**Abstract:**

We demonstrate the first MRAM-based IMC macro, implemented in an advanced-node 22nm FD-SOI technology from GF and achieving high row parallelism, for maximizing IMC gains. Our implementation is enabled by high-sensitivity pitch-matched readout circuits, addressing non-idealities using both circuit and software techniques. We present basic operation and neural-network (NN) CIFAR-10 classification, leveraging a generalized training algorithm and achieving 5.1 TOPS/W and 758 GOPS/mm2.

ESSCIRC ESSDERC 2021

A Maximally Row-Parallel MRAM In-Memory-Computing Macro Addressing Readout Circuit Sensitivity and Area

in-memory-computing

rram

mram
