High harmonic generation (HHG) in gasses has become a method of choice among table-top extreme ultraviolet (XUV) sources. In order to generate higher photon energies from this process, many strategies can be implemented, including red-shifting and compressing the driver pulses. Here, we propose a new approach for inducing a red-shift to driver pulses and compressing them to few-cycle durations in a single stage. This method uses the recently discovered multidimensional solitary states (MDSS) pulses that result from the nonlinear Raman process in gas-filled hollow-core fibers. It has a few key advantages: 1) MDSS are created from relatively long pulses, making this method suitable for any laser source offering sub-picosecond pulses. 2) The MDSS pulses can be compressed by simple propagation through glass. 3) In contrast with commonly-used optical parametric amplifiers, the induced red-shift can be modest, allowing to reach a target XUV photon energy while minimizing the detrimental effects of long driver wavelengths on HHG efficiency.
To produce MDSS pulses, the output pulses of a Titanium-Sapphire system are stretched to 400 fs and coupled to a hollow-core fiber filled with nitrogen. In the fiber, intermodal nonlinear processes occur which lead to the red-shifted MDSS pulses. Then, CaF2 plates inserted into the beam path compress the pulses down to 12 fs and these are sent to an argon-filled cell where HHG occurs. From this simple apparatus, the HHG spectrum is expanded to cover the M$_{2,3}$ edge of cobalt and $10^9$ photons/second are generated at 60 eV. This significant XUV photon flux allows for the implementation of X-ray resonant magnetic scattering measurements on a cobalt/platinum ferromagnet, an example of photon-hungry application. Although such flux has previously been generated in a different gas from the direct output of the same laser system, the conversion efficiency of our approach is one order of magnitude higher as it allows to reach the target photon energy by generating harmonics in argon, a gas that offers a large generation efficiency. Due to its simplicity and versatility, our approach can readily be adapted to different applications and could be particularly interesting for high power Ytterbium laser systems offering sub-picosecond pulses.

CAP Virtual Congress 2021

Multidimensional Raman Solitons as Drivers of the High Harmonic Generation Process

ultrafast magnetism

multidimensional solitary states

high harmonics generation

**WELCOME TO THE 2021 CAP VIRTUAL CONGRESS UNDERLINE PLATFORM**

The CAP staff and our organizing and program committees are pleased to welcome you to our 2021 Congress filled with plenary talks, technical sessions/talks, student presentations and competition sessions, workshops, and several symposia offered by the CAP divisions and its partners.

You will also have opportunities to network with other delegates through the Gathertown platform accessed by selecting the lounge or posters button on the left.

Registered delegates should use the schedule button to call up the details of the session/event they wish to attend.  Each sessions includes a link to access the online platform where the event is taking place, either within Underline or through other Congress-related Zoom meetings.

Invited speaker talks are identified with an (I), and student competitors include a (G*) or (U*) to identify graduate or undergraduate presenters.

Please take the time to check out the information about our sponsors and exhibitors, request further information, or leave a note of thanks for their support.

General information about the Congress can be found on the CAP website Congress pages at https://www.cap.ca/congress/2021.

Looking for a specific talk?   A full searchable list is available on our Indico Congress site at https://indico.cern.ch/event/985448/contributions/

We look forward to sharing this exciting week with you!


technical paper

Seawater spray and precipitation are two main sources of icing and ice accumulation in cold ocean regions, presenting a major challenge for shipping and operating maritime equipment [1].
There is a limited number of analytical techniques to study seawater spray ice formation. MRI is known for its non-invasive capabilities in measurements of a solid ice [2,3]. In this work, we investigated the potential of MRI as an analytical measurement technique for studies of the seawater spray ice.
The signal detected with MRI/NMR comes from pockets of brine in the forming ice, and the unfrozen water, with the 1H NMR signal from the brine decreasing as the temperature drops and the brine freezes further. 3D MRI showed different freezing patterns and temperature gradients depending on the initial freezing temperature and the surface geometry. T1-T2 maps indicated strong changes in relaxation parameters as the freezing progresses, indicating changing environment for the brine in the growing ice [4]. In a separate freezing series using Na NMR, the amount of sodium in the brine remained almost unchanged until the brine reached the eutectic temperature, and the sodium precipitation accelerated.
These measurements were done on an MRI scanner, with the freezing setup designed to fit a 4 cm i.d. RF probe inside a 2.4 T superconducting magnet. To explore a possibility of using NMR for freezing studies in a more open environment, we also used a portable, unilateral NMR device to characterize sea spray freezing on a cold surface. The device consisted of a flat 3-magnet array [5] with the sensitive volume (approx.2 mm x 15 x 15 mm) at 1 cm away from the magnet surface. 1D-resolved 1H NMR measurements provided information on the brine concentration, T2 and diffusion at a range of temperatures.
The results provide information on the changing environment in brine in freezing sea sprays, with a potential for NMR studies both in the lab and in the field.

