In recent years, magnetic refrigeration (MR) has gained much attention, rather than conventional gas refrigeration, being an energy efficient and eco-friendly technology. For that purpose, the current research for exploring potential magnetocaloric material is focused on the material exhibiting first-order magnetostructural transition (MST) along with large change in magnetization and hence large magnetocaloric effect (MCE) [1]–[3]. Recently, Ni-Co-Mn-Ti-based all d-metal Heusler alloy is found to be an excellent candidate for magnetic refrigeration which exhibits multicaloric properties such as MCE [4], elastocaloric effect [5], and giant barocaloric effect [6].&lt;br/&gt;In the present work, we explore the effect of Sn doping at Ti-site and also heat treatment condition on MCE properties of Ni&lt;sub&gt;35&lt;/sub&gt;Co&lt;sub&gt;15&lt;/sub&gt;Mn&lt;sub&gt;37&lt;/sub&gt;Ti&lt;sub&gt;13-&lt;i&gt;x&lt;/i&gt;&lt;/sub&gt;Sn&lt;i&gt;&lt;sub&gt;x&lt;/sub&gt;&lt;/i&gt; (x = 0,1 and 2) alloys through thermal and magnetic measurements. The observed MST temperature (&lt;i&gt;T&lt;sub&gt;M&lt;/sub&gt;&lt;/i&gt;) shifts toward lower temperature with Sn doping whereas, the sharpness of the transition enhances with annealing time which effectively increases the MCE response as shown in fig.1 (a)). The sample with &lt;i&gt;x&lt;/i&gt; = 1 exhibits a plateau-like magnetic entropy change (ΔS&lt;sub&gt;M&lt;/sub&gt;) with a maximum peak value of ΔS&lt;sub&gt;M &lt;/sub&gt;~ 5.7 Jkg&lt;sup&gt;-1&lt;/sup&gt;K&lt;sup&gt;-1&lt;/sup&gt; due to a magnetic field change of 50 kOe. It is interesting to note that ΔS&lt;sub&gt;M&lt;/sub&gt; value remains almost the same with value ~ 4 Jkg&lt;sup&gt;-1&lt;/sup&gt;K&lt;sup&gt;-1&lt;/sup&gt; for a temperature region of 300 K-350 K shown in fig.1 (b). Large ΔS&lt;sub&gt;M&lt;/sub&gt; in a wide temperature interval is attributed to the existence of inter-martensite transition along with MST. The large ΔS&lt;sub&gt;M &lt;/sub&gt;value with wide tunable operating temperature region in the vicinity of room temperature and the estimated large relative cooling power (RCP) of ~ 384 J/kg enable the material a suitable candidate for solid-state MR technology.

![](https://assets.underline.io/uploads/markdown_image/1/image/0742db6c7fcbb9ed5a3e2fcb08c45c88.jpg)

Figure 1: (a) Magnetization vs. T for x = 1 and 2alloys under different annealing temperatures. Inset shows DSC heat-flow vs. T with a ramp rate of 10 K/m of x = 1 sample.

![](https://assets.underline.io/uploads/markdown_image/1/image/2d9c91f1787e1efc24138fdba6d61ecd.jpg)

Figure 1: (b) ΔSM vs. T at different magnetic field for x = 1 alloy.



2022 Joint MMM-INTERMAG

Large plateau-like Magnetic entropy change in Sn doped Ni-Co-Mn-Ti all d metal Heusler alloy

The 15th Joint MMM-INTERMAG Conference (2022 Joint) is sponsored jointly by AIP Publishing and the IEEE Magnetics Society. Members of the international scientific and engineering communities interested in recent developments in fundamental and applied magnetism are invited to attend and contribute to the technical sessions. The technical program will include invited and contributed papers in oral and poster sessions, invited symposia, a plenary session, and an evening session, with about 1500 presentations overall. This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

The 2022 Joint Conference will offer both in-person and prerecorded on-demand content.

For tickets to the event, please register at the following link: https://magnetism.org/register

Please register for the Joint MMM-Intermag conference to join the event.

