This paper presents a real-time capable nonlinear model predictive control (NMPC) strategy to effectively control the driving performance of an electric vehicle (EV) while optimizing thermal utilization. The prediction model is based on an experimentally validated two-node lumped parameter thermal network (LPTN) and one-dimensional driving dynamics. An efficient solver for the trajectory tracking problem is exported using acados and deployed on a dSPACE SCALEXIO embedded system. The lap time of a high-load driving cycle compared to a state-of-the-art derating strategy improved by 2.56% with an energy consumption reduction of 2.43% while respecting the temperature constraints of the electric drive.

Nonlinear Model Predictive Control Conference 2021

Embedded Real-Time Nonlinear Model Predictive Control for the Thermal Torque Derating of an Electric Vehicle

temperature control

embedded systems

permanent magnet motors

automotive control

real-time control

nonlinear model predictive control

optimal control

The IFAC Conference on Nonlinear Model Predictive Control (NMPC 2021) aims to bring together researchers interested in and work in the MPC field from both academia and industry. This allows us to reflect and establish the current state-of-the-art and focus on the future development of the MPC field towards relevant directions.

Model predictive control (MPC) is indisputably one of the advanced control techniques that have significantly affected control engineering practice with thousands of controllers implemented in various fields, spanning from the process industry to automotive and robotics. This is due to its unique ability to handle constraints, take preview information about disturbances and setpoint changes into account, and optimize performance. Furthermore, MPC allows the consideration of various types of dynamics, from linear to nonlinear, discrete to continuous, as well as an online adaptation of models and parameters. The research community on MPC is very active, with hundreds of papers published every year. Over the past decades, many theoretical, as well as implementation results, have been achieved.