[1]A.R. Dehghani-Sanij, S.R. Dehghani, G.F. Naterer, Y.S. Muzychka, Ocean Eng. 143 (2017) 1–23.
[2]M.W. Hunter, R. Dykstra, M.H. Lim, T.G. Haskell, P.T. Callaghan, Appl. Magn. Reson. 36 (2009) 1–8.
[3]J.R. Brown, T.I. Brox, S.J. Vogt, J.D. Seymour, M.L. Skidmore, S.L. Codd, J. Magn. Reson. 225 (2012) 17–24.
[4] G.Wilbur, B.MacMillan, K.M.Bade, I.Mastikhin, J. Magn. Reson. 310 (2020) 106647.
[5] J.C.Garcia-Naranjo, I.Mastikhin, B.J.Colpitts, B.J.Balcom, J. Magn.Reson. 207 (2010) 337-344

Sea spray freezing measurements with MRI and portable NMR

Gravitational Wave (GW) detection from continuous sources such as pulsars is an anticipated discovery. However, due to exceedingly weak signals, detection is challenging. In this presentation, we detail the derivation of a Fourier transform of a continuous wave signal amenable for detection of the GW signal from a pulsar. We also present an easy to implement algorithm for computing peak heights and frequencies from analytical results arising from features in frequency evolution of gravitational wave signals. Our approach can handle gaps in data, allowing longer
coherence lengths. While the presentation focuses on GW detection from pulsar, our results are general and can be applied to any monochromatic signals of this form.

Fourier transform of gravitational wave signals from a pulsar

In optics, caustics are bright, sharp lines and shapes created by the natural focusing of light. Some examples include rainbows, the wavy lines on the bottom of swimming pools and the patterns produced by gravitational lensing. The intensity at a caustic diverges in the classical ray theory, but can be smoothed by taking into account the wave nature of light. In this work we consider a new type of caustic that occurs in quantum systems due to phase singularities; because phase is such a central concept in wave theory, this heralds the breakdown of the wave description and is an example of a quantum caustic. In particular, we consider analogue black holes which can be formed in a flowing Bose-Einstein condensate (BEC) gas. Waves flowing near the event horizon (describing analogue Hawking radiation) appear to suffer a logarithmic phase divergence, which is known as the trans-Planckian problem for gravitational black holes. We describe the regularization procedure required to cure this quantum caustic in our BEC system, and make connections to catastrophe theory.

Hawking radiation as a quantum caustic

Purpose: A quantitative measure of delivered ionizing radiation is recommended for quality assurance and quality control purposes for patients undergoing radiotherapy treatments. Current dosimeters are not well suited for direct measurements due to atomic composition and size limitations. We are developing a fiber optic probe dosimeter based on radiochromic material for in vivo dosimetry. Through measuring the change in optical absorption of the radiochromic sensor, we can quantify the absorbed dose of ionization radiation delivered in real-time. The radiation-sensitive material is composed of lithium-10,12-pentacosa diynoate (LiPCDA), which upon exposure, polymerizes and results in an increased optical density. We observed that monomers of LiPCDA can have two distinct crystalline morphologies, with aspect ratios 10:1 producing hair-like structures and 2:1 resulting in platelets, with polymerized absorbance peaks typically centred at 635 nm and 674 nm, respectively. We aim to characterize and compare the dose-response of the two crystal morphologies achieved through desiccation and Li+ concentration.

