2,3]. We observed anhysteretic FOMT in a lanthanide-based compound Pr2In with the classical RKKY-type magnetic interaction between 4f electrons of trivalent Pr. Although such behavior is phenomenologically similar to Eu2In, another lanthanide system showing hysteresis-free FOMT [4], the crystal structure and magnetic interactions in Eu2In are markedly different from Pr2In due to the presence of divalent Eu [4,5]. In the vicinity of ferromagnetic to paramagnetic transition temperature (TC ~57 K) Pr2In exhibits a large magnetic field-induced entropy change with the maximum value of -ΔSM ~ 23 J/kg K for ΔH = 50 kOe, which is comparable to a number of other potential magnetocaloric materials in the temperature range of 40-80 K, reported in the literature [6]. The temperature and magnetic field dependence of ΔSM can be expressed as ΔSM ~ Hn , where the local exponent n varies with both H and T, showing a clear maximum with n>>2 , a characteristic feature of FOMT [7]. The observation of anhysteretic FOMT and a large MCE in Pr2In with conventional RKKY-type magnetic exchange promises further advancements in developing novel functional caloric materials by manipulating electronic structure of 4f-based materials. Acknowledgement: This work was performed at Ames Laboratory and was supported by DMSE, BES, Office of Science of the U.S.DOE. Ames Laboratory is operated for U.S DOE by Iowa State University under Contract No. DE-AC02-07CH11358.References: 1. N. A. Zarkevich et al., Journal of Alloys and Compounds 802, 712-722 (2019). 2. F. X. Hu et al., Applied Physics Letters 78, 3675 (2001) 3. A. Fujita et al. , Physical Review B 67, 104416 (2003) 4. F. Guillou et al., Nature Communications 9, 2925 (2018). 5. A. Biswas et al., Physical Review B 101, 224402 (2020). 6. L. Li et al., Journal of Alloys and Compounds 823, 153810 (2020). 7. J. Law et al., Nature Communication 9, 2680 (2018).

Large magnetocaloric effect due to anhysteretic first-order transition in Pr2In

Discovery of the giant magnetocaloric effect (MCE) in interrmetallic Gd5(Si2Ge2) [1] led to an increase the interest in the materials with large MCE due to the possibility of their practical application as a working body [2] in magnetic cooling devices. Recently so-called shape-memory ferromagnets based on Heusler alloys Ni-Mn-Z (Z = Ga, In, Sn, Sb) began to be considered as the promising materials. For example, for Ni50Mn35Sn15 the value of △S = 14,2 J/(kgK) at 187 K in a magnetic field of 50 kOe [3]. The aim of this work was to study the effect of variation in chemical composition (the relative concentration Ni/Mn) on the MCE in Ni43+xMn46-xSn11 (x = 0; 1) Heusler alloys. Ingots were prepared by arc melting in an inert atmosphere and subsequently subjected to annealing at 1100 K for 24 h followed by furnace cooling. The elemental analysis and X-ray diffraction studies were performed. The magnetic and galvanomagnetic properties were measure at the Atomistitut, TU Wien using an MPMS XL7 (Quantum Design) SQUID magnetometer. The magnetic properties were measured in magnetic fields of up to 70 kOe in the temperatures range 150-330 K. As a result of this work it was established that the variation in the chemical composition does not lead to a significant change of the maximum value of the magnetocaloric effect (△S = 44 J/(kgK) and 40 J/(kgK) for Ni43Mn46Sn11 and Ni44Mn45Sn11, respectively), but shift its maximum (≈ 32 K). It was found that in the investigated alloys a change in the relative concentration Ni/Mn (and hence the e/a) does not significantly influence on the value of Curie temperature TC. The results of this work were obtained within the state assignment of the Ministry of Education and Science of the Russion Federation (theme “Spin” No. AAAA-A18-118020290104-2) and supported in part by RFBR grant (project No. 18-02-00739).References: [1] V.K. Pecharsky, K.A. Gschneider, Physical Review Letters, Vol. 78, p. 4494 (1997) [2] V.K. Pecharsky, K.A. Gschneider, Journal of Magnetism and Magnetic Materials, Vol. 200, p. 44 (1999) [3] T. Krenke, E. Duman, M. Acet, E.F. Wassermann, X. Moya, L. Mañosa, A. Planes, Nature Materials, Vol. 4, p. 450 (2005)

Influence of Ni/Mn Concentration on the Magnetocaloric Effect in Ni43+xMn46-xSn11 (x = 0; 1) Heusler Alloys

