In this work, we revisit the L-BTBT GIDL in GAA nanowire FETs and propose design guidelines for amplifying the hole accumulation and floating body effects for realizing scalable 1T-DRAM with large sense margin, high retention and low write energy. The proposed NWFET based 1T-DRAM exploiting L-BTBT GIDL for write operation exhibits an ultra-low write energy of 7.3 fJ, high sense margin of 88.4 nA and a retention time of 0.1 ms even for an ultra-short gate length of 20 nm.

DRC 2022

Revisiting Gate-Induced Drain-Leakage in Nanowire FETs for 1T-DRAM

gate-induced drain leakage

nanowire fets

capacitorless dram

dram