Method: The hair-like LiPCDA in commercial film was desiccated, producing crystals with an absorbance peak at 674 nm. Both materials were exposed to 50-3000 cGy using a clinical linear accelerator with a 6MV X-ray beam; samples of varying Li+ concentration were exposed to 200-400 cGy. Absorbance spectra for all samples were collected and were imaged with a scanning electron microscope to compare their crystal morphology.

Results: Differences in crystal morphology were not observed when hair-like LiPCDA was desiccated. However, varying the molar ratio of Li+ to PCDA to produce crystals with either 635 nm or 677 nm absorbance peak, differentiable crystal morphologies were observed. The platelet form is ~3x less sensitive to dose but with a more extensive dynamic range relative to hair-like.

Conclusion: Crystals can be preferentially grown and exhibit differing dose-response. The macrostructure effect on radiation sensitivity in the context of radiotherapy will be explored.

Characterization of modified radiochromic materials for measuring ionizing radiation

In this joint experimental and theoretical work [1], photoelectron emission from excited states of laser-dressed atomic helium is analyzed. We successfully demonstrate a method that is complimentary to transient absorption (e.g. [2]) for the assignment of light-induced states (LIS). The experiment is carried out at DESY in Hamburg and uses the FLASH2 free-electron laser to produce an extreme ultraviolet (XUV) pulse to which the helium atom is subjected along with a temporally overlapping infrared (IR) pulse in the multi-photon ionization regime ($\approx$10$^{12}$ W/cm$^2$). Analysis of the experiment occurs at the reaction microscope (REMI) end station [3] at FLASH2. The XUV pulse is scanned over the energy range 20.4 eV to 24.6 eV, corresponding to excited states of helium. The resonant, electric dipole-allowed $n$P states corresponding to a first step of single XUV photon excitation are shown to lead to ionization, independent of whether or not the lasers temporally overlap. However, dipole-forbidden transitions to $n$S and $n$D states corresponding to multiphoton (XUV $\pm$ $n$IR) excitation are observed during temporal overlap. Studying photo\-electron angular distributions (PADs) in the case where the ionization pathway of a LIS is difficult to resolve energetically allows for an unambiguous determination of the dominant LIS. The IR intensity and relative polarization between the lasers are varied to control the ionization pathway. Numerical solutions of the time-dependent Schr\"odinger equation within a single-active electron model with a local potential completely support the experimental findings in this project.
[1] S. Meister $\textit{et al}$., Phys. Rev. A $\bf{102}$ (2020) 062809; Phys. Rev. A $\bf{103}$ (2021) in press.
[2] S. Chen $\textit{et al}$., Phys. Rev. A $\bf{86}$ (2012) 063408.
[3] S. Meister $\textit{et al}$., Applied Sciences $\bf{10}$ (2020) 2953.
*work supported by NSERC, NSF, and XSEDE

Emergence of light-induced states in the few-photon ionization of atomic helium*

Lattice gauge theory is an indispensible tool for non-Abelian fields, such as those in quantum chromodynamics where lattice results have been of central importance for several decades. Recent studies suggest that quantum computers could extend the reach of lattice gauge theory in dramatic
ways, but the usefulness of quantum annealing hardware for lattice gauge theory has not yet been explored. In this work, we implement SU(2) pure gauge theory on a quantum annealer for lattices comprising a few plaquettes in a row with a periodic boundary condition. Numerical results are obtained from calculations on D-Wave Advantage hardware for eigenvalues, eigenvectors, vacuum expectation values, and time evolution. The success of this initial exploration indicates that the quantum annealer might become a useful hardware platform for some aspects of lattice gauge
theories.

SU(2) lattice gauge theory on a quantum annealer

We combined information from Fluorescence Correlation Spectroscopy (FCS), Nuclear Magnetic Resonance (NMR), Small-Angle X-ray Scattering (SAXS) and Single-Molecule Förster Energy Transfer (smFRET) to calculate conformational ensembles for the neuronal transcription factor initiation protein 4E-BP2. This is a 120-residue intrinsically disordered protein which toggles between an active, non-phosphorylated (NP) state and an inactive multi-phosphorylated (5P) state. An initial pool of 4E-BP2 structures was generated using Trajectory Directed Ensemble Sampling (TraDES) (Feldman & Hogue, Proteins: Structure, Function, and Bioinformatics, 46, 8-23, 2002). The ENSEMBLE method (Krzeminski et al, Bioinformatics, 29, 398-399, 2013) was used to search and select conformations within the initial pool that are consistent with the experimental data. NMR and SAXS data were used as restraints for the conformational search and FCS and smFRET data were used as validation.

