**Please read the paper on the following link:**

https://1worldcontent.com/ess/9229.pdf

**Abstract:**

A 32 Kb dual-port low-voltage SRAM in 28nm FD-SOI, featuring foundry supplied high-density 6T bitcells, is presented. Dual-port configurability is realized by a unique dual-rail architecture, utilizing boost techniques that guarantee reliable operation in low-voltage. The area cost of the array is 62% lower, compared to widely used 8T two-port or dual port SRAM arrays. The SRAM reliably operates in the low-voltage regime, and an access rate of 1MHz is measured at VMIN of 0.29V. The highest energy efficiency of 1.35 fJ/bit-access is obtained at 80MHz access rate, at a VDD of 0.54V.

ESSCIRC ESSDERC 2021

A Low-Voltage 6T Dual-Port Configured SRAM with Wordline Boost in 28 nm FD-SOI

single-ended read

6t bitcell

boost-assist

dual-port

sram

low-power

low-voltage

The aim of ESSCIRC and ESSDERC is to provide an annual European forum for the presentation and discussion of recent advances in solid-state devices and circuits.
The level of integration for system-on-chip design is rapidly increasing.

This is made available by advances in semiconductor technology. Therefore, more than ever before, a deeper interaction among technologists, device experts, IC designers, and system designers is necessary. ESSCIRC and ESSDERC are governed by a common Steering Committee and share Plenary Keynote Presentations and Joint Sessions bridging both device and circuit communities.

Highlights:
* 3 joint keynote presentations
* 3 keynote presentations ESSCIRC
* 3 keynote presentations ESSDERC
* Invited papers with overall coverage of all aspects of advanced devices and circuits
* Presentation of IEEE and ESSCIRC/ESSDERC Awards
* Educational Events

JOINT PLENARY talks live broadcast: September 13, 2021<br>
ESSCIRC and ESSDERC KEYNOTE talks live broadcast: September 15, 2021<br>
LIVE Q&A INTERACTIVE sessions for all Conference Technical sessions: September 14 – 16 – 17, 2021<br>
LIVE Q&A INTERACTIVE sessions for all Educational Events: September 20-21-22, 2021<br>
(on demand videos available from September 6 until November 30, 2021)

**Please see here for the [ESSCIRC Guide](https://drive.google.com/file/d/10dghzuv4aQBty4QfTIY9Q8hXyqsue8Le/view?usp=sharing), [ESSDERC Guide](https://drive.google.com/file/d/10dx9y2tm9cHPDa4upNUYjfXCf44aPry5/view?usp=sharing), and the [Program at a Glance](https://drive.google.com/file/d/10eU0OLTXEpiNzI5hkqv4mSr43T8cedPP/view?usp=sharing)**


To access ESSCIRC ESSDERC 2021, you must pre-register for the conference.  Instructions on how to access the event will be provided directly to attendees and included on the ESSCIRC ESSDERC conference website. [Register now](https://www.esscirc-essderc2021.org/).

Please register for the ESSCIRC conference to join the event.

The aim of ESSCIRC and ESSDERC is to provide an annual European forum for the presentation and discussion of recent advances in solid-state devices and circuits.
The level of integration for system-on-chip design is rapidly increasing.

This is made available by advances in semiconductor technology. Therefore, more than ever before, a deeper interaction among technologists, device experts, IC designers, and system designers is necessary. ESSCIRC and ESSDERC are governed by a common Steering Committee and share Plenary Keynote Presentations and Joint Sessions bridging both device and circuit communities.





technical paper

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9038.pdf

**Abstract:**

Apart from the well-known nonlinearity-induced fixed spurs, a DDSM divider-based fractional-N frequency synthesizer can manifest spurs with time-varying frequency offsets from the carrier; these are called wandering spurs. This paper presents experimental results for a 4.9 GHz CP-PLL fractional-N PLL featuring a modified MASH-based divider controller that implements wandering spur suppression. The synthesizer achieves a 20 dB reduction in the spectral envelope of the short-term output phase noise spectrum when compared to the standard MASH DDSM divider controller.

Experimental Verification of Wandering Spur Suppression Technique in a 4.9 GHz Fractional-N Frequency Synthesizer

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9138.pdf

**Abstract:**

An ultra-low power truly balanced frequency doubler has been demonstrated in a 110 nm CMOS technology, operating from 22 to 25 GHz with high fundamental rejection. Current-reused structure is leveraged to save power consumption, improve its fundamental rejection and symmetry of the differential outputs. The measured saturated power is 0-dBm and the best fundamental rejection is 44 dB. The frequency doubler operates under a 1.2 V supply voltage and achieves -4.2 dB conversion gain with 6 mW power consumption.

An Ultra-Low Power K Band Balanced Frequency Doubler with a Novel Current-Reused Structure

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9027.pdf

**Abstract:**

This paper presents a 53.25 GHz to 213 GHz frequency quadrupler with an output bandwidth of 15.5 GHz. In saturation the system achieves 11.8 dB of conversion gain at 2dBm of saturated output power. Consuming 92.9mW of DC power, the power-added efficiency is 1.6 %, a 28.7% against the current state of the art. Harmonic suppression greater than 30 dB over the full 3-dB-bandwidth is achieved, while the rejection at center frequency is greater than 45 dB. Being the first in its class to combine large power delivery with high conversion gain, more than doubling the state of the art, the demonstrated quadrupler qualifies for application in large-scale transceivers where high levels of local oscillator signal powers need to drive several parallel de-/ modulator stages.

