Magnetorheological elastomer (MRE) is a magnetic particle reinforced elastomer composite, which its mechanical properties can be controlled with the application of a magnetic field.&lt;sup&gt;1&lt;/sup&gt; The magnetorheological effect induces changes in stiffness and damping properties in the composite with the response of the magnetic particles to the external magnetic field.&lt;sup&gt;2&lt;/sup&gt; Smart sensor and actuator components can be fabricated for adaptive vibration control systems where mechanical properties can be controlled by the application of magnetic field. Typically, composites are prepared by mixing magnetic particles with the uncured rubber matrix and then the mixture is poured into a mold for curing. Recently low-cost 3D printers are widely available, utilizing various polymers. Manufacturability of MRE composites using additive manufacturing (AM) process has gained great attention so the geometrical design of the MRE composite fabrication can be achieved.&lt;sup&gt;3&lt;/sup&gt; In this research, development of filament of MRE for fused filament fabrication based on additive manufacturing is performed. The magnetorheological effect depends on the particle’s magnetic properties and volume fraction, and distribution, etc. Filament materials are developed by mixing thermoplastic polyurethane (TPU) pellets with the magnetic particles (iron oxide, carbonyl Fe particles), followed by extrusion process to produce rolls of filament. Due to the nature of the mixing process relying on gravity to feed material into the extruder, denser and much smaller magnetic particles (~10 μm) than the TPU pellets (~mm) tend to fall to the bottom of the hopper, leading non-uniform distribution of magnetic particle along the filament thru extrusion process. Therefore, the trickling systems with a screw feeder were developed to provide consistent trickling rate of each TPU and magnetic particles respectability. [Figure 1 (a)] The trickling rate of TPU was fixed at ~4.9 g/min and the trickling rate of iron oxide was varied from 0.0 to 2.5 g/min. Five sets of filaments were produced with different trickling rates of iron oxide.[Figure 1(b)]. Diameter ranges from 1.45 ± 0.01 to 1.55 ± 0.06 mm. The density of filament increases with the higher trickling rate of magnetic powder and the densities change from 1.33 ± 0.05 to 1.46 ± 0.05 g/cc, indicating that the volume fraction control of magnetic particles in the extrusion process was successful. The grayscale level plot [Figure 1 (c)] indicates the iron oxide concentration in each filament in the yellow box region. The grayscale plot profiles the images with each point represents the average pixel intensity. This data shows that the filaments produced with lower trickling rate (0.6 and 1.0 g/min) did not show significant difference but the lower gray scale values of filaments with 1.5 and 2.5 g/min indicate that there are more iron oxide particles. Micro-focus X-ray tomography scans were performed on the produced composite filament (Figure 2). The results show that magnetic particles are well dispersed in the matrix. The small grains are &amp;lt; ~30 mm and the larger grains are ~60 mm. The iron oxide volume fraction ranges from 9.31% to 12.95%. This demonstrates that MRE filament feedstock materials can be successfully manufactured for use in fused filament deposition processes.

**References:**

1. S. S. Kang, K. Choi, and J. D. Nam, Materials., Vol.13, p.4597 (2020)&lt;br/&gt;2. O. Padalka, H. J. Song, N. M. Wereley, J. A. Filer, IEEE Transactions on Magnetics, Vol. 46, p.2275 (2010)&lt;br/&gt;3. A. K. Bastola, M. Paudel, L. Li, Smart Materials and Structures, Vol. 29, p.123002 (2020)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/b3aba021d44c39dfd0f2da3a1c22aa82.jpg)
Figure 1 (a) Schematic drawing and image of developed trickling system. (b) coils of TPU filaments produced with different amount of iron oxide. (c) image of extruded filaments and plot profile of the yellow box.

![](https://assets.underline.io/uploads/markdown_image/1/image/f2f413611412f4c079a9eb2b2e621762.jpg)
Figure 2 X-ray tomography scan performed on the produced composite filament. Iron oxide particles are highlighted with color coding by volume. The TPU matrix is colored in light gray to easily visualize the pores and iron oxide dispersions.

