Abstract Body: This work presents the design, fabrication, and characterization of 3D thin-film metal electrodes for electrochemical bio-sensing (EBS) applications utilizing inkjet printing (IP) on shape memory polymer (SMP) substrates. Inkjet printing electrodes on SMP allows for 3D electrode formation in a single process step at low temperature and atmospheric pressure. In this study, a thermally contracting SMP has been utilized to print EBS electrode patterns using IP silver nanoparticle ink, extending previous work. The silver nanoparticle ink electrode geometry is sintered and shrunk simultaneously by placing it into an oven for 3 minutes. It is observed that the reduction factor of the processed EBS (sintered and shrunk) achieves up to 60% approximately and creates a complex 3D metal topology which is difficult to obtain using conventional electrode fabrication techniques. SMP is a polymer which remembers its initial shape and returns to that shape when heated above its glass transition temperature. Generally, at room temperature SMP stays at martensite phase and achieves austenite phase after heat application (in this study, 180 C). In order to observe the shrinking characteristics of the SMP film used for this study (MagicShrink), 18 different samples (1 cm by 1 cm) were shrunk at six different temperatures (140 C to 190 C) for 3 minutes. It is observed that, the shrinking mechanism is similar and stable for each sample. The reduction factor of the shrunk film is 0.6 for each sample. In this study, nanoparticle silver ink (ANP DGP-40-LT-15-C) is used to IP EBS pattern using Dimatix Materials Printer (Fujifilm, DMP-2831). This nanoparticle ink becomes conductive by curing it at 120 C ~150 C for 10 minutes. But it is perceived that the desired conductivity can be achieved only within 3 minutes at 140 C to 190 C with SMP (simultaneous curing and shrinking mechanisms). Resistivity measurements of the SMP fabricated electrodes have been performed to characterize the process impact on thin-film performance. Scanning electron microscopy is utilized to further characterize the 3D microstructure and topology created by IP on SMP fabrication process for EBS at different process temperatures. Further, electrochemical characterization of the 3D SMP electrodes are performed and compared to a conventional EBS 2D electrode. Fabricating EBS on SMP with IP technology have shown promising potential to improve electrochemical sensing. The inkjet on SMP process demonstrates significant 3D silver electrode using nanoparticle ink for an increased electrode surface area for EBS, which is difficult to fabricate using conventional techniques, with potential applications for other electrode technologies benefitting from increased device surface area. References [1] R. C. Roberts, J. Wu, N.Y. Hau, Y.H. Chang, S.P. Feng, D.C. Li, &quot;Facile 3D Metal Electrode Fabrication for Energy Applications via Inkjet Printing and Shape Memory Polymer,&quot; Journal of Physics: Conference Series 557 (2014) 012006. [2] R. C. Roberts, S. Zeng, and N. C. Tien, &quot;Design and Fabrication of Buckled Metal Strain Gauges using Shape Memory Polymer and inkjet Additive microfabrication,&quot; Technical Digest, The 14th IEEE Conference on Sensors (Sensors 2015), Busan, Korea, Nov. 1-4, 2015, pp. 1665-1668.
