Singapore

There has been growing interests in perovskite-silicon tandem solar cells to reach ultrahigh efficiency beyond the Shockley-Queisser limit. The ideal band gap for the tandem configuration is ~1.67 to 1.75 eV for the top cell and 1.12 eV for the bottom cell. The band gap of perovskites can be tuned by (partial) replacement of iodine anions with bromine or chlorine. However, the replacement of I with Br by more than 20%, which is necessary to enlarge the band gap to ~1.7 eV, leads to stability issues under illumination through phase separation. One approach to stabilize the perovskite is to introduce a two-dimensional (2D) phase in which sheets of [PbX6]−2 octahedra are separated by an excess number of long-chain molecules. Most of the recent studies have focused on the cation components of the 2D additives rather than the anions. We developed a 2D-3D mixed wide band gap (1.68 eV) perovskite using a mixture of thiocyanate with the more conventional choice, iodine. Through a careful application of atomic resolution transmission electron microscopy, we demonstrated that electrical and charge transport properties as well as the physical location of 2D passivation layers can be controlled with anion engineering of the 2D additives. Moreover, we can use this approach to extend light stability and to improve device performance. For a perovskite device, we achieved a PCE of 20.7% that retained &gt; 80% of its initial efficiency after 1000 hours of continuous illumination in working conditions. For a monolithic 2T perovskite/Si tandem solar cells, the champion 2T tandem device achieved a PCE of 26.7%.

MATERIALS FOR HUMANITY (MH 21)

Efficient, stable silicon tandem cells enabled by anion-engineered wide-bandgap perovskites

**Please view our Welcome to MH21 video.**

<center>
<figure class="video_container">
	 <iframe src="https://screencast-o-matic.com/watch/cr1UYHV1pcz?v=6&ff=1&title=0&controls=1" width=826 height=526 frameborder="0" allowfullscreen="true"> </iframe>
</figure>
	</center>


**Walkthrough Video**

Here is a Walkthrough showing how to navigate the conference and network with others

<center>
<figure class="video_container">
	 <iframe src="https://screencast-o-matic.com/watch/cr1vnrV1paE?v=6&ff=1&title=0&controls=1" width=826 height=526 frameborder="0" allowfullscreen="true"> </iframe>
</figure>
	</center>




	 Organized by

<a href="https://mrs.org.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/95d5789689d5f900b90e9fe54ea3cf0d.jpg"</a>



	 In association with

<a href="http://www.ntu.edu.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/334cd171ad2fdee033c635b368e5e160.png"</a>
	<a href="https://www.nus.edu.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/32e6f82c0440f7bb24c590f9f67821bd.png"</a>
		<a href="https://www.a-star.edu.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/72557865b589cfa3d2a0243ffce4a270.png"</a>




	 Supported by

		 <a href="https://www.visitsingapore.com/mice/en/about-us/about-secb/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/6e679842ead62be522ba6a630b82d5c9.png"</a>

To access the MH 21 Conference, [please register](https://mh21.mrs.org.sg/event/da3f9651-429f-4763-81b2-ebd7311b6bc8/websitePage:206f7605-1731-41f9-8421-56d3890f398f)

MH 21 is arranged around 6 themes that focus attention on pressing needs that should be addressed to enhance the well-being of communities and provide a forum for presenting breakthrough discoveries.

