2D transition metal dichalcogenides (TMDCs) have potential for quantum applications but progress has been slow due to contact problems. In particular, quantum transport studies are difficult as low-quality contacts are exacerbated at cryogenic temperatures where quantum devices are typically operated. Here, we use indium alloy to form contacts with chemical vapour deposition grown single-layer and bilayer WS2 devices. The devices exhibit ultra-low contact resistances and Schottky barrier heights at temperatures as low as 3 K, which in turn enables high carrier mobilities and measurements of resonant quantum tunnelling. Density functional theory calculations provide further insights into the intricacies of the metal/semiconductor interface and quantum transport in the material. Our results unlock the potential for 2D semiconductors in low temperature applications such as in quantum information processing.
