Permanent micro-magnets are widely used in many devices such as MEMS and diverse biological applications. However, their fabrication typically includes several complex processing steps. MnBi is an intermetallic ferromagnetic alloy that possesses good permanent magnet properties such as a high Curie temperature of 711 K, a high magnetocrystalline anisotropy of 1.6 MJ/m&lt;sup&gt;3&lt;/sup&gt; at room temperature, a relatively high (BH)&lt;sub&gt;max&lt;/sub&gt; of around 20 MGOe and, remarkably, an unusual positive temperature coefficient of the coercivity [1,2], which makes MnBi an attractive rare earth-free alternative for high temperature applications.&lt;br/&gt;In this study, a one-step route has allowed for the fabrication of highly crystalline hexagonal MnBi micro-islands (lateral dimension of 30 µm and thickness of 0.2 – 2.1 µm), by RF-sputtering of a composite target onto glass substrates at different deposition temperatures (T&lt;sub&gt;D&lt;/sub&gt;) [3]. A strong impact of T&lt;sub&gt;D&lt;/sub&gt; on the magnetic properties has been proven. Specifically, magnetic anisotropy could be tuned from out-of-plane (T&lt;sub&gt;D&lt;/sub&gt; &amp;lt; 375 K) to in-plane (T&lt;sub&gt;D&lt;/sub&gt; = 475 K), remarkably, without applying any external magnetic field during the deposition.&lt;br/&gt;High values of coercivity have been obtained: 13.1 kOe at 400 K along the out-of-plane direction for the sample grown at 375 K and 14.1 kOe at 400 K along the in-plane direction for the sample grown at 475 K. The sample topography and the magnetic domain structure have been studied, observing a strong perpendicular anisotropy in micro-islands with a crater-like shape as shown in the scheme of Figure 1. It has been observed that the periodicity of stripe domains obeys the D = 1.18 * sqrt (T) law [4] in good agreement with theoretical predictions (data points and red line in Figure 1). We have validated the dependency of D &lt;i&gt;vs&lt;/i&gt; T in MnBi thin films previously reported in literature, which has been possible through the MFM study (Fig. 1) of the crater-like shape of our MnBi micro-islands [3]. Moreover, this study has allowed us to extend the dependency of D &lt;i&gt;vs&lt;/i&gt; T for MnBi in a thickness range well beyond previously published results.&lt;br/&gt;&lt;br/&gt;Acknowledgements&lt;br/&gt;IMDEA acknowledges financial support from the EU M-ERA.NET Network and MINECO through &quot;NEXMAG&quot; (Project Success Case at H2020 M-era.Net, Ref. PCIN-2015-126) and &quot;3D-MAGNETOH &quot;(Ref. MAT2017-89960-R); and from CM through &quot;NANOMAGCOST&quot; (Ref. P2018/NMT-4321).

**References:**

[1] K. Patel &lt;i&gt;et al.&lt;/i&gt;, Nanoscale 10, 11701 (2018)&lt;br/&gt;[2] E. Céspedes&lt;i&gt; et al.&lt;/i&gt;, J. Alloys Compd. 729, 1156 (2017); M. Villanueva &lt;i&gt;et al.&lt;/i&gt;, AIP Adv. 9, 035325 (2019)&lt;br/&gt;[3] M. Villanueva &lt;i&gt;et al.&lt;/i&gt;, Submitted for publication (2021)&lt;br/&gt;[4] C. Kittel, Physical Review 70, 11-12 (1946)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/65afd49c6f719bdfe8463c50b2dc14a0.jpg)
Figure 1. Dependence of domain width (D/2) on the thickness (T) of the MnBi micro-islands from MFM images (inset) measured at remanence after sample demagnetization. The D = 1.18 * sqrt (T) law is obtained by fitting the data points (red line).
