Anode materials required basic properties like metallic structure, fast and easy diffusion and low redox potential (OCV). Recently, the novel two-dimensional polyalanine C3N predicated as a promising and alternate anode material for LIB at the place of graphite. C3N is a two-dimensional sp 2 hybridized semiconductor material. In our work by using first principles approach, we proposed the C3N/Graphene, C3N/Graphene_BL and BL_C3N/Graphene multilayer heterostructure. For all these multilayer heterostructure, we are able to attain specific capacity in the range of 581 - 484 mAh/gm. Due to small interlayer distance (3.15 Å) as compare to graphite delivers the volume expansion in the range of 18 - 20 %.

MATERIALS FOR HUMANITY (MH 21)

First Principles study of sp2 hybridized C3N/Graphene multilayer heterostructure as a promising anode for Li-ion Battery