The NP 4E-BP2 ensemble calculated with SAXS-only restraints showed a bimodal distribution of protein global dimensions such as the radius of gyration and the end-to-end distance. The back-calculated FRET efficiency and the hydrodynamic radius for this ensemble were lower than the respective experimental values. These inconsistencies are likely due to lack of short-range (5-20 Å) distance restraints, which are currently addressed by acquiring Paramagnetic Resonance Enhancement (PRE) data. Such data is available for the phosphorylated state (5P 4E-BP2), however this is partly folded, with a 4-stranded beta domain spanning residues 18-62. To address this challenge, we used the FastFloppyTail (FFT) program (Ferrie & Petersson, The Journal of Physical Chemistry B, 124, 5538-5548, 2020) to generate structures in the initial pool. As such, the folded region was modelled using the 5P 4E-BP2 folds from the Protein Databank, while the disordered tails were generated through the FFT algorithm. By incorporating the more realistic FFT-built prior in ENSEMBLE calculations, more accurate conformational ensembles of both phospho- and non-phospho- variants of 4E-BP2 were obtained. Analysis of these ensembles in terms of polymer physics and contact maps reveal new molecular level details lead to new insights into the biological function of 4E-BP2.

Protein Conformational Ensembles for a Disordered Protein Restricted by Separate Biophysical Experiments

Chemical warfare agents (CWAs) are potential threats to civil society and defence personnel. In recent years, many efforts has been deployed to develop a scalable, rapid and accurate detection system to identify trace amount of CWAs. Here we report a graphene-based field-effect transistor (GFET) sensor able to detect 800 ppb of dimethyl methyl phosphonate (DMMP), a simulant of the nerve agent sarin. We observe enhanced sensitivity when the GFET sensor is exposed to few mWs of UV light. Back gate measurements performed before and during exposures to the analyte allow us to investigate the sensing mechanism while monitoring the induced changes in carrier concentration and mobility in graphene.

Development of graphene-based field-effect transistor (GFET) sensors for a simulant of chemical warfare agents

Cosmology presupposes that on scales of $10^{8}$ light years the universe is the same at every point and in every direction. This is observationally supported by the cosmic microwave background (CMB) which has a temperature of 2.7 Kelvin in all directions. However, there exist small perturbations on this symmetric background - for example the CMB has perturbations of 0.001 Kelvin. A study of these fluctuations is cosmological perturbation theory. In this talk, I will review the standard theory of cosmological perturbations, explain our framework which is different from the standard method and then generalize our framework to include a matter clock.

Cosmological perturbation theory with matter time.

The solid polymer light-emitting electrochemical cell (PLEC) possesses a polymer homojunction that is reminiscent of a conventional p-n junction but also exhibits distinct features that are profoundly intriguing. The PLEC junction is formed under bias when the propagating p- and n-doping fronts in the semiconducting polymer make contact. The PLEC junction can be immobilized by cooling after the initial junction formation. Once the junction is fixed by cooling, the “frozen-junction” PLEC exhibits a unipolar electroluminescence (EL) and photovoltaic response. Further, the resulting frozen junction can be relaxed, or partially de-doped into a p-i-n junction by controlled manipulation of ion motion. The as-frozen p-n junction can be relaxed with repeated thermal cycles. More precisely, the de-doping was carried out in a single heating/cooling cycle during which a constant reverse bias (RB) current was applied to monitor the extent of de-doping and the magnitude of RB EL. It is on a frozen polymer p-i-n junction that the most puzzling electroluminescent phenomenon was observed. A model is developed that explains the reverse bias EL as caused by the tunnel injection of electrons and holes from bandgap states into a de-doped “intrinsic” region between the p- and n-doped regions. Moreover, the RB EL exhibits hypersensitivity to temperature when the de-doped cell was cooled. There is currently no explanation to this drastic EL enhancement by cooling. Several possible causes have been ruled out through a series of control experiments.
