A study on the effects of porosity on the capacitance of p-doped Si electrodes was carried out in the presented work. For that two different parameters, namely the porosification time and the current density applied in the anodization process have been varied and as a result 12 types of porous Si electrodes, corresponding to 6 different current densities and 2 different time durations, were obtained and evaluated in a plane parallel capacitor configuration through EIS, CV and C&amp;D measurements. In addition to porosification, the electrodes have also been modified through electrodeposition of a conductive polymer and thermal treatment towards obtaining activated carbon at the surface.

AIP Publishing Horizons - Energy Storage and Conversion

In-depth analysis of porous Si electrodes for supercapacitors

porous si

energy storage

supercapacitors
