Magnetic navigation systems (MNSs) capable of generating various types of magnetic fields have been widely studied for the effective manipulation of biomedical magnetic robots [1-4]. Previous researchers proposed a geometrically and electrically efficient MNS comprised of a simple triad of electromagnetic coils (TEC) that can generate two-dimensional (2D) magnetic robot motions [3]. However, the TEC suffered from the restricted working area of the magnetic robot due to the nonlinearly distributed magnetic field throughout the system. In this research, we propose a method to precisely generate 2D magnetic torque and force of a magnetic robot regarding the robot&#39;s current position inside the TEC. Since the TEC is composed of three identical circular coils located at the vertices of an equilateral triangle, the magnetic field at a certain position inside the TEC can be expressed in terms of the three coils&#39; currents and a position vector by using Jacobian and transformation matrices [4]. From this expression, we established several constraint equations to optimally manipulate the magnetic robot’s 2D motions at any position within the TEC. Fig. 1 shows several simulated magnetic fields of the TEC to propel a magnetic robot (red dots) in the direction of the x-axis. It shows that the TEC can generate a relatively uniform magnetic force within the nearby area of a magnetic robot, making it possible to move the magnetic robot in the desired direction (Fig. 2). We then constructed the TEC and a closed-loop visual tracking system to demonstrate that the TEC can manipulate a magnetic robot inside the TEC in a closed-loop manner. The results showed that the proposed method and system can improve the magnetic robot’s admissible working area in the TEC effectively and precisely.References: [1] M. Kummer, J. Abbott, and B. E. Kratochvil et al., IEEE Transactions on Robotics, Vol. 26, pp. 1006-1017, 2010. [2] Q. Cao, X. Han, B. Zhang, and L. Li et al., IEEE Transactions on Applied Superconductivity, Vol. 22, 2012. [3] H. Lee and S. Jeon, AIP Advances. Vol. 10, 2020. [4] G. Go, H. Choi, and S. Jeong et al., Sensors and Actuators, Vol. 205, P. 215-223, 2014.
