**Abstract:**

This paper presents a new method to reliably simulate the PDE and jitter for realistic 3D device simulations of SPAD devices. This method is based on the use of electric field lines to mimic the carriers\&#39; trajectories, which allows the transformation of a 3D problem into a multitude of 1D problems. This idea is applied to the McIntyre model for breakdown avalanche probability to calculate PDE, but also for jitter prediction using a dedicated advection-diffusion model. The results obtained numerically are compared with an extensive series of measurements and show a good agreement on a wide variety of device designs.

ESSCIRC ESSDERC 2021

Comprehensive Modeling and Characterization of Photon Detection Efficiency and Jitter in Advanced SPAD Devices

technology computer-aided design (tcad)

avalanche breakdown probability

photon detection efficiency (pde)

single-photon avalanche diode (spad)

jitter

breakdown voltage
