We investigate collective motions of points in 2D systems, orchestrated by Lloyd algorithm. The algorithm iteratively updates a system by minimising the total quantizer energy of the Voronoi landscape of the system. As a result of a tradeoff between energy minimisation and geometric frustration, we find that optimised systems exhibit a defective landscape along the process, where strands of 5- and 7-coordinated dislocations are embedded in the hexatic phase. In particular, dipole defects, each of which is the simplest possible pair of a pentagon and a heptagon, come into the picture of dynamical arrest, as the system freezes down to a disordered hyperuniform state. Moreover, we explore the packing fractions of 2D disk packings associated to the obtained hyperuniform systems by considering the maximum inscribed disks in their Voronoi cells.

Powders &amp; Grains 2021

Dynamical arrest of topological defects in 2D hyperuniform disk packings

[EPJ Web of Conferences, Volume 249 (2021)](https://www.epj-conferences.org/articles/epjconf/abs/2021/03/contents/contents.html)

Follow us on [Twitter](https://twitter.com/g2021_p)

**Meet the Organizers**

<center>
<figure class="video_container">
	  <iframe src="https://screencast-o-matic.com/watch/cr130qV10B3?v=6&ff=1&title=0&controls=1" width=826 height=526  frameborder="0" allowfullscreen="true"> </iframe>
</figure>
	</center>


Welcome to the 2021 Powders and Grains conference. Please review the event's **Code of Conduct** [here](https://drive.google.com/file/d/1P_bOrjI2jSE55twRPVzWl5VkfARR-qBL/view?usp=sharing).


**Powders & Grains 2021 Walkthrough Screencast**

This video will demonstrate how to navigate the conference and virtual platform -- and network with other attendees and speakers.


<center>
<figure class="video_container">
	  <iframe src="https://screencast-o-matic.com/watch/cr1vnKV1pgn?v=6&ff=1&title=0&controls=1" width=826 height=526  frameborder="0" allowfullscreen="true"> </iframe>
</figure>
	</center>

To register for the event, please follow the link below.

Powders & Grains 2021

Powders & Grains 2021 will be held in Buenos Aires (Argentina, VIRTUAL) July 5, 13, 21, 29 and Aug 6, 2021. The aim of the conference is to give an up-to-date picture of the broad research field of granular media, powders and grains. Contributions from experts around the world will focus on research topics that cover a wide range of open problems in the field.

technical paper

Landslides appear in many different forms and sizes, from devastating debris flows to overly optimistic sand castles. A familiar and well-documented feature of all landslides is the positive correlation between volume and landslide runout. Larger landslides have a greater potential to reach farther. Here we explore the low volume limit and find a surprising negative correlation between volume and landslide runout. A decrease in volume leads to an increase in runout. In a series of experiments we systematically vary the landslide volume to reveal a transition between these two regimes.

A landslide granular phase transition

In this work, we apply the theory of radiation and reception of acoustic waves in the analysis of the acoustic contributions of the silo music phenomenon. The length portion of the silo where the silo music phenomenon occurs is considered a continuous line source. The continuous line source modeled as a simple acoustic source permits the analysis of the acoustic far field, interpreting the polar graphics of the beam patterns of the acoustic contributions. We propose to apply this technique in the silo design to diminish adverse acoustic effects during the discharge process of granular materials. Additionally, we present calculations of the sound pressure level of the silo music phenomenon.

Acoustic radiation patterns of the silo music phenomenon

The moisture has been recognized to have a significant influence on the initiation movement of sand by wind and consequently on sand transport rates. The pertinent literature regarding these phenomena is sparse and current available theoretical and empirical models exhibit considerable disagreement regarding the magnitude of moisture effects. We believe that these discrepancies comes from the fact that the moisture levels are not well controlled neither properly measured and are susceptible to strongly vary over time due to evaporation. To get rid of the variability of moisture content due to evaporation, we propose a new approach based on the use of non-volatile liquid, namely silicon oil instead of water. This insures a proper control of the liquid content and the production of reliable data concerning the variation of the transport threshold with liquid content.

