BiSb topological insulator is a promising candidate for spin-orbit-torque (SOT) magnetoresistive random-access memory (MRAM). A giant spin Hall angle &lt;i&gt;θ&lt;/i&gt;&lt;sub&gt;SH&lt;/sub&gt; up to 52 and 10.7 has been observed for BiSb deposited by MBE on GaAs(111) [1] and by sputtering on c-plane Al&lt;sub&gt;2&lt;/sub&gt;O&lt;sub&gt;3&lt;/sub&gt; [2] substrates, respectively. In realistic MRAM, however, magnetic tunnel junctions whose core structure includes an MgO barrier layer and a free ferromagnetic layer on top have to be deposited on Si/SiO&lt;sub&gt;x&lt;/sub&gt; substrates. In this work, we demonstrate the large &lt;i&gt;θ&lt;/i&gt;&lt;sub&gt;SH&lt;/sub&gt; = 2.4 of BiSb in all-sputtered BiSb/CoPt/MgO multilayers on Si/SiO&lt;sub&gt;x&lt;/sub&gt; substrates, and investigate the SOT magnetization switching behaviors. Low power and fast switching is attained, demonstrating the robustness and reliability of BiSb as a spin current source.&lt;br/&gt;We deposited BiSb(10)/Pt(0.8)/Co(0.6)/Pt(0.8)/MgO(10) (Fig. 1(a)), from top to bottom on Si/SiO&lt;sub&gt;x&lt;/sub&gt; substrates at room temperature (thickness in nm). The Pt/Co/Pt trilayers are perpendicularly magnetized with a large anisotropy field of 4.5 kOe (Fig. 1 (b)(c)). Fig. 1(d) shows 2nd harmonic Hall resistance &lt;i&gt;R&lt;/i&gt;&lt;sub&gt;2&lt;i&gt;ω&lt;/i&gt;&lt;/sub&gt;&lt;i&gt; &lt;/i&gt;- field &lt;i&gt;H&lt;sub&gt;x&lt;/sub&gt;&lt;/i&gt; characteristics at different current density &lt;i&gt;J&lt;/i&gt;&lt;sup&gt;BiSb&lt;/sup&gt;, and a representative fitting curve (dashed) for evaluation of the antidamping-like field &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;AD&lt;/sub&gt;. Fig. 1(e) shows the estimated &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;AD&lt;/sub&gt; at various &lt;i&gt;J&lt;/i&gt;&lt;sup&gt;BiSb&lt;/sup&gt;, which yields &lt;i&gt;θ&lt;/i&gt;&lt;sub&gt;SH&lt;/sub&gt; = 2.4. Fig. 2(a) shows the pulse width &lt;i&gt;τ&lt;/i&gt; dependence SOT switching loop. The magnetization of CoPt trilayers can be efficiently switched by a small threshold current density &lt;i&gt;J&lt;/i&gt;&lt;sub&gt;th&lt;/sub&gt;&lt;sup&gt;BiSb&lt;/sup&gt; = 2.3 MAcm&lt;sup&gt;-2&lt;/sup&gt; at pulse width of 50 ms. The &lt;i&gt;J&lt;/i&gt;&lt;sub&gt;th&lt;/sub&gt;&lt;sup&gt;BiSb&lt;/sup&gt; - &lt;i&gt;τ&lt;/i&gt; characteristics yields the thermal stability factor Δ = 32 (Fig. 2(b)). We also demonstrate robust switching by consecutive pulses (Fig. 2(c)) and fast switching down to 100 ns (Fig. 2(d)). Our work shows that it is possible to implement ultralow power SOT-MRAM using BiSb on Si/SiO&lt;sub&gt;x&lt;/sub&gt; substrates.

![](https://assets.underline.io/uploads/markdown_image/1/image/377dc47146e78726a8fbab3cddd96e54.jpg)

Fig. 1 (a) Schematic structure. (b)(c) Hall resistance measured with magnetic field perpendicular to the film plane and in-plane along the current direction. (d) R2ω as a function of Hx at different JBiSb. (e) HAD as a function of JBiSb.

![](https://assets.underline.io/uploads/markdown_image/1/image/0dfa12a8b5145229ef559ecc86b500d1.jpg)

Fig. 2 (a) SOT switching loops at different τ. (b) JthBiSb as a function of τ. (c) Robust switching by 100 μs pulse currents. (d) Switching loops by short pulses.


2022 Joint MMM-INTERMAG

Low power spin-orbit torque magnetization switching in all-sputtered BiSb topological insulator / perpendicularly magnetized CoPt / MgO multilayers on Si substrate
