The limited range of quantum key distribution (QKD) in fiber based systems led to several projects aiming for the development of a satellite based QKD infrastructure. Photonic integrated circuits (PICs) are a convenient way to implement all necessary optical functions necessary for QKD, while meeting the stringent demands on size, weight and power in satellite missions.

In this work, we present our payload intended for the demonstration of integrated quantum communication technology in space. It is based on two Indium-Phosphide PICs implementing a source for modulated weak coherent states as well as a quantum random number generator (QRNG) based on homodyne measurements of the quantum mechanical vacuum state. The whole system is implemented on a 10 cm x 10 cm PCB including electronics, making it compatible to the CubeSat standard.

These developments will be tested as a part of the CubeSat mission QUBE, which is scheduled for launch in December 2021.

Bristol Quantum Information Technologies Workshop

Integrated photonics for quantum communications on a CubeSat

qrng

satellite-qkd

integrated photonics