This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

In recent years, magnetic refrigeration (MR) has gained much attention, rather than conventional gas refrigeration, being an energy efficient and eco-friendly technology. For that purpose, the current research for exploring potential magnetocaloric material is focused on the material exhibiting first-order magnetostructural transition (MST) along with large change in magnetization and hence large magnetocaloric effect (MCE) [1]–[3]. Recently, Ni-Co-Mn-Ti-based all d-metal Heusler alloy is found to be an excellent candidate for magnetic refrigeration which exhibits multicaloric properties such as MCE [4], elastocaloric effect [5], and giant barocaloric effect [6]. In the present work, we explore the effect of Sn doping at Ti-site and also heat treatment condition on MCE properties of Ni35Co15Mn37Ti13-xSnx (x = 0,1 and 2) alloys through thermal and magnetic measurements. The observed MST temperature (TM) shifts toward lower temperature with Sn doping whereas, the sharpness of the transition enhances with annealing time which effectively increases the MCE response as shown in fig.1 (a)). The sample with x = 1 exhibits a plateau-like magnetic entropy change (ΔSM) with a maximum peak value of ΔSM ~ 5.7 Jkg-1K-1 due to a magnetic field change of 50 kOe. It is interesting to note that ΔSM value remains almost the same with value ~ 4 Jkg-1K-1 for a temperature region of 300 K-350 K shown in fig.1 (b). Large ΔSM in a wide temperature interval is attributed to the existence of inter-martensite transition along with MST. The large ΔSM value with wide tunable operating temperature region in the vicinity of room temperature and the estimated large relative cooling power (RCP) of ~ 384 J/kg enable the material a suitable candidate for solid-state MR technology.

![](https://assets.underline.io/uploads/markdown_image/1/image/0742db6c7fcbb9ed5a3e2fcb08c45c88.jpg)

Figure 1: (a) Magnetization vs. T for x = 1 and 2alloys under different annealing temperatures. Inset shows DSC heat-flow vs. T with a ramp rate of 10 K/m of x = 1 sample.

![](https://assets.underline.io/uploads/markdown_image/1/image/2d9c91f1787e1efc24138fdba6d61ecd.jpg)

Figure 1: (b) ΔSM vs. T at different magnetic field for x = 1 alloy.

poster

As the number of biomedical applications of superparamagnetic iron-oxide nanoparticles (SPION) grows, having a detailed understanding of their magnetic state is increasingly important. It is commonly assumed that dipole-dipole interactions are not relevant for superparamagnetic nanoparticles because of thermal fluctuations. Here we show evidence that dipole-dipole interactions do indeed affect the collective magnetic state of a SPION sample. Ferromagnetic resonance spectroscopy of iron-oxide nanoparticles with a diameter of 10 nm reveals that the configuration of the particles has a strong effect on their effective magnetic anisotropy on short time scales. Fitting the experimental spectra using a theoretical model [1] enables the quantification of these anisotropy fields. Nanoparticles in suspension with a surfactant exhibit an easy-axis anisotropy due to field-induced alignment, whereas condensed dry nanoparticles (which no longer have the surfactant) exhibit an easy-plane anisotropy due to agglomeration. The difference between the effective uniaxial anisotropies in suspension versus the dry state is on the order of 0.1 T. The effective uniaxial anisotropies exhibited by the nanoparticles in these configurations are an order of magnitude larger than the intrinsic magneto-crystalline anisotropy. This suggests that dipole-dipole interactions can be important to the collective magnetic state of superparamagnetic systems despite thermal fluctuations and should be considered for high-frequency applications.

Ferromagnetic resonance of superparamagnetic iron-oxide nanoparticles: quantification of dipole-dipole interactions

