In the recent past, organometal halide perovskites have gained huge attention for application in various optoelectronic devices such as solar cells, light-emitting diodes (LEDs), photo-detectors, Lasers, etc.1,2 Such a wide range of applications are attributed to the extraordinary properties of these materials such as large range energy bandgap tunability from 2.43 eV to 1.50 eV, large absorption coefficients (~21.026 mm-1), large charge carrier lifetimes (~260 μs), mobilities (μe=73 cm2/V-sec, μh=43 cm2/V-sec), and diffusion lengths (~7.7 µm).3–6 However, the instability of bulk perovskite materials in ambient air conditions limits their usage at the device level. Contrary to bulk counterparts, the low-dimensional, as well as quasi dimensional perovskites, show improved stability which is promising for the development of these materials for optoelectronic devices. We present, the Ruddlesden-Popper phase 2D perovskites of type (CH)2(MA)n-1PbnI3n+1, [CH=2-cyclohexylethylamine; MA=methylamine] where, n is an integer and represents the number of inorganic layers of PbI6 octahedron in the perovskite crystal structure (Figure 1a). The spin-coating of these materials results into self-assembled highly crystalline films. The energy bandgap (Eg) of these films decreased with an increase in n-value and upon illumination with λex~470 nm LED strong and tunable photoluminescence is observed (Figure 1b). Photocurrent density (λex~470 nm) for the photo-detectors is found to increase with increase in n-value from 16.67 nA/cm2 (n=1) to 67.78 nA/cm2 (n=4) at 0V bias as well as with increase in bias.

AIP Publishing Horizons - Energy Storage and Conversion

Investigation of 2D Ruddlesden-Popper Perovskites Optoelectronic Devices

large grain size

good photoluminescence

vertical two electrode

good photo response
