Here we present an X-ray, magnetometry, and electron microscopy study of novel 40 nm FeCr spinel oxide nanoparticles (NPs) containing ~4 nm FeO clusters occupying up to 20% of the volume. The unique structure provides a large effective interface area between the antiferromagnetic (AFM) FeO clusters and the ferrimagnetic (FiM) spinel structure, leading to one of the largest exchange bias (EB) observed in FeO-based NP systems.&lt;br/&gt;Nanoparticles composed of Wüstite FeO and Magnetite Fe&lt;sub&gt;3&lt;/sub&gt;O&lt;sub&gt;4&lt;/sub&gt; have been studied extensively and exhibit a wide range of magnetic properties [1-3]. Both oxides share the same fcc oxygen lattice and differ only in the occupancy and valence of the Fe cations in the tetrahedral (A) and octahedral (B) interstitial sites. Wüstite has a rock salt (RS) structure with Fe&lt;sup&gt;2+&lt;/sup&gt; occupying B-sites in the fcc O-lattice. In bulk, FeO is not stoichiometric and thermodynamically stable under ambient conditions, which results in a defect Fe&lt;sub&gt;x&lt;/sub&gt;O RS structure. The Fe&lt;sup&gt;2+&lt;/sup&gt; ions in the RS structure can diffuse and oxidize into Fe&lt;sup&gt;3+&lt;/sup&gt; at the surface, forming the inverse spinel structure of Magnetite, where Fe&lt;sup&gt;3+&lt;/sup&gt; occupies the A-lattice while the B-lattice is equally shared by the Fe&lt;sup&gt;2+&lt;/sup&gt; and Fe&lt;sup&gt;3+&lt;/sup&gt; cations. At the nanoscale, the transformation of Wüstite into Magnetite leads to Fe&lt;sub&gt;x&lt;/sub&gt;O/Fe&lt;sub&gt;3&lt;/sub&gt;O&lt;sub&gt;4&lt;/sub&gt; core/shell (CS) NPs where exchange coupling between the AFM core and the FiM shell leads to the emergence of EB [1-6], which manifests as a horizontal shift of the hysteresis and coercivity increase.&lt;br/&gt;Here, NPs with an average diameter of 40 nm are generated using an aerosol technique based on spark ablation [7-9] where the material is evaporated from stainless steel grade 430 electrodes containing 97.4% FeCr with a 4:1 ratio of Fe:Cr [9]. The evaporated material is transported where adiabatic expansion and mixing with the carrier gas cool down the vapor, which condensates into sub 10 nm primary particles that form larger agglomerates as they collide. The agglomerates are transported through a furnace where they are compacted at 1200 &lt;sup&gt;o&lt;/sup&gt;C before being size-selected and deposited onto a substrate using an electric field. The structural characterization was performed by high-resolution electron microscopy (HRTEM) and the compositional analysis was carried out with energy dispersive X-ray spectroscopy (EDXS) in scanning transmission electron microscopy (STEM) mode, see Figure 1 (a and b), along with X-ray photoelectron spectroscopy (XPS) performed at the Species beamline, MAX IV [10]. The NPs appear to have a single crystalline phase with a spinel oxide structure, and homogeneously distributed Fe and Cr within the NP with the expected Fe:Cr ratio of 4:1. However, X-ray diffraction (XRD) acquired at the 11-ID-B beamline of the Advanced Photon Source [11] reveals the co-existence of up to 20% RS crystallites with a size (~4 nm) about one order of magnitude smaller than the spinel phase (~40 nm). The significant volume fraction and the small size of the RS phase rule out a CS structure and point to Fe&lt;sub&gt;x&lt;/sub&gt;O RS clusters embedded in the spinel structure as schematically illustrated in Fig. 1 c). In stainless steel, Cr prevents the corrosion of metallic Fe by forming an oxide that blocks further diffusion and oxidation of Fe at the surface. We propose that Cr plays a similar role here, but now preventing the full transformation from Fe&lt;sub&gt;x&lt;/sub&gt;O → Fe&lt;sub&gt;3&lt;/sub&gt;O&lt;sub&gt;4&lt;/sub&gt;, both in the primary particles and during compaction.&lt;br/&gt;X-ray magnetic circular dichroism (XMCD) data, acquired at the X-treme beamline of the Swiss Light Source [12] shows the FM interaction between the Fe&lt;sup&gt;2+&lt;/sup&gt;/Fe&lt;sup&gt;3+&lt;/sup&gt; and Cr&lt;sup&gt;3+&lt;/sup&gt; ions in the B-lattice, and an AFM coupling to the Fe&lt;sup&gt;3+&lt;/sup&gt; ions in the A-lattice. Differences observed in XMCD spectra recorded at 2 K and 300 K at the Fe L&lt;sub&gt;3&lt;/sub&gt;-edge indicate an AFM to paramagnetic transition, further supporting the presence of Fe&lt;sub&gt;x&lt;/sub&gt;O in the NPs. Element and site specific m(H) curves were recorded and the differences between Fe and Cr will be discussed, along with a more precise determination of the individual ions’ magnetic contribution by means of multiplet simulations.&lt;br/&gt;Temperature-dependent magnetization measurements also indicate the presence of Fe&lt;sub&gt;x&lt;/sub&gt;O, where a rapid increase in magnetization is observed around the Neél temperature of FeO (T&lt;sub&gt;N&lt;/sub&gt; ~ 200 K - Fig.2 left-panel). The magnetic moment as a function of applied magnetic field at a temperature of 2 K after cooling in a field of 1 T is shown in the right-panel of Figure 2. As can be seen, the hysteresis is significantly shifted with respect to the field axis. The observed shift of µ&lt;sub&gt;0&lt;/sub&gt;H = 460 mT is among the highest values ever reported for Fe-oxide NPs, and significantly larger than the typical values for Fe&lt;sub&gt;x&lt;/sub&gt;O/Fe&lt;sub&gt;3&lt;/sub&gt;O&lt;sub&gt;4&lt;/sub&gt; NPs [13] (a record high of 860 mT was reported by Lottini &lt;i&gt;et al&lt;/i&gt; [14] after Co doping). Furthermore, a 38% increase in the coercivity at 2 K (580 mT) after cooling in a magnetic field is also observed. That the EB is the result of interactions with the AFM Fe&lt;sub&gt;x&lt;/sub&gt;O clusters is also corroborated by the temperature dependence of the H&lt;sub&gt;EB&lt;/sub&gt; which vanishes above the FeO T&lt;sub&gt;N&lt;/sub&gt;, immediately followed by a rapid coercivity decrease. The large EB is attributed to the unique structure in which the embedded AFM clusters have an increased effective AFM-FiM interface area compared to AFM/FiM core/shell structures.