The Ga2-xFexO3 (GFxO) compound, is a quite interesting material due to simultaneous exhibit magnetic and electric orderings [1,2]. However, the physical properties of GFxO at reduced grain sizes remain underexplored due to the challenges associated with their synthesis with a proper control over the crystalline phase. In addition, the effect of the Fe/Ga ratio on the magnetic properties of the nanosized GFxO system has not yet been completely established. In this work, therefore, we prepare a series of GFxO nanoparticles with 0.8 ≤ x ≤ 1.2 using the sol-gel method to systematically study the effect of the Fe/Ga ratio on their structural and magnetic properties. All the samples of GFxO with 0.8 ≤ x ≤ 1.2 have been characterized by the powder XRD measurements and Rietveld refinements. All the observed peaks can be indexed by reflections of the Pc21n orthorhombic structure of GFxO, and no impurity phase was found. The determined lattice parameters are found to display a monotonic increase with the Fe content x. Composition of the GFxO nanoparticles was confirmed by energy dispersive X-ray spectra. The evolution of the Néel temperature (TN) of GFxO samples versus their Fe-content (x). It is found that with increasing Fe-content, up to 1.2, the TN increases from 279 to 350 K. Moreover, the magnetic hysteresis curves measured below TN exhibit two-phase-like magnetic behavior consisting of soft and hard magnetic phases. The results could be explained by the site-disorder of the cations in GFxO nanoparticles.

Compositional dependence of magnetic properties of multiferroic Ga2-xFexO3 nanoparticles

The exchange bias (EB) phenomenon, generally quantified by the shift of the hysteresis loop along the magnetic field axis, has been observed in several Mn-rich Heusler alloys [1, 2, 3]. The fundamental science that drives EB and its technological impact are both of great interest [4, 5]. The EB effect in Mn-rich Heusler alloys is primarily related to the coexisting ferromagnetic (FM) and antiferromagnetic (AFM) interactions. Interestingly, the Mn atoms are responsible for both the FM and AFM interactions in these materials. In the Heusler alloy Mn(2)NiGa, both FM and AFM interactions are present. However, the material does not exhibit any EB effect. Interestingly, a strong EB was observed in Ga-deficient/Ni-rich Mn(2)Ni(1.4)Ga(0.6), which demonstrated the importance of crystalline site occupancies of the Mn atoms in driving EB [6]. Here, we have performed an experimental study on the effect of Fe doping on the magnetic and EB properties of Mn(2-x)Fe(x)Ni(1.6)Ga(0.4) (0 ≤ x ≤ 0.35). The goal of the study was to explore the effect of Fe doping on the FM and AFM interactions in the system. The samples were fabricated by arc melting, drop-casting, and annealing techniques. X-ray diffraction measurements and the scanning electron microscopy images showed that the alloys were phase segregated with two different lower symmetry structures. For all values of x, EB was observed in the materials. An EB field of as large as ~4000 Oe and a coercive field of ~14 kOe were observed in the materials. The structural, magnetic, and EB properties of all the alloys in the Mn(2.x)Fe(x)Ni(1.6)Ga(0.4) system will be presented.

The Magnetic and Exchange Bias Properties of Phase Segregated Mn2-xFexNi1.6Ga0.4

Self-Assembled Magnetic Nanoparticle (MNP) structures have a wide range of applications in industry, chemistry, and medicine[1]. It has been shown through experiments and computational simulation that various patterns of MNPs can be deposited on a substrate [2,3]. One mechanism for self-assembly is the gradient of an applied field exerting a force on the MNPs. For example, a single perpendicular transition of magnetization (from up alignment to down) in a computer hard drive can produce a gradient sufficient to promote a single line with a width of multiple MNPs assembling on the substrate. Therefore, the chosen magnetic structure of the substrate is a determining factor in creating the desired end structure. While simulations have been performed to understand this assembly, they lack key features found in experimental systems. This work builds upon existing computational models [3] by including small reversed regions in the magnetization, multiple transition regions in the simulated area, and changes to the total magnetic field created by the addition of a soft underlayer found in hard disk drives, as seen in Fig. 1. Along with new geometry, we also investigate the effect of varying the transition separation (distance d in Fig. 1) on the final structure. Our simulations investigate the trajectories of 27 nm diameter magnetite nanoparticles using a model based on Langevin dynamics including translation and rotation. The simulation results match those found experimentally both qualitatively and also in quantitative measures of the hexagonal ordering of assembled MNPs.

![](https://assets.underline.io/uploads/markdown_image/1/image/c5671c00cf66a50726252709d063f817.jpg)

Fig. 1. The magnetic profile of the hard and soft layers of the hard drive. With constants t1, t2, a, and d being the hard layer thickness, soft layer thickness, width of reversed magnetization, and separation of regions respectively. Above the substrate is the deposited nanoparticle structure found through simulation results using this geometry.