There has been growing interests in perovskite-silicon tandem solar cells to reach ultrahigh efficiency beyond the Shockley-Queisser limit. The ideal band gap for the tandem configuration is ~1.67 to 1.75 eV for the top cell and 1.12 eV for the bottom cell. The band gap of perovskites can be tuned by (partial) replacement of iodine anions with bromine or chlorine. However, the replacement of I with Br by more than 20%, which is necessary to enlarge the band gap to ~1.7 eV, leads to stability issues under illumination through phase separation. One approach to stabilize the perovskite is to introduce a two-dimensional (2D) phase in which sheets of [PbX6]−2 octahedra are separated by an excess number of long-chain molecules. Most of the recent studies have focused on the cation components of the 2D additives rather than the anions. We developed a 2D-3D mixed wide band gap (1.68 eV) perovskite using a mixture of thiocyanate with the more conventional choice, iodine. Through a careful application of atomic resolution transmission electron microscopy, we demonstrated that electrical and charge transport properties as well as the physical location of 2D passivation layers can be controlled with anion engineering of the 2D additives. Moreover, we can use this approach to extend light stability and to improve device performance. For a perovskite device, we achieved a PCE of 20.7% that retained > 80% of its initial efficiency after 1000 hours of continuous illumination in working conditions. For a monolithic 2T perovskite/Si tandem solar cells, the champion 2T tandem device achieved a PCE of 26.7%.

technical paper

Thermochromic material responds to solar spectrum differently at the stimulus of heat which makes it attractive in the energy saving smart windows application due to its rational response, simple set up and passive response. The most studied inorganic VO2 has the intrinsic problems of low luminous transmission (Tlum) and low solar modulation (ΔTsol the transmission difference between high and low temperatures).Numerous efforts such as employing dopings, nanoparticle-based composites, and nano-porous structuring have been widely studied. Our group have developed five new approaches to tackle this veritable challenge, namely, biomimetic nanostructuring including photonic structure6 and moth eye gridded structures tunable plasmonic structuresorganic and hybrid structures. In addition, new active controls has also been applied to thermochromic material to generate a new electro-thermochromics or mechanical-thermochromic materials. A very recent new liquid window developed will be presented.

Progress in Energy Saving Thermochromic Smart Windows

In many industries such as Aerospace, Defense, Marine, Transportation, Off-shore high performance materials are required. For such applications, laminated carbon fiber reinforced polymeric (CFRP) composites are preferred due to their high specific strength and stiffness compared to other advanced materials. While CFRP composites provide excellent inplane properties, their performance when subjected to transverse loadings, both static and dynamic, needs further improvements. In recent years, addition of nanoparticles such as carbon nanotubes, carbon nanofibers, graphene and nanoclay, when suitably modified with chemical functional groups on their surfaces, in the polymers used for the fabrication of fiber reinforced composites has resulted in significant enhancement in their static and dynamic properties as well as durability. Over last few years, systematic investigations were carried out by our group to optimize the processing of epoxy resin systems with combinations of nanoclay and multiwalled carbon nanotubes through a multi-step process involving combinations sonication, magnetic mixing, three-roll mill, and high shear mixing. Epoxy resin modified with the nanoparticles was then used to fabricate carbon fiber composites. Both modified epoxy and nanophased fiber reinforced composites were characterized for properties such as fracture toughness, storage modulus, loss modulus, tensile, flexure, low-velocity impact and flexural fatigue. Results of the study indicate significant enhancement is all the properties and reduced damages. These enhancements were attributed to increased interfacial interactions between the three phases: nanoparticles, polymers and fibers. Details of these studies will be presented. Financial support through funding from the Department of Defense, as well as the research work carried out by the graduate students are hereby acknowledged.

Performance Enhancements in Carbon Fiber Reinforced Polymer Composites through Nanoparticles Inclusion

The formation and control of surface creases in soft materials under compression have intrigued the mechanics community for decades and recently found many applications in tissue biomechanics, soft robotics and tunable devices. In spite of a rapidly growing literature in this field, existing methods of analysis often rely on a presumed crease configuration and consequently there is still a lack of profound theoretical understanding on crease nucleation. In this study, we propose a force based perturbation approach to predicting the occurrence of crease nucleation without assuming a post-instability configuration. In a set of carefully controlled FEM simulations, by considering the relative magnitudes among the element size, perturbation displacement and sample size, we find that beyond a critical strain around , a flat surface under uniform deformation becomes metastable, while the creased configuration becomes stable, with energy barrier for creasing proportional to the square of the FEM element size and therefore vanishing in the continuum limit. Beyond the Biot critical strain of , the uniformly deformed configuration of a flat surface becomes unstable. Our force-based instability criterion also enabled us to determine the critical conditions of crease formation for different materials under general loading conditions, leading to a set of crease diagrams. Interestingly, it is shown theoretically and validated experimentally that some highly compressible soft materials do not undergo creasing under loading conditions close to equibiaxial compression.

