This work presents a new method of noise model implementation for circuit simulations, which enables the generation of Lorentzian-type spectra. The importance of Lorentzian noise modeling is explored in contrast to classic 1/f or Random Telegraph Noise (RTN) modeling, in terms of PSD, total noise power, and device-to-device noise variability reproduction, through analysis of experimental data. The Verilog-A modeling methods for both types of Lorentzian noise are demonstrated and validated, using a Lambert-W function charge-based drain current model. Finally, fundamental digital and analog circuits such as the Ring Oscillator are used to showcase the usefulness and applicability of the “VERILOR” model in circuit noise simulations.

ESSCIRC ESSDERC 2021

VERILOR: A Verilog-A Model of Lorentzian Spectra for Simulating Trap-Related Noise in CMOS Circuits

circuit noise

verilog-a

tri-gate nanowire mosfets

noise variability

lorentzian noise

g-r noise

low-frequency noise

random telegraph noise