![](https://assets.underline.io/uploads/markdown_image/1/image/1d865be38544da32adc5e3193282044a.jpg)

Fig. 2. Scanning Electron Microscope image of magnetic nanoparticles assembled on substrate with spacing of 500 nm between the center of the reversed magnetized regions.

Self-Assembled Magnetite Nanoparticles above a hard drive: the effect of the Soft Underlayer and Changing the Separation of Reversed Magnetic Regions

Pt/Co/Ir-based synthetic antiferromagnets (SAFs) are key building blocks in high performance magnetic memory devices due to their large perpendicular magnetic anisotropy (PMA) and interlayer exchange coupling (IEC) energies, respectively, and tolerance to thermal processing [1-2]. Fortuitously, the IEC field and PMA field both can be enhanced significantly via judicious tuning of the Ir thickness [3]. Further gains in IEC and PMA may be required in emerging memory devices. And while the materials system may appear to be well optimized, additional refinement could be realized through the exploration of alternative processing approaches. In particular, the replacement of Argon with a heavier gas during sputtering (e.g. Krypton) is known to enhance the PMA of Co/Pt multilayers due to reduced bombardment of the growing film from gas species during deposition, reduced intermixing of layers and improved columnar film growth, overall enhancing the PMA [4]. To the best of our knowledge, this remains an unexplored approach for SAFs in general, and particularly not for the Pt/Co/Ir system. We investigated the role of sputter gas in the properties of a SAF structure grown by DC magnetron sputtering in an ultrahigh vacuum chamber (base pressure &lt; 10-7 Pa) on a thermally oxidized Si wafer with the following film stacking structure (thicknesses in parentheses in nm): Ta(5)/Pt(5)/[Co(0.4)/Pt(0.6)]x5 /Co(0.4)/Ir(t Ir )/[Co(0.4)/Pt(0.6)]x3 /Ru(2)/Ta(3). We varied the Ir spacer thickness between 0.3 nm and 0.7 nm to cover the first IEC peak around 0.5 nm. The sample sputtered in an 6 mTorr Kr environment exhibited a peak IEC field of 1.7 T, exceeding its Ar counterpart by over 35% (see Figure 1). This same thickness is also associated with the largest PMA (µ0HK = 5.4 T), which exceeded the Ar-sputtered counterpart by over 30% (see Figure 2). A 400°C post-annealing treatment in vacuum (&lt; 4 x 10-6 Pa) only causes a moderate reduction in the IEC field to 1.5 T. These results suggest that using Krypton as the sputtering gas could lead to superior performing SAFs for emerging memory devices.

![](https://assets.underline.io/uploads/markdown_image/1/image/3890c9e476423eca20805db63c667207.jpg)

Out-of-plane magnetic hysteresis curves for Pt/Co/Ir SAF sputtered in 6 mTorr (a) Ar or (b) Kr

![](https://assets.underline.io/uploads/markdown_image/1/image/6b14d60039618d0b815c660023e772ea.jpg)

In-plane magnetic hysteresis loops for Pt/Co/Ir SAF

Perpendicular Magnetic Anisotropy, Interlayer Exchange Coupling and Annealing Stability in Krypton-sputtered Pt/Co/Ir Synthetic Antiferromagnets

Transition-metal oxide (TMO) based heterostructures are the fertile playground to explore or functionalize novel quantum states. In this regard, the combination of 3d and 5d TMOs have gained special interest because of the strong competition between strong spin-orbit coupling and electron correlation at the interface of those heterostructures. Additionally, the inversion symmetry breaking may result in a distinct interfacial Dzyaloshinskii-Moriya interaction (DMI) and the formation of non-collinear magnetic texture in case of magnetic TMOs. Among the 5d TMOs, SrIrO3 (SIO) has gained significant attention in recent years. It displays large spin-orbit coupling and the semi-metallic ground state is highly susceptible to structural distortions. In this study, we have grown crystalline trilayer structures consisting of SIO and a 3d ferromagnetic insulator (FMI), i. e., (SIO/FMI/SIO or FMI/SIO/FMI). In-situ observation of RHEED oscillations and x-ray diffraction indicate layer-by-layer epitaxial growth. We will report in detail on the electronic transport and magnetic properties of the these heterostructures.