A 213 GHz 2 dBm Output-Power Frequency Quadrupler with 45 dB Harmonic Suppression in 130 nm SiGe BiCMOS

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9061.pdf

**Abstract:**

This work presents a broadband and high power D-band multiplier by 4 chain designed in a 130nm silicon-germanium (SiGe) BiCMOS technology. A single-ended 35 GHz input signal is made differential by a Marchand balun and multiplied by 4 by means of a Gilbert cell based quadrupler. The undesired harmonics are filtered out by a double section harmonic filter and, after a D-Band Marchand balun employed for differential to single conversion, amplified using a broadband 3-stage cascode amplifier. The presented circuit achieves a 3-dB bandwidth of 60 GHz, covering the entire D-band (110 GHz to 170 GHz) with a peak saturated output power of 8 dBm. A rejection of more than 40 dB has been measured for 3rd, 5th, 6th and 7th harmonics at 140 GHz. The designed circuit consumes 280mW from a 3.3V supply, resulting in a drain efficiency of 1.75%. The proposed solution shows a 43% relative bandwidth, which is, to the best of the authors’ knowledge, the largest among the up to now published silicon based D-band frequency multiplier by 4 chains.

A Broadband 110-170 GHz Frequency Multiplier by 4 Chain with 8 dBm Output Power in 130 nm BiCMOS

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9269.pdf

**Abstract:**

We present a 2T0C IGZO based Capacitor-less memory that enhances the sensing margin and retention time for DRAM applications requiring higher data immunity. In the proposed technique for increased data integrity, the Read Bit-Line (RBL) is precharged at Half-VDD, instead of Full-VDD, to utilize the rising edge of read word line (RWL) at the beginning of read. This increases the storage node potential of the bit-cell (due to coupling between RWL and the storage node) which is otherwise degraded at write termination due to coupling of write word line (WWL) and the storage node.

Enhanced Data Integrity of In-Ga-Zn-Oxide Based Capacitor-Less 2T Memory for DRAM Applications

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9029.pdf

**Abstract:**

A fast charge loss during short time retention operation was observed in word-line stacked 3-D NAND flash memory, and the origin of the fast charge loss was comprehensively evaluated. Using a fast-response pulse I-V system, the fast charge loss behaviors from lateral and vertical migration of trapped charges were thoroughly investigated and measured at various program/erase levels and temperatures in solid and checkerboard pattern.

Vertical and Lateral Charge Losses During Short Time Retention in 3-D NAND Flash Memory

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9189.pdf

**Abstract:**

This paper presents a comparison of array-level performance of non-volatile SOT-MRAM and SOTFET-RAM to conventional 6T CMOS SRAM using a specially developed simulation suite that merges physics-based compact models and layout-based parasitic extraction. Unlike prior work, our characterization framework generates a full layout of the memory array including all peripheral logic and routing. The framework uses an industry-standard parasitic extraction tool to generate the full netlist including parasitics which is then simulated using compact models for the appropriate emerging non-volatile device. Using this framework, we show about 1.8X energy savings for total read operations and write operations, and 2X area savings for the SOT-based memories relative to a comparable CMOS SRAM for a 256X128 array size. Our unique full-layout approach also enables important insights that challenge conventional wisdom based on higher-level modeling.

Layout-Based Evaluation of Read/Write Performance of SOT-MRAM and SOTFET-RAM

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9231.pdf

**Abstract:**

Ge MFS capacitors with ultrathin ferroelectric HZO are prepared to fabricate FTJ devices. 5 nm HZO after wake-up show good reliability and excellent polarization switching characteristics featuring high remanent polarization Pr~ 22.2 μF/cm2 and low coercive voltage Vc ~ 1.1V. These performance characteristics create the prospect for low voltage (<2 V) /low power NVM FTJ memories. According to our modeling, 5 nm FTJs suffer from low Jon, but thinner HZO devices combine high Jon (>0.1 A/cm2) and relatively large TER (>70). A sufficiently large Jon has been measured on our 3-nm HZO FTJs, albeit with lower-than-expected TER and Ion/Ioff ratios.

Scaling Ferroelectric HZO Thickness for Low Power Ge MFS-FTJ Memories

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9220.pdf

**Abstract:**

In this paper, artificial synapses based on 4-terminal ferroelectric Schottky barrier field effect transistors (FE-SBFETs) are experimentally demonstrated. The ferroelectric polarization switching dynamics gradually modulate the Schottky barriers, thus programming the device conductance by applying positive and negative pulses to imitate the excitation and inhibition behaviors of biological synapse, respectively. The excitatory post-synaptic current can be tuned by the back-gate bias, enabling the reconfiguration of the weight profile with high speed (20 ns) and low energy (< 1 fJ) consumption. Besides, tunable long term potentiation and depression with high endurance and low cycle-to-cycle variations are achieved. These findings demonstrate FE-SBFET has high potential as an ideal synaptic component for the future intelligent neuromorphic network.

4-Terminal Ferroelectric Schottky Barrier Field Effect Transistors as Artificial Synapses

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9239.pdf

**Abstract:**

We present an innovative mechanism to remove electric charges from SRAM bitcells. The particularity of this countermeasure is to be compatible with SRAMs designed from foundry bitcells. We have designed and characterized an 8kB SRAM in 22nm FD-SOI technology exploiting the proposed security strategy demonstrating an erase operation accomplished in the ns time scale (versus 295µs using conventional power-off) with an additional area <5%. We have also shown the better efficiency of our solution compared to a solution without prior erasure. The use of the latter drops the ratio of zeroized addresses at 92%, while increasing energy consumption by 2.1x.

A Low-Voltage 6T Dual-Port Configured SRAM with Wordline Boost in 28 nm FD-SOI