Aerodynamic and impact thresholds for cohesive mixture of sand and non-volatile liquid

A bidisperse medium of large sand particles and small glass beads is mixed in a cylindrical vessel that is put in rotational motion around an eccentric static rod. The subsequent segregation occurring in the system is investigated primarily at the free surface where the large particles concentration globally increases towards a limit value while oscillating. In order to gain deeper understanding of the intrinsic mechanisms causing the segregation, we also explore the dynamics in the bulk. Average residual bulk displacements fields both vertically and orthoradially could then be measured and show a secondary flow that counteracts the segregation process

Modulated segregation of a bidisperse granular mixture due to recirculation currents

We present a newly developed experiment for the examination of low-speed impacts under asteroidconditions. More specifically, our experimental setup enables us to simulate a very clean milligravity environ-ment under vacuum, in which projectiles are shot at a granular bed at several cm/s. This granular bed consists ofirregularly formed basalt particles with different size distributions. The experiment is carried out in the Bremendrop tower in its catapult mode, granting more than 9 s microgravity. Here, we discuss the setup and assess itsperformance.

Experiments on rebounding slow impacts under asteroid condition

We investigate failure in granular material with numerical simulations based upon DEM (Distinct Element Method).

Failure is associated with a discontinuity in a component of the incremental strain over a plane surface through the condition of the determinant of the acoustic tensor to be zero.

DEM simulations are carried out on an aggregate of elastic frictional spheres, initially isotropically compressed and then sheared at constant pressure.

The components of the stiffness tensor are evaluated numerically in
stressed states along the triaxial test, and employed in the condition of the acoustic tensor to predict localization.

This occurs in the pre-peak region, where the material behavior is on average incrementally frictionless, i.e., change in deviatoric stress due to the tangential forces is negligible.


Failure in granular materials based on acoustic tensor: a numerical analysis

Displacement fields in sheared particle packings often display vortex-like structures that reveal essential features about the mechanical state of the collection of particles. There are several metrics to quantify these flow field features, yet extracting such quantitative metrics from flow field or particle tracking data involves
making numerous choices on the time and length scales over which to average. Here we employ a much used experimental data set on sheared disk packings to explore how such arbitrary data mining choices affect the obtained results. We focus on calculating the strain dependent vorticity, as this metric is a differential method hence potentially sensitive to the way it is computed. We find that the total surface area with an absolute vorticity above a certain threshold approaches a plateau value as shear progresses. This plateau value exhibits a non-monotonic dependence on packing fraction. We also show which range of choices yields results that can
support an analysis method independent, physical interpretation of the flow field data.

Strain dependent vorticity in sheared granular media

We focus on localizing the source of acoustic emissions within a compressed two-dimensional granular ensemble of photoelastic disks, having as main information the arrival times of the acoustic signal to 6 sensors located in the boundaries of the system. By estimating, thanks to the photoelasticity of the grains, the wave speed at every point of the structure, we are able to compute the arrival times from every point of the system to the sensors. A comparison between the arrival time differences between every set of computed values to those from the actual measurements allows finding the source of the acoustic emissions.

Acoustic localisation in a two-dimensional granular medium

In the present work, the relaxation of several wood powders has been investigated in an annular shear cell. It is found that the slow logarithmic relaxation commonly observed for various materials including granular materials is interrupted by large events. Their frequency and amplitude are investigated with respect to particle size and stress-history by measuring stresses and strain. These large events during
the relaxation appear to be controlled by the deformation. The coarser the particles are, the bigger is the deformation of the powder bed between two fast relaxation events and during the event.

Slow and intermittent stress relaxation of biomass granular media

We analyze the dilation of the system in a cylindrical granular fault consisting of one single layer of disks submitted to both normal pressure and continuous and slow shear, which results in intermittent and sudden energy release events that reproduce the main laws of seismicity. The dilation of the system can be separated into two parts: a smooth increase of dilation, plus sudden changes both contracting and dilating the medium, which are correlated to abrupt jumps -both positive and negative- in the measured resisting torque. We explain the four possible (and existing) general scenarios combining those two variables: dilation jumps and torque jumps, thanks to the assumption of an optimal local angle in the direction of force chains, and each reorganization of the structure as a replacement of the force chain holding most of the applied stress. The average rate of increase of global dilation varies monotonically with the size of the energy release event, making dilation a plausible candidate to predict catastrophic events in such earthquake-like systems.

Dynamical arrest of topological defects in 2D hyperuniform disk packings
