This paper presents an IF-to-millimetre-wave (mmW) upconversion mixer for multistandard transmitter (Tx) architectures implemented in a 65nm standard CMOS technology. The proposed mixer circuit utilises transformer-coupled transistor stacking that allows high overdrive voltages in a low-supply voltage design. The fabricated mixer occupies 0.33mm2 of chip area including LO- and RF-baluns as well as the pads. The measured return loss of the differential IF input is better than -13 dB for a frequency range of up to the 3rd harmonic of the input signal centred at 5GHz. The maximum measured conversion gain is 13.3dB at an LO power level of 0dBm with a 3-dB IF-bandwidth of 6GHz. The 3-dB RF-bandwidth for an IF-input centred at 5GHz spans from 19GHz to 35GHz. The input-referred 1-dB compression point is -12.2dBm with an IIP3 of -12dBm. The total power consumption is 78.5mW. The LO-to-RF isolation is better than 32dB in the entire bandwidth.
