GdFeCo, a rare-earth/transition-metal composition, is a competitive candidate for practical applications on GMR devices [1,2], magneto-optical recording medium [3,4], and ultrafast magnetic switching [5,6]. Particularly, the ability to control magnetic coercivity (H&lt;sub&gt;c&lt;/sub&gt;) is one of the most important parameters for the advantage in magnetic data storage technologies. It is well known that the coercivity of the GdFeCo compound can be tuned by varying content of Gd or FeCo component [7]. Although these methods can effectively alter the magnetic properties of a sample, the changes are permanent, thus, one may expect a further increase in the flexible ability to manipulate H&lt;sub&gt;c&lt;/sub&gt; will be explored. Here, we reveal that the coercive field of GdFeCo adjacent to heavy metal Hf can be effectively modulated by electric current.&lt;br/&gt;The stack structure of Gd&lt;sub&gt;28.5&lt;/sub&gt;(Fe&lt;sub&gt;80&lt;/sub&gt;Co&lt;sub&gt;20&lt;/sub&gt;)&lt;sub&gt;71.5&lt;/sub&gt; (7nm)/Hf(4nm)/MgO(4nm), as illustrated in Fig.1(a), is prepared by means of a RF magnetron co-sputtering, and then characterized by the X-Ray Fluorescence (XRF) spectroscopy technique and the Alternating Gradient Magnetometer (AGM). A 5 μm-width and 100 μm-length Hall bar is fabricated using standard photolithography, E-beam lithography, and Ar ion-beam etching technique. We perform a measurement by injecting a DC current along the Hall channel in the presence of an external magnetic field which is swept perpendicularly to the sample plane, as illustrated in Fig.1(b).&lt;br/&gt;Interestingly, we observe that in the early stage of measurement, the H&lt;sub&gt;c &lt;/sub&gt;reduces drastically while at a higher current level coercivity is able to recover back to its initial value, as shown in Fig. 2. Such dependence of H&lt;sub&gt;c&lt;/sub&gt; on electric current can be explained by the competing interplay of the spin-orbit torque (SOT) that arises from heavy metal layer Hf and the Joule heating effects. This finding is a supplement for researchers and engineers who are working on spintronics materials

![](https://assets.underline.io/uploads/markdown_image/1/image/08b9c854f08b49452e0f1b365d6455ba.jpg)

(a) Schematic illustrations of stacked structure for thin films; (b) Optical microscopy image of the Hall bar device and the schematic of the experimental setup for the magneto-transport measurement.


![](https://assets.underline.io/uploads/markdown_image/1/image/693fba0be8e46cdfc523beab4832c892.jpg)

Hc variation as a function of input DC obtained from the anomalous hall effect (AHE) measurements.

2022 Joint MMM-INTERMAG

Manipulation of coercivity in GdFeCo/Hf heterostructures by an electrical current

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

INTERMAG 2021

GdFeCo, a rare-earth/transition-metal composition, is a competitive candidate for practical applications on GMR devices [1,2], magneto-optical recording medium [3,4], and ultrafast magnetic switching [5,6]. Particularly, the ability to control magnetic coercivity (Hc) is one of the most important parameters for the advantage in magnetic data storage technologies. It is well known that the coercivity of the GdFeCo compound can be tuned by varying content of Gd or FeCo component [7]. Although these methods can effectively alter the magnetic properties of a sample, the changes are permanent, thus, one may expect a further increase in the flexible ability to manipulate Hc will be explored. Here, we reveal that the coercive field of GdFeCo adjacent to heavy metal Hf can be effectively modulated by electric current. The stack structure of Gd28.5(Fe80Co20)71.5 (7nm)/Hf(4nm)/MgO(4nm), as illustrated in Fig.1(a), is prepared by means of a RF magnetron co-sputtering, and then characterized by the X-Ray Fluorescence (XRF) spectroscopy technique and the Alternating Gradient Magnetometer (AGM). A 5 μm-width and 100 μm-length Hall bar is fabricated using standard photolithography, E-beam lithography, and Ar ion-beam etching technique. We perform a measurement by injecting a DC current along the Hall channel in the presence of an external magnetic field which is swept perpendicularly to the sample plane, as illustrated in Fig.1(b). Interestingly, we observe that in the early stage of measurement, the Hc reduces drastically while at a higher current level coercivity is able to recover back to its initial value, as shown in Fig. 2. Such dependence of Hc on electric current can be explained by the competing interplay of the spin-orbit torque (SOT) that arises from heavy metal layer Hf and the Joule heating effects. This finding is a supplement for researchers and engineers who are working on spintronics materials

![](https://assets.underline.io/uploads/markdown_image/1/image/08b9c854f08b49452e0f1b365d6455ba.jpg)

(a) Schematic illustrations of stacked structure for thin films; (b) Optical microscopy image of the Hall bar device and the schematic of the experimental setup for the magneto-transport measurement.


![](https://assets.underline.io/uploads/markdown_image/1/image/693fba0be8e46cdfc523beab4832c892.jpg)

Hc variation as a function of input DC obtained from the anomalous hall effect (AHE) measurements.
