**Please read the paper on the following link:**

https://1worldcontent.com/ess/9227.pdf

**Abstract:**

This paper presents the design of a 60 GHz Quadrature Digitally-Controlled Oscillator for a low-power Frequency-Modulated Continuous Wave radar System-on-Chip. The quadrature coupling is exploited to achieve a seamless and ultra wide frequency tuning range of 11 GHz. The oscillator is designed for integration in an All-Digital Phase-Locked Loop with a simplified interface with the digital loop filter without the need for an extensive calibration. A wide-band and low-power divider chain is designed using dynamic topologies. The circuits are integrated in GF 22-nm FDX CMOS technology and consume between 12.8 and 22.4mW across the frequency range (17.6mW on average).

ESSCIRC ESSDERC 2021

A 60 GHz QDCO with 11 GHz Seamless Tuning for Low-Power FMCW Radars in 22-nm FDSOI

adpll

wide-range

qdco

fmcw

low-power

mm-wave

radar
