Small battery-powered electronic devices such as the Internet-of-Things (IoT) wireless sensors and actuators have found widespread use in many building environments in recent years. However, these devices rely on battery power and batteries need charging or replacement. Current research efforts have focused on finding ways for these sensors to self-harvest energy from the environment in which they are installed1. Indoor photovoltaics (IPV) are an intuitive choice for harvesting the wasted indoor ambient light, even under low light conditions, and using it to charge the battery and powering of these devices2. In this work, we investigate battery charging properties of small rechargeable batteries from low charge to full charge, by assembling and using PV mini-modules of three different technologies, including monocrystalline silicon (c-Si), gallium-indium-phosphide (GaInP) and gallium-arsenide (GaAs) under broadband LED lighting at an illuminance of 1000 lx. Battery charging times are shortest for the more efficient GaInP and GaAs mini-modules whose spectral responsivity are a better match to the LED test source, which contains mostly visible photons, and longest for the less efficient Si cells. As a demonstration, a wireless temperature sensor mote was attached to the charging circuit and operated to determine its power consumption in relation to the available charging power. The mote’s maximum power draw was less than the charging power from the least efficient c-Si mini-module. Our findings affirm the feasibility of utilizing PV under typical indoor lighting conditions to power IoT devices.

AIP Publishing Horizons - Energy Storage and Conversion

Indoor photovoltaics for battery-powered sensors

battery charging

wireless sensor

indoor light

energy harvesting

photovoltaics
