Since 1973, Earliest Deadline First (EDF) uniprocessor scheduling has been known to be superior to its Rate Monotonic (Fixed-Priority, FPS) counterpart. Such superiority manifested in optimality, the capacity of EDF to feasibly sustain full utilization, which FPS can only achieve in certain favorable circumstances. In 2005, further research results argued that EDF&#39;s superiority would also extend to finer-grained performance indicators, such as preemption count, release and response-time jitter, resilience to transient overload. Recent work allowed EDF uniprocessor scheduling to be used in place of default FPS in Ada Ravenscar systems with unchanged application code: this development provides an interesting and practical avenue for empirical EDF-to-RM performance comparisons in an especially lean and efficient embedded setting. We leveraged that opportunity to develop a toolbox that enables quantitative comparison of EDF-to-RM uniprocessor scheduling with lightweight run-time tracing and offline analytic. In this work we present that toolbox and illustrate results we obtained with it, which shed new light on the presumed superiority of EDF to RM.

AEiC 2021 - 25th Ada-Europe International Conference on Reliable Software Technologies

Removing bias from the judgment day: A Ravenscar-based toolbox for quantitative comparison of EDF-to-RM uniprocessor scheduling
