Abstract Body: β-Ga2O3 is well known for its multidimensional functionality, such as deep-UV photodetector, high power electronic device, water splitting, CO2 reduction, gas sensor, etc. Here we are presenting a low cost pulsed laser deposition method to demonstrate nano-columnar β-Ga2O3 thin film on silicon substrate with an average crystallite size of ~9 nm. In-situ anisotropic thermal conductivity during the grow process facilitates the unidirectional columnar growth of β-Ga2O3 thin film, decorated with nanocrystalline surface morphology. With increasing substrate temperature, it shows blue shifting of band edge absorption with decreasing defect density. Luminescence spectra show drastic improvement in intensity (~30 times), which is beneficial for further optoelectronic application.

EMC 2021

Realization of Self-Assisted Growth of Nano-Columnar β-Ga2O3 Thin Film on Silicon Substrate

nano-columnar β-ga2o3 thin film

green emission

β-ga2o3

pulsed laser deposition
