Properties of higher-order magnetic anisotropy constants in soft-hard nanocomposite materials still attract much debate [1]. We investigated the magnetic anisotropy in a L1&lt;sub&gt;0&lt;/sub&gt;/A1 FePt system using the VAMPIRE software package [2]. An elongated, faceted cylindrical core-shell was constructed with a L1&lt;sub&gt;0&lt;/sub&gt;-FePt core of varied size surrounded by an A1-FePt shell. The system exchange interaction was 3-dimensional and accounted up to the third-nearest neighbours. A 2-ion Fe-Pt anisotropy component was incorporated to the system Hamiltonian following Mryasov et al. [3]. The angular dependence of the restoring torque was calculated from 0K to 1000K in 5K steps using a constrained Monte-Carlo integrator. Temperature-dependent anisotropy constants were then determined from fitting to the system torque as a function of the constrained angle.&lt;br/&gt;&lt;br/&gt;We find that the core-shell structure exhibits an unexpected 4&lt;sup&gt;th&lt;/sup&gt;-order anisotropy term of which magnitude depends on the core-size ratio R. The K&lt;sub&gt;2&lt;/sub&gt;/K&lt;sub&gt;1&lt;/sub&gt; ratio, with K&lt;sub&gt;1 &lt;/sub&gt;and K&lt;sub&gt;2 &lt;/sub&gt;being the 2&lt;sup&gt;nd&lt;/sup&gt; and 4&lt;sup&gt;th&lt;/sup&gt;-order anisotropy constant respectively, displays a non-monotonic pattern with a peak occurring at R ~ 0.55 &lt;i&gt;[Fig.1]&lt;/i&gt;. We find that K&lt;sub&gt;2&lt;/sub&gt; scales with (M/M&lt;sub&gt;s&lt;/sub&gt;)&lt;sup&gt;~2&lt;/sup&gt; at temperatures below T&lt;sub&gt;c &lt;/sub&gt;&lt;i&gt;[Fig.2]&lt;/i&gt; - a remarkable deviation from the established Callen-Callen theory [4] which instead predicts a scaling with (M/M&lt;sub&gt;s&lt;/sub&gt;)&lt;sup&gt;10&lt;/sup&gt;. A simple analytical model shows the 4&lt;sup&gt;th&lt;/sup&gt;-order term to arise from canting of the core and shell magnetisation. Further, the model demonstrates that the magnitude of the 4&lt;sup&gt;th&lt;/sup&gt;-order term is proportional to K&lt;sub&gt;1&lt;/sub&gt;&lt;sup&gt;2&lt;/sup&gt;/J, with J the exchange coupling. Given that the 2-ion K&lt;sub&gt;1&lt;/sub&gt; term scales approximately with M&lt;sup&gt;2&lt;/sup&gt; and J with M&lt;sup&gt;2&lt;/sup&gt;, the predicted scaling exponent is 2 in agreement with the simulations. Generally, the 4&lt;sup&gt;th&lt;/sup&gt;-order anisotropy constant is shown to exhibit a strong dependence on the system geometry, thus suggesting that the Callen-Callen power law is not universal and valid only for single-ion anisotropies.

![](https://assets.underline.io/uploads/markdown_image/1/image/22a9ca96de68d358f16ce046a83fffba.jpg)

Fig.1: A low temperature scan displays a non-monotonic dependence of K2/K1 on core size ratio R with a peak at R ~ 0.55.

![](https://assets.underline.io/uploads/markdown_image/1/image/bb578e32eb2732e857794fddce38fa58.jpg)

Fig.2: K2 scaling with M/Ms for R=0.50 results in a scaling exponent β ~ 1.81 not 10 as predicted by Callen-Callen.

2022 Joint MMM-INTERMAG

Higher-order magnetic anisotropy in soft-hard nanocomposite materials

The 15th Joint MMM-INTERMAG Conference (2022 Joint) is sponsored jointly by AIP Publishing and the IEEE Magnetics Society. Members of the international scientific and engineering communities interested in recent developments in fundamental and applied magnetism are invited to attend and contribute to the technical sessions. The technical program will include invited and contributed papers in oral and poster sessions, invited symposia, a plenary session, and an evening session, with about 1500 presentations overall. This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

The 2022 Joint Conference will offer both in-person and prerecorded on-demand content.

For tickets to the event, please register at the following link: https://magnetism.org/register

Please register for the Joint MMM-Intermag conference to join the event.

This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

Properties of higher-order magnetic anisotropy constants in soft-hard nanocomposite materials still attract much debate [1]. We investigated the magnetic anisotropy in a L10/A1 FePt system using the VAMPIRE software package [2]. An elongated, faceted cylindrical core-shell was constructed with a L10-FePt core of varied size surrounded by an A1-FePt shell. The system exchange interaction was 3-dimensional and accounted up to the third-nearest neighbours. A 2-ion Fe-Pt anisotropy component was incorporated to the system Hamiltonian following Mryasov et al. [3]. The angular dependence of the restoring torque was calculated from 0K to 1000K in 5K steps using a constrained Monte-Carlo integrator. Temperature-dependent anisotropy constants were then determined from fitting to the system torque as a function of the constrained angle. We find that the core-shell structure exhibits an unexpected 4th-order anisotropy term of which magnitude depends on the core-size ratio R. The K2/K1 ratio, with K1 and K2 being the 2nd and 4th-order anisotropy constant respectively, displays a non-monotonic pattern with a peak occurring at R ~ 0.55 [Fig.1]. We find that K2 scales with (M/Ms)~2 at temperatures below Tc [Fig.2] - a remarkable deviation from the established Callen-Callen theory [4] which instead predicts a scaling with (M/Ms)10. A simple analytical model shows the 4th-order term to arise from canting of the core and shell magnetisation. Further, the model demonstrates that the magnitude of the 4th-order term is proportional to K12/J, with J the exchange coupling. Given that the 2-ion K1 term scales approximately with M2 and J with M2, the predicted scaling exponent is 2 in agreement with the simulations. Generally, the 4th-order anisotropy constant is shown to exhibit a strong dependence on the system geometry, thus suggesting that the Callen-Callen power law is not universal and valid only for single-ion anisotropies.

![](https://assets.underline.io/uploads/markdown_image/1/image/22a9ca96de68d358f16ce046a83fffba.jpg)

Fig.1: A low temperature scan displays a non-monotonic dependence of K2/K1 on core size ratio R with a peak at R ~ 0.55.

![](https://assets.underline.io/uploads/markdown_image/1/image/bb578e32eb2732e857794fddce38fa58.jpg)

Fig.2: K2 scaling with M/Ms for R=0.50 results in a scaling exponent β ~ 1.81 not 10 as predicted by Callen-Callen.
