Metal additive manufacturing is an invaluable part of robust and on-demand supply chains of the future. With its ability to consolidate material to high density into geometrically complex structures, selective laser melting (SLM) is a powerful tool for the fabrication of high strength, lightweight components. A limited pool of qualified alloys remains to be an impediment to greater adoption. Martensitic steels are a class of alloys that see widespread use in industries for tooling and highly stressed load bearing parts. However, their presence in the literature remains sparse in comparison to several workhorse steel alloys. In this work, we discuss the print optimization for this class of steels, including optimization of laser power, scanning speed, hatch distance and platform heating temperature. We investigate the general microstructural features of these steels, which is dominated by post-solidification displacive martensitic transformation and its response to cyclic thermal cycles in SLM. We demonstrate that martensitic high strength steels can be processed by SLM to have excellent mechanical properties in the as-printed state. Greater understanding of the SLM processing of this class of steels will enable the fabrication of stronger and lighter parts for increasingly demanding applications.

MATERIALS FOR HUMANITY (MH 21)

Untapped strength in metal additive manufacturing: characteristics and properties of martensitic steels by selective laser melting