A perturbation force based approach to creasing instability in soft materials under general loading conditions

Light is a ubiquitous renewable energy resource that nature has implemented as the foundational power supply for biomass generation on Earth. Human society is also built upon an intense reliance on chemical demands for our food, materials, and pharmaceuticals; yet, the chemical industry has evolved to power those industrial processes with energy derived from the combustion of fossil fuels. While the chemical industry is a cornerstone of the modern world, it also exists as one of the most polluting sectors on the planet. Is it possible to develop novel nanophotonic materials that effectively harness optical energy to power chemical processes and transition to a sustainable energy supply of the global chemical industry? In this talk, I will detail recent efforts in the development of plasmonic photocatalysts. These nanophotonic materials have demonstrated unique pathways to activate and engage chemical bond formation when illuminated with visible light, primarily due to non-thermal contributions to chemical processes at interfaces. The talk will introduce fundamental concepts in the rational design of plasmonic catalysts, highlight several important demonstrations of plasmonic photocatalysts in reactions key for global sustainability (e.g., H2 generation and greenhouse gas mitigation), and describe recent developments in optically coupled transmission electron microscopy to reveal the influence of light on atomic-scale phase transformations. Important attention will be paid to describe work where the influence of light results in unique mechanistic pathways for chemical reactions, particularly hydrogenation chemistry and nanoscale phase transformations. Finally, this talk will conclude with an outlook on the future of nanophotonic chemical processes in the next decade.

Making and Breaking Chemical Bonds with Light

Meta-lenses consist of a large number of optical nano-antennas which are capable of focusing the incoming wavefront of light [1-6]. We use a 60 × 60 dielectric achromatic meta-lens array to capture multidimensional optical information. The highest efficiency can be up to 74% at a wavelength of 420 nm, while the average efficiency is approximately 39% over the whole working bandwidth. The light field images and the depth information of objects can be determined by reorganizing the patches of sub-images and calculating the disparity of neighbor sub-images, respectively. The depth information can be used to optimize the patch sizes to render the all-in-focus images without artifacts. The smallest feature of objects that could be resolved in our system is 1.95 μm under the incoherent white light. Our work provides several advantages associated with light field imaging: elimination of chromatic aberration, polarization selectivity and compatibility of the semiconductor process. Considering the flexibility, the achromatic multiplexed meta-lens array with integrated functionalities may be promising for multi-focusing microscopy, high-dimension quantum technology, hyperspectral microscopy, micro robotic vision, autonomous sensing, virtual and augmented reality (VR and AR), drones, and miniature personal security systems [7-10].
References:
[1] S. M. Wang, et al., Nature Comm. 8, 187 (2017).
[2] B. H. Chen, et al., Nature Nanotechnology 13, 227 (2018).
[3] V.-C. Su, et al., Adv. Optical Mater. 6, 1800554 (2018).
[4] H.‐H. Hsiao, et al., Adv. Optical Mater. 6, 1800031 (2018).
[5] R. J. Lin, et al., Nature Nanotechnology, 14, 227 (2019).
[6] L. Li, et al., Science 368, 1487–1490 (2020).
[7] G. Qu, et al., Nature Communications 11, 5484 (2020).
[8] M. K. Chen, et al., Advanced Optical Materials 4, 202001414 (2021).
Acknowledgment: This work was supported by RGC Areas of Excellence Scheme 2020/21 (AoE/P-502/20).


