We present the simulations of optical waveguide arrays used as photonic quantum simulators of a Heisenberg spin-chain in a silicon nitride photonic chip. The photonic lattices were manufactured using electron beam lithography and reactive ion etching process to obtain ridge waveguides. The photonic devices are currently in process of characterization with a CW laser of 780 nm, where the light is coupled vertically with a single mode fiber into Bragg gratings optimized for a wavelength of 800 nm. Finally, the dynamics of the system can be determined by measuring the output of the lattice and choosing the initial state with the input port of the array of waveguides.
