Recently, a regional MPC approach has been proposed that exploits the piecewise affine structure of the optimal solution (without computing the entire explicit solution before). Here, regional refers to the idea of using the affine feedback law that is optimal in a vicinity of the current state of operation, and therefore provides the optimal input signal without requiring to solve a QP. In the present paper, we apply the idea of regional MPC to min-max MPC problems. We show that the new robust approach can significantly reduce the number of QPs to be solved within min-max MPC resulting in a reduced overall computational effort. Moreover, we compare the performance of the new approach to an existing robust regional MPC approach using a numerical example with varying horizon. Finally, we provide a rule for choosing a suitable robust regional MPC approach based on the horizon.

Nonlinear Model Predictive Control Conference 2021

Reducing the computational effort of min-max model predictive control with regional feedback laws

model-based control

robust control

predictive control

quadratic programming

constraints

The IFAC Conference on Nonlinear Model Predictive Control (NMPC 2021) aims to bring together researchers interested in and work in the MPC field from both academia and industry. This allows us to reflect and establish the current state-of-the-art and focus on the future development of the MPC field towards relevant directions.

Model predictive control (MPC) is indisputably one of the advanced control techniques that have significantly affected control engineering practice with thousands of controllers implemented in various fields, spanning from the process industry to automotive and robotics. This is due to its unique ability to handle constraints, take preview information about disturbances and setpoint changes into account, and optimize performance. Furthermore, MPC allows the consideration of various types of dynamics, from linear to nonlinear, discrete to continuous, as well as an online adaptation of models and parameters. The research community on MPC is very active, with hundreds of papers published every year. Over the past decades, many theoretical, as well as implementation results, have been achieved.