Meta-optics: Meta-lens for imaging, sensing, and quantum chip

Coherent optical excitations in van der Waals materials (2D polaritons) span a large range of optical phenomena which arise from their extraordinary dispersion relations [1]. Among the different polaritons, it is particularly interesting to examine polaritons in hyperbolic materials (hyperbolic phonon-polaritons, hPhP) which show rich physical behavior, ranging from negative refraction and subdiffraction imaging. The phononic resonance creates a dispersion relation that contains multiple branches, which were shown to be tunable by the 2D material geometry, thickness, and surrounding environment [2], reaching relatively low losses in room temperature [3].
Among the various experimental techniques that are used in the field of 2D polaritons, scanning nearfield optical microscopy (SNOM) and its variants dominates the direct nearfield imaging of 2D polaritons. Specifically, recent advances in time-resolved SNOM allowed adressing the polariton’s dynamical properties as group velocity from the changes of interference of scattered polaritons with different time delays [4]. However, this interferometric technique cannot image the wavepacket dynamics, as it excludes the phase difference between different wavelengths. Different imaging techniques such as electron energy loss spectroscopy (EELS), where the 2D polariton dispersion was recently extracted [5], obtains only time-independent information on the polaritonic modes.
Here we present how an ultrafast transmission electron microscope (UTEM), driven by femtosecond mid-infrared pulses, can probe the spatiotemporal dynamics of 2D wavepackets.
We record how the mid-infrared pulses excites hPhP wavepacket and measure the wavepacket's trajectory inside the sample, revealing unforseen physical behaviors: multi-branch wavepacket splitting and wavepacket acceleration and deceleration. These phenomena are especially surprising since conventional wavepackets propagate in a fixed group velocity. We show that it is the unique dispersion relations of the hyperbolic PhPs that facilitates these phenomena, while recording group velocities between c/45 to c/850. These results examplify the wide physical spatiotemporal dynamical phenomena that can be probed through a non-destructive measurement using the unique combination of femtosecond temporal and nanometer spatial resolution of the UTEM.

Refs:
[1] D. N. Basov, A. Asenjo-Garcia, P. J. Schuck, X. Zhu, A. Rubio, Polariton panorama. Nanophotonics 10, 549–577 (2020).
[2] S. Dai et al. Tunable Phonon Polaritons in Atomically Thin van der Waals Crystals of Boron Nitride. Science. 343, 1125–1129 (2014).
[3] A. J. Giles et al. Ultralow-loss polaritons in isotopically pure boron nitride. Nat. Mater. 17, 134–139 (2018).
[4] E. Yoxall et al. Direct observation of ultraslow hyperbolic polariton propagation with negative phase velocity. Nat. Photonics. 9, 674–678 (2015).
[5] N. Li et al. Direct observation of highly confined phonon polaritons in suspended monolayer hexagonal boron nitride. Nat. Mater. 20, 43–48 (2021).

Imaging the dynamics of 2D polariton wavepackets

We will discuss research on generating a wide range of colors by nanostructuring materials that are colorless in bulk. Unlike pigments and dyes that have specific colors due to their chemical composition, we generate colors by precise nanopatterning structures using two-photon polymerization (TPL) and electron beam lithography (EBL), shaping them into a variety on geometry out of metals, semiconductors, stacks of metal/dielectrics, and most recently low refractive-index polymers. For instance, we introduce a heat-shrinking method to produce 3D-printed photonic crystals with a 5x reduction in lattice constants, achieving sub-100-nm features exhibiting a full range of colors. We recently demonstrate four-dimensional (4D) printing of shape memory polymer (SMP) that imparts time responsive properties to 3D structures. A new SMP photoresist based on Vero Clear was used achieving print features at a resolution of~ 300 nm half pitch using TPL. Prints consisting of grids with size-tunable multi-colours enabled the study of shape memory effects to achieve large visual shifts through nanoscale structure deformation. These structural colors could have an impact on humanity by providing potentially alternative solutions to spectral control in sensors to decorative colors in consumer products.