Magnetotransport of SrIrO3 based symmetric heterostructure

In this work we study the influence of interface parameters on the perpendicular magnetic anisotropy (PMA) and the interfacial Dzyaloshinskii-Moriya interaction (DMI) of Pd(111)/Co/CoO/Pd thin epitaxial films with different oxidation depths. Epitaxial Si(111)/Cu(2 nm)/Pd(2 nm)/Co(1 nm) films were grown by molecular beam epitaxy in ultrahigh vacuum chamber. After deposition of ferromagnetic layer, films were exposed the procedure of artificial oxidation with dry oxygen. We varied the oxide thickness and this way we changed the remanent ferromagnetic thickness. Determination of the thickness of the magnetic layers carried out by measuring the saturation magnetic moment with vibrating samples magnetometry. We also used SQUID-magnetometer for low-temperature measurements. Magnetic structure was investigated by a magneto-optical Kerr effect (MOKE) microscope which was equipped with a hand-made coil applying out-of-plane magnetic fields and an in-plane electromagnet. Significant elastic strains appear on Pd/Co interface lead to induce strong perpendicular magnetic anisotropy [1]. Artificial oxidation of magnetic layer leads to symmetry breaking on the bottom and top magnetic interfaces in epitaxial films, which reduces compensation of interfacial DMI. It should be noted that including of oxide layer is eliminate the asymmetrical contribution of chiral dumping in comparing with symmetrical Pd/Co/Pd [2] structures, it following from symmetrical parabolic shape of domain walls velocity curves as shown on figure 1(a) and allow determine the DMI field by minimal velocity field Hmin[3]. Moreover, Pd/Co/CoO thin films demonstrate strong exchange bias in out-of-plane magnetic field at a low temperature, as shown on figure 1(b). The reported study was partially funded by Council for Grants of the President of the Russian Federation (project - MK-1384.2021.1.2), the Russian Ministry of Science and Higher Education (the state task 0657-2020-0013) and grant of the Government of the Russian Federation (Project Proposal No.2020-220-08-4899) .

![](https://assets.underline.io/uploads/markdown_image/1/image/065806aae110d0b3e47020289f3a6c9f.jpg)

Dzyaloshinskii-Moriya Interaction and exchange bias in epitaxial Pd/Co/CoO films

Dzyaloshinskii-Moriya Interaction and exchange bias in epitaxial Pd/Co/CoO films

The formation of hybrid ferromagnetic/molecule heterostructures can lead to strong modifications of the magnetic properties of the ferromagnetic layer[1]. Such modifications, like magnetic anisotropy easy axis reorientation[2, 3] and magnetic hardening[4] are linked to the hybridization at the interface between the molecules p-orbitals and the ferromagnetic surface d-orbitals[1][2]. Here we report a novel finding: an interface dependent of NMR spectra of 7 nm polycrystalline Co thin films capped with two different organic molecules, Fullerene C60 and Gallium-quinoline Gaq3. Cobalt layers are grown simultaneously on two Al2O3(0001) substrates at RT and UHV by e-beam evaporation. The molecular layers are then grown without breaking the vacuum, by thermal evaporation at similar conditions. The molecular layer thickness is 25 nm, in order to guarantee a uniform coverage of the metallic surface. Cobalt surface characterization is performed by ex-situ AFM on a bare 7nm Co ultra-thin film (Fig. 1), showing a uniform, atomically flat and granular surface (RMS of (0.3 ± 0.1) nm). Ex-situ AFM characterization of the molecular layers shows a complete coverage, and RMS less than 1nm. NMR characterization is performed at T=77°K in zero external applied field. 59Co spectra where taken in the frequency range 190-235 MHz. For each sample, different spectra were acquired with different transmitted RF power, in order to obtain the enhancement factor [5]. We obtain an enhancement factor ratio of 2 between the Co/Gaq3 and the Co/C60 systems. This is in agreement with L-MOKE characterization at T= 77°K, showing that the Co/Gaq3 system is magnetically harder than the Co/C60. The corrected NMR spectra, (Fig. 2), show the presence of both FCC and HCP phases. Remarkably, their spectral weights is different for the two samples, depending on the molecular species deposited over the Cobalt surface. These results can be explained as due to an interface-induced modification of the hyperfine field felt by the 59Co nuclei, implying a profound impact of the interface on the magnetic properties of a significant portion of the ferromagnetic structure.