Magnetorheological elastomers (MREs) are magnetoactive smart materials that exhibit mechanical deformation in the presence of magnetic fields. The greatest MRE performance is seen from magnetic annealing, which creates high internal anisotropy. It is hypothesized that increased anisotropy from Fused Deposition Modeling (FDM, extrusion-based 3D-printing) could also increase MRE performance. Alignment of magnetic particulate within the material used in this process would further bolster the anisotropy and, thus likely, the magnetoactive response of the printed part. This work studies how different magnetic annealing setups can be applied to thermoplastic MRE extrusion geometries and how each setup effects resulting magnetoactive properties. Three different magnetic fields were used in the annealing process: no magnetic field (0M), stronger field (5M), and weaker field (3M). The magnetic annealing setup was composed of four stacks of NdFeB magnets arranged longitudinally around the extrusion path for an axial applied field. 0M had no magnets, 5M had 5 NdFeB magnets, and 3M had 3 NdFeB magnets each separated by a steel spacer acting as a saturated magnet. A map of each magnetic vector field was characterized in 3D using a gaussmeter mounted to a robotic arm. Despite the different number of rare-earth magnets, the non-zero fields had fairly minimal differences. Both non-zero magnetic annealing setups generated greater magnetoactive response in the final MRE than zero field (Fig 1). Between the two non-zero fields the stronger field gave the greatest response but was difficult to make samples with. This work demonstrates that both magnetic annealing setups can enhance performance over no magnetic field; while the preferred setup may depend on a compromise between enhanced performance with ease of extrusion.

Magnetic Annealing of Extruded Thermoplastic Magnetorheological Elastomers for 3D-Printing via FDM

In search of potential replacement of highly expensive rare-earth metal (Gd)and its alloys [1-2] for environment friendly magnetic refrigeration technology [3] near room temperature , the earth-abundant Mn-based alloys, particularly Mn5Ge3 (TC =297 K) [4], have got much attention with reasonably high relative cooling power (RCP). In this work, we undertake Mn5Ge3 alloy and optimize the synthesis, particularly excess Mn (to compensate evaporation loss) in arc melting method, followed by annealing conditions. The maximum magneto-caloric effect is observed for Mn5Ge3 alloy with ferromagnetic ordering at TC = 299(2) K and MS (at 5 K) =142 emu/g (by dc magnetization study) from arc melting synthesis with 5 % excess Mn and vacuum annealing at 800oC for 7 days. The magnetic ordering for optimized sample is further evaluated by detailed critical exponent study using modified Arrot plot (MAP) and scaling method gives second order phase transition at TC = 297.5(1) K with exponents β = 0.348(1) and γ=1.193(2), which lies in close proximity to 3D Heisenberg model. The magnetic isotherms are further employed to study the magneto-caloric effect. Using Maxwell equations, the change in magnetic entropy, -△Sm│max is calculated as 4.7 J/kgK at 5 T applied field; the field dependence of -△Sm|max follow power law behaviour, -△Sm│max ∝ Hn with exponent, n = 0.62(1), in well consistent with n = 0.638 for 3D Heisenberg model. Finally, the material parameter for practical utilization in magnetic refrigeration i.e. RCP = -△Sm│max x δTFWHM is obtained as 450 J/kg for a field change of 5 T, which is significantly larger than earlier reported 388 J/kg for Mn5Ge3 synthesized with annealing at 750oC for 4 days. Although obtained RCP value is nearly 70 % that for the commonly used rare-earth Gd, importantly with production cost maximum 32 % only [see Table I] that makes Mn5Ge3 alloy highly promising for magnetic refrigeration application near room temperatureReferences: 1. S. Y. Dankov, A. M. Tishin, V. K. Pecharsky, Phys. Rev. B 57, 3478 (1998) 2.S. Gorsse, B. Chevalier, and G. Orveillon, Applied Physics Letters 92, 122501 (2008) 3.C. Aprea, A. Greco, A. Maiorino, Journal of Physics: Conference Series 655, 012026 (2015) 4. T. Tolinski and K. Synoradzki, Intermetallic, vol. 47, pp. 1–5, (2014)

Optimization of magnetic refrigerant capacity of Mn5Ge3 alloy near room temperature

Magnetorheological elastomers (MREs) are a smart material with the ability to physically deform when in the presence of an applied magnetic field. Extruding MREs into filament allows for the use of FDM manufacturing. FDM has been shown to manipulate the mechanical and magnetic properties of polymer matrix composites, which in turn could fine-tune the magnetoactive responses of printed MREs. This project investigates how the magnetic and magnetoactive properties of composite materials made of thermoplastic polyurethane (TPU) and 15 vol% iron particulate are affected by the size of the particulate within the matrix. Two different sizes of iron particulate are tested: 100 mesh (<150 micron) and spherical carbonyl 1-3 micron. Varying particulate size is of interest for FDM 3D printing because of limitations due to small nozzle sizing. This means that larger particulate can cause more issues of clogging, though it is less expensive and more accessible than smaller particulate. After the composites were fabricated, the resulting magnetic properties were tested via a VSM. Hysteresis loops showed that the smaller particulate samples had a lower magnetic susceptibility than the larger particulate samples. That means the larger particulate will exhibit greater magnetization under the same applied field. The magnetoactive properties were tested by measuring the angle of deformation under various transverse applied magnetic field strengths (limit 0.4T). The magnetoactive properties of the filaments are shown visually in Figure 1 and quantitatively in Figure 2. In both, it can be clearly seen that the larger particulate samples respond with a greater angle of deformation at every tested applied field. In conclusion, larger particulate leads to greater magnetic susceptibility and magnetoactive deformation, but the smaller particulate does have a more desirable size and shape for FDM.