Colorless Materials For Humanity’s Color Needs

Unidirectional magnetoresistance (UMR) is a new type of MR effect, which is strongly related to the spin-orbit coupling (SOC) in various types of magnetic heterostructures, consisting of either conventional transition heavy metals or emergent materials systems such as topological insulators (TIs). UMR differs from other well-reported spin-dependent MR effects, such as the spin Hall magnetoresistance (SMR), that the resistance is current direction dependent. Although some seminal works have proposed its origin, especially for the UMR in normal metal/ferromagnetic metal (NM/FM) and TI/FM bilayer systems, the physical mechanisms that can lead to UMR still remain elusive. In this presentation, I will first introduce some of the common features and measurement protocols for UMR. Then I will discuss the possible scenarios that can lead to a sizable spin-dependent UMR in magnetic heterostructures: the spin Hall effect (SHE), Rashba-Edelstein effect (REE), and topological surface states (TSSs). Employing UMR for fast-track spin-orbit torque (SOT) characterization in a pump-probe fashion will also be demonstrated.

Unidirectional Spin-Dependent Magnetoresistance: Physics and Applications

Spin-orbit interaction (SOI) has been playing one of the most pivotal roles in condensed matter physics. Especially, the role of the SOI in spintronics and spin-orbitronics is quite significant and much effort has been paid to explore novel physics related with SOI in these research fields.
Although a magnitude of the SOI of solids has been thought to be inherently determined and unchanged, our finding of gate-tunable SOI, resulting in control of the inverse spin Hall effect, opened a new field of gate-tuneable SOI [1,2]. Furthermore, we have recently discovered that a strong electric field application to a solid with inherently small SOI enables creation of synthetic Rashba fields and gate-tunability of them [3].
In this presentation, the recently-found gate modulation of SOI in solids will be discussed.

References:
[1] S. Dushenko, M. Shiraishi et al., Nature Communications 9, 3118 (2018).
[2] S. Yoshitake, M. Shiraishi et al., Appl. Phys. Lett. 117, 092406 (2020).
[3] S. Lee, M. Shiraishi et al., to appear.


Gate modulation of spin-orbit interaction in solids

Two-dimensional magnets based on van der Waals materials are currently fostering great expectations for the advancement of spin-orbitronics, which aims to exploit the spin-orbit coupling in non-centrosymmetric magnetic heterostructures to enable current-driven magnetic torques and stabilize homochiral magnetic textures. Van der Waals magnets are particularly appealing for this purpose as their properties can be tuned by surface engineering at the atomic level. In this talk, I will present our investigation of the spin-orbitronics properties of selected highly promising van der Waals candidates, both in pristine and Janus configurations, from first principles and effective tight-binding models. I will first discuss the spin-orbit torque that emerges from inversion symmetry breaking in magnetic transition metal dichalcogenide monolayers [1] and demonstrate that sizable torques can be obtained, whose magnitude is controlled by the electric dipole due to the chalcogen elements. Most importantly, I will show the existence of a unique spin-orbit torque component that allows for field-free current-driven switching, of highest interest for applications. Then, I will discuss the nature of Dzyaloshinskii-Moriya interaction in these systems, and how they can stabilize magnetic skyrmions, but also magnetic bimerons depending on the magnetic anisotropy properties [2]. Finally, I will discuss the spin-orbitronics properties of Fe3Ge2Te2 and show that in spite of its high symmetry, its inherent mirror symmetry breaking enables the onset of an in-plane Dzyaloshinskii-Moriya interaction that can stabilize planar chiral textures [3].

[1] Smaili et al., arXiv:2007.07579
[2] Laref et al., arXiv:2011.07813
[3] Laref et al., Physical Review B 102, 060402(R) (2020)


Premium content

Efficient, stable silicon tandem cells enabled by anion-engineered wide-bandgap perovskites

Downloads

Next from MATERIALS FOR HUMANITY (MH 21)

Progress in Energy Saving Thermochromic Smart Windows

Similar lecture

Meta-optics: Meta-lens for imaging, sensing, and quantum chip
