Over the last two decades, prototype devices for future classical and quantum computing technologies have been fabricated by using scanning tunnelling microscopy and hydrogen resist lithography to position phosphorus atoms in silicon with atomic-scale precision. Despite these successes, it is only recently that our group demonstrated that a donor precursor molecule other than phosphine is compatible with the hydrogen resist lithography technique [1]. Here we describe the successful fabrication of atomic-scale structures of arsenic-in-silicon, using arsine (AsH3) as the precursor molecule. We fully elucidate the surface chemistry and reaction pathways of arsine on Si(001), revealing significant differences to phosphine. The properties of arsenic-in-silicon devices, and potential benefits of using arsenic instead of phosphorus, are briefly highlighted using spectroscopic and electrical characterisation techniques. Also presented will be recent work showing that broadband electric force microscopy (bb-EFM) can be used to characterise the properties of a nanoscale p-n junction [2], made from phosphorus and boron using hydrogen lithography by our collaborators at IBM Research - Zürich.
[1] T.J.Z. Stock et al., ACS Nano, 14 3316 (2020).
[2] G. Gramse et al., Nature Electronics, 3 531 (2020).


MATERIALS FOR HUMANITY (MH 21)

Fabrication and characterisation of nano- and atomic-scale dopant structures in silicon