**References:**

[1] Sun, Xiaolian, et al. &quot;Tuning exchange bias in core/shell FeO/Fe3O4 nanoparticles.&quot; Nano letters 12.1 (2012): 246-251.&lt;br/&gt;[2] Estrader, Marta, et al. &quot;Origin of the large dispersion of magnetic properties in nanostructured oxides: Fe x O/Fe 3 O 4 nanoparticles as a case study.&quot; Nanoscale 7.7 (2015): 3002-3015.&lt;br/&gt;[3] Wetterskog, Erik, et al. &quot;Anomalous magnetic properties of nanoparticles arising from defect structures: topotaxial oxidation of Fe1–x O| Fe3− δO4 core| shell nanocubes to single-phase particles.&quot; ACS nano 7.8 (2013): 7132-7144.&lt;br/&gt;[4] Iglesias, Oscar, Amilcar Labarta, and Xavier Batlle. &quot;Exchange bias phenomenology and models of core/shell nanoparticles.&quot; Journal of nanoscience and nanotechnology 8.6 (2008): 2761-2780.&lt;br/&gt;[5] Meiklejohn, William H., and Charles P. Bean. &quot;New magnetic anisotropy.&quot; Physical review 102.5 (1956): 1413.&lt;br/&gt;[6] Nogués, Josep, et al. &quot;Exchange bias in nanostructures.&quot; Physics reports 422.3 (2005): 65-117.&lt;br/&gt;[7] R. Hallberg, L. Ludvigsson, C. Preger, B. Meuller, K. Dick, and M. Messing, &quot;Hydrogen-assisted spark discharge generated metal nanoparticles to prevent oxide formation,&quot; Aerosol Science and Technology, vol. 52, no. 3, pp. 347-358, 2018.&lt;br/&gt;[8] B.O. Meuller, M.E. Messing, D.L.J. Engberg, et al. ”Review of spark discharge generators for production of nanoparticle aerosols” Aerosol Sci. Technol., 46, 1256, 2012.&lt;br/&gt;[9] C. Preger et al., &quot;Controlled Oxidation and Self-Passivation of Bimetallic Magnetic FeCr and FeMn Aerosol Nanoparticles&quot;, The Journal of Physical Chemistry C, vol. 123, no. 26, pp. 16083-16090, 2019.&lt;br/&gt;[10] S. Urpelainen, C. Såthe, W. Grizolli, M. Agåker, A. R. Head, M. Andersson, S.-W. Huang, B. N. Jensen, E. Wallén, H. Tarawneh, et al., &quot;The species beamline at the max iv laboratory: a facility for soft x-ray rixs and apxps&quot;, Journal of synchrotron radiation, vol. 24, no. 1, pp. 344-353, 2017.&lt;br/&gt;[11] U. Rütt, M. Beno, J. Strempfer, G. Jennings, C. Kurtz, and P. Montano, &quot;Diffractometer for high energy x-rays at the APS&quot;, Nuclear Instruments and Methods in Physics Research Section A: Accelerators, Spectrometers, Detectors and Associated Equipment, vol. 467, pp. 1026-1029, 2001.&lt;br/&gt;[12] C. Piamonteze, U. Flechsig, S. Rusponi, J. Dreiser, J. Heidler, M. Schmidt, R. Wetter, M. Calvi, T. Schmidt, H. Pruchova, et al., “X-treme beamline at sls: X-ray magnetic circular and linear dichroism at high field and low temperature&quot;, Journal of synchrotron radiation, vol. 19, no. 5, pp. 661-674, 2012.&lt;br/&gt;[13] Phan, Manh-Huong, et al. &quot;Exchange bias effects in iron oxide-based nanoparticle systems.&quot; Nanomaterials 6.11 (2016): 221.&lt;br/&gt;[14] Lottini, E., et al. &quot;Strongly exchange coupled core| shell nanoparticles with high magnetic anisotropy: a strategy toward rare-earth-free permanent magnets.&quot; Chemistry of Materials 28.12 (2016): 4214-4222.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/d2fd8d2c49ec21852eb227573753590a.jpg)
Fig 1. a) left: HRTEM image of a NP; right: FFT indicating spinel; b) EDXS showing Fe, Cr and O distribution; c) Schematic model of a spherical spinel NP containing cubic FeO clusters (brown).

![](https://assets.underline.io/uploads/markdown_image/1/image/04541974969216210d0c73ac8ae0bc2a.jpg)
Fig 2. Left: temperature susceptibility in a 10 mT field in ZFW and FCC cases; right: 1 T FC m(H) showing the horizontal hysteresis shift.

INTERMAG 2021

 Large Exchange Bias in FeCr Spinel Oxide Nanoparticles with Embedded FexO Clusters
