**Please read the paper on the following link:**

https://1worldcontent.com/ess/9141.pdf

**Abstract:**

We present a circuit model for the co-simulation of spin qubits with their control and readout electronics in a common simulation environment. The model, completely simulated in Spectre, can handle all the basic operations on spin qubits, including readout and universal single and 2-qubit quantum gates. Furthermore, the model has the ability to include nonidealities such as decoherence and noisy control signals, thereby paving the way for circuit-technology co-optimization for spin-based quantum computation.

ESSCIRC ESSDERC 2021

Circuit Model for the Efficient Co-Simulation of Spin Qubits and Their Control &amp; Readout Circuitry

control electronics

circuit model

quantum gate

spin qubit

quantum computing
