The millimeter-wave (mmWave) and terahertz (THz) bands offer enormous bandwidth that is unparalleled, compared to the bandwidth available at lower microwave bands. This bandwidth has significant impact on the performance of wireless systems. The larger the channel bandwidth, the higher the throughput of wireless communication systems, and the higher the resolution of radar sensor systems.
For the development of mmWave and THz wireless systems, advanced packaging platforms are required for system-integration of the ICs, antennas and other components required for system functionality. However, these platforms, also called antenna-in-package (AiP) platforms in published literature must meet some key requirements.
In this talk, the packaging requirements for mmWave and THz wireless applications are extensively discussed.
