Nanostructured Ni-Zn ferrite (NZF) thin film, deposited by a CMOS-compatible microwave-assisted solvothermal (MAS) process, exhibits ‘far-from-equilibrium’ arrangement of cations in the spinel structure with significant anisotropy, thus promising for miniaturized passive devices in GHz regime [1, 2]. Achieving extreme cationic distribution at sub-200oC is the hallmark of this process [3] where, selected metal precursors dissolved in a solvent transform into metal oxide and nucleate on an immersed substrate under microwave heating at 2.45 GHz interacting with solvents of high loss-tangent (tanδ). The objective here is to study the impact of the solvent tanδ on the film’s magnetic property, especially the surface spin-canting layer and interparticular dipolar interaction. NZF films were deposited on Si(100) substrates using various ratios of ethanol (tanδ≈0.941), 1-decanol (tanδ≈0.1), and benzyl alcohol (tanδ≈0.667). The best characteristics were for ethanol:benzyl alcohol ratio (vol.) of 3:5. A smooth, densely packed NZF film (~ 200 nm) composed of highly crystalline nanoparticles (8.6 nm) resulted. Raman analysis of A1g mode shows a degree of inversion for Fe3+ ions x = 0.21 corresponding to 89% population of Fe3+ in octahedral site which led to a net magnetic moment enhancement (Ms of 79 emu/cc@300K), much higher than with 1-decanol [1]. The magnetic size deduced from the Langevin function (DL:9.4 nm) is consistent with that of Scherrer’s crystallite size with surface spin canting layer of 0.5 nm at 300 K. Temperature-dependent magnetization at different dc fields shows strong inter-particle dipolar interaction, estimated as EDipole≈ 1.9×10-17 J (300 K); 1.3×10-16 J (5 K). The blocking process shows individual 2-level energy system replaced by a multi-valley energy system. Thus, TB distribution and anisotropy energy barrier were ascertained from the derivative of thermoremnant magnetization with temperature. A close association between the anisotropy constants and strength of dipolar interaction is realized, driven by the influence of high microwave absorbing solvents.References: 1 R.R. Kahmei, R. Sai, S. Arackal, S.A. Shivashankar, and N. Bhat, IEEE Magn. Lett. 10, 1 (2019). 2 R. Sai, S.D. Kulkarni, M. Yamaguchi, N. Bhat, and S.A. Shivashankar, IEEE Magn. Lett. 8, 3 (2017). 3 I. Bilecka and M. Niederberger, Nanoscale 2, 1358 (2010).

MMM 2020

The impact of the solvent tanδ on the magnetic characteristics of nanostructured NiZn-ferrite film deposited by microwave-assisted solvothermal technique
