Recently, SmFe&lt;sub&gt;11&lt;/sub&gt;Ti-based compounds with the ThMn&lt;sub&gt;12&lt;/sub&gt; crystal structure have been widely studied as a candidate for new permanent magnets due to their excellent intrinsic magnetic properties. Although those compounds have a high anisotropy field (12 T), the actual coercivity is less than 10% of their anisotropy field &lt;sup&gt;1&lt;/sup&gt;. In general, it is well known that fine precipitates corresponding to the size of the domain wall (several nm to several tens of nm) increase the coercivity of hard magnetic materials by acting as the domain wall pinning site. The addition of C to the SmFe&lt;sub&gt;11&lt;/sub&gt;Ti alloy may result in TiC precipitates in the matrix, and subsequent changes in the coercivity can be expected. In this study, SmFe&lt;sub&gt;11&lt;/sub&gt;Ti alloys containing different amount of C atoms were fabricated by the melt-spinning method to investigate the effects of C atoms on the microstructures and magnetic properties.&lt;br/&gt;SmFe&lt;sub&gt;11&lt;/sub&gt;Ti&lt;sub&gt;1+x&lt;/sub&gt;C&lt;sub&gt;x&lt;/sub&gt; (x = 0, 0.05, 0.1, 0.2) alloys with the ThMn&lt;sub&gt;12&lt;/sub&gt; crystal structure was successfully fabricated by the melt-spinning method and subsequent heat treatment. The optimum heat treatment condition was found to be 850°C for 15 minutes, and the coercivity was shown to be about 6.2 kOe regardless of the C content (Fig. 1). In order to understand these results, the microstructural analysis was performed. It was found that the matrix had the ThMn&lt;sub&gt;12&lt;/sub&gt; crystal structure and the average grain size was about 30 nm in all samples regardless of the C content (Fig. 2). In these samples, coarse TiC grains (&amp;gt;100 nm) instead of TiC nano-precipitates were formed independently from the matrix. This result explains the reason why the coercivity did not change. Thus, the experimental conditions for obtaining the precipitates are under investigation.


![](https://assets.underline.io/uploads/markdown_image/1/image/75746d30b79db84128662e894a5853fe.jpg)


Fig. 1 Coercivity measured at 2.5 T of SmFe11Ti1+xCx (x = 0, 0.5, 0.1, 0.2) alloys heat treated at 850°C for 15 minutes.


![](https://assets.underline.io/uploads/markdown_image/1/image/4b02a146f9f1f24e4dc7ba739af1ff8b.png)

Fig. 2 Microstructures of SmFe11Ti1.2C0.2 sample heat treated at 850°C for 15 minutes. (a)Bright field image using Transmission Electron Microscopy. (b)Dark field image and corresponding EDS mapping image using Scanning Transmission Electron Microscopy. The grains which was shown in dark contrast on the image was region that Ti and C was concentrated.
