Emergent behaviours in complex systems arise from simple interactions between individual components that lead to global complexity [1]. Emergence is found in nature as a mechanism behind intelligent biological processes [2], but thus far, little has been done to exploit the computational power that emergence could offer for machine learning hardware. Here we demonstrate how the emergent properties of a magnetic system can be exploited to perform meaningful computation in materio. Using a combination of X-ray photoemission electron (X-PEEM) microscopy and polarised neuron reflectivity (PNR), we show that arrays of interconnected magnetic nanowire rings demonstrate emergence as a result of complex domain wall (DW) pinning events. The stochasticity associated with DW pinning produces emergent, dynamic equilibria in DW population and array magnetisation [3]. We then present a phenomenological model of these stochastic pinning events and show that the model provides excellent agreement to our experimental data (Fig. 2). The system’s nonlinear response and its inherent memory allowed us to implement a machine learning paradigm called ‘reservoir computing’ (RC). In RC, artificial neural networks are replaced by time-dependent ‘reservoirs’ which capture the advantages of recurrent neural networks (RNNs), without the associated difficulty of training RNNs [4]. Using the model, we demonstrated the feasibility of the ring arrays performing machine learning tasks, including speech processing and signal classification. We believe the sub-millimetre size and ability to solve complex tasks makes the arrays exciting candidates for microprocessors, with parallel computation and memory capability, enabling more energy efficient data processing tasks due to the reduced computational expense.References: [1] - P. Curseu, J. Inf. Technol., 21, (2006), [2] - B. Lindsey et al, Comprehensive Physiology, 2, (2012). [3] - R. Dawidek et al. [Under Review], [4] - M. Lukoševičius and H. Jaeger, Comput. Sci. Rev., 3, (2009).