![](https://assets.underline.io/uploads/markdown_image/1/image/c869a8e80820732a32b196f9bff82f4d.jpg)

Fig.1 AFM image of 7 nm Co on Al2O3(0001).

![](https://assets.underline.io/uploads/markdown_image/1/image/3d5728d48b592cd7c66676f9a176ec72.jpg)

Fig.2 NMR spectra of Co(7nm)/C60 and Co(7nm)/Gaq3.

Interface dependence of NMR spectra of 59Co with different molecular overlayers

Modification and control of magnetic anisotropy is crucial for the development of new permanent magnet materials, high density information storage, and many advanced spintronic applications. Enhanced anisotropy is often achieved via shape modification, stabilization of non-cubic crystal structures, or proximity effects such as exchange bias. An unusual proximity effect occurs at the interfaces of thin Co films adjacent to π-conjugated C60 fullerene films where initial field hysteresis loops exhibit a substantial asymmetry and considerable broadening at reduced temperatures [1]. We investigate these effects with temperature-dependent broadband ferromagnetic resonance (FMR). A key question in these studies is whether the C60-derived anisotropy affects the dynamical properties of the Co / C60 system including resonant fields, damping, and spectroscopic g-factors. We examine the magnetometry and FMR response of a Co [12 nm] / C60 [35 nm] / Nb [16 nm] sample as a function of temperature and field history. Conventional field hysteresis loops identify two main effects: the asymmetry is present only for the initial loop and the enhanced coercive field increases monotonically for temperatures below 200 K. Temperature-dependent FMR from 4 – 35 GHz confirm these observations. The effective magnetization (μ0Meff) tracks the increased anisotropy of the Co / C60 upon cooling, but following field cycling μ0Meff is reduced. The difference (Δμ0Meff) is as large as 26 mT at 10 K and Δμ0Meff drops to zero above 200 K. These effects are not observed in control samples with a Cu spacer layer inserted between the Co and C60 layers. Gilbert-type damping is slightly increased in the Co / C60 system at all temperatures, however, the enhanced anisotropy prior to field cycling has little effect on damping.

Anisotropy Enhancement in Co / C60 Fullerene Bi-Layers Determined by Ferromagnetic Resonance

The interest in the magnetic cooling devices has led to an intensive search for suitable well-performing magnetocaloric materials over the last 25 years. However, to this date only a few material systems have been found to be suitable for commercial applications. Computational screening makes possible sieving through thousands of known compounds without the need to perform time-consuming measurements and therefore can play an important role in detecting novel magnetocaloric materials. To identify such systems of interest we selected several screening parameters using properties of various well-known MCE materials as a reference. Along with magnetic properties, other factors important for practical applications were taken into consideration including price, availability, and toxicity of candidate materials. Combining these criteria, we implemented an algorithm for the screening process as a set of automated computational tools. It relies on information readily available in the structural databases to perform detailed modelling via ab-initio calculations. Two computational databases (Aflowlib and Materials Project) and two experimental databases (COD and ICSD) are used as initial source of information totaling to 800k candidate compositions. As a main metric to predict the magnetocaloric performance we use the magneto-elastic response of the candidate. This is done by computing magnetic moment of the material across a range of deformations, both volumetric and uniaxial. This parameter shows good correlation with ΔSM measured in known magnetocaloric materials. A step-by-step application of initial screening parameters to sort out unsuitable materials before performing more computationally heavy assessments allows us to quickly process large number of candidates. This resulted in a shortlist of promising compounds to serve as a guide for experimental research. The flexibility of the computational toolset makes it possible to easily build in additional screening parameters to further adjust or refine the search process.

Large plateau-like Magnetic entropy change in Sn doped Ni-Co-Mn-Ti all d metal Heusler alloy