INTERMAG 2021

 Magnetic Particle Reinforced Elastomer Composites for Additive Manufacturing

[![](https://assets.underline.io/uploads/markdown_image/1/image/985c8a40b04e56675221c8549975de3c.png)](https://drive.google.com/file/d/1B70nPIeeeqdG4UU70NlYXuKVOHLRuJEo/view?usp=sharing)

### ** History of DRC**
The Device Research Conference (DRC) began in the pre-transistor era with the 1942 establishment of the Conference on Electron Device Research (CEDR). Following William Shockley’s 1948 CEDR presentation of the transistor device, the Solid-State Device Research Conference (SSDRC) was established, with invitation-only attendance.

In the ensuing decades, many exciting firsts were presented at SSDRC, including the use of impurity diffusion in silicon and germanium, the first practical MOSFET, and the first lattice-matched heterojunction.

In 1969, under the leadership or Herbert Kroemer and Cal Quate, the CEDR and SSDRC merged into DRC. In 1970, attendance was opened to all, and the first DRAM (dynamic random-access memory), room temperature lasers, and first CCD (charge-coupled device) were reported—all in the same 1970 DRC meeting!

1976 saw the first official coordination of tandem meetings between DRC and the Electronic Materials Conference (EMC) to bring together the electronic materials and device communities—a custom which persists to this day. In 1991, DRC began publishing its digest with IEEE; they can all be found [here on IEEE Xplore](https://ieeexplore.ieee.org/xpl/conhome/1000199/all-proceedings). Throughout this period, DRC featured reports of many novel and record-setting devices, including the HEMT (High Electron Mobility Transistor), VCSEL (Vertical Cavity Surface Emitting Laser), HBT (Heterojunction Bipolar Transistor), and nanoscale MOSFETs.

In recent years, DRC has continued to be the world’s premier forum to present innovative semiconductor device research with work on organic thin film transistors, graphene and carbon nanotube transistors, and 2D materials all featuring prominently in the 1990s through to the present day. In 2017, we celebrated DRC’s 75th anniversary with special sessions and an [article in the Journal of the Electron Device Society](https://ieeexplore.ieee.org/stamp/stamp.jsp?tp=&arnumber=8168249&isnumber=8232486). DRC technical topics continue to evolve with emerging device trends such as memory devices, quantum devices, optoelectronics/photonics, and wide bandgap power devices to reflect the exciting work being done by a diverse community of device engineers around the globe.

Today, as we look forward to the next 75+ years of device innovation, DRC continues to lead the way in showcasing top-caliber research, facilitating vibrant discussion and debate and acting as a platform to nurture the next generation of device engineers. We welcome you to join us at the next DRC!

To learn more about DRC's history, please see [Aaron Franklin, Debdeep Jena and Deji Akinwande, "75 Years of the Device Research Conference—A History Worth Repeating," in IEEE Journal of the Electron Devices Society, vol. 6, pp. 116-120, 2018. doi: 10.1109/JEDS.2017.2780778](https://ieeexplore.ieee.org/stamp/stamp.jsp?tp=&arnumber=8168249&isnumber=8232486).

### **Topics**
* Biological Devices
* Devices for Extreme Conditions
* Heterogeneously Integrated Devices
* Memory Devices
* Modeling and Simulation of Devices
* Nanoscale and Vacuum Devices
* Optoelectronic and Optical Devices
* Other Emerging Devices
* Power Devices
* Quantum Devices
* RF and Terahertz Devices
* Spintronic and Magnetic Devices
* Thin-film Devices
* Wide-bandgap Devices

### **Invited Speakers**
* Patrick Fay, University of Notre Dame
* Susanne Hoffmann-Eifert, Peter Grünberg Institute
* Sanghyeon Kim, Korea Advanced Institute of Science and Technology
* Sriram Krishnamoorthy, University of California, Santa Barbara
* Mario Lanza, King Abdullah University of Science and Technology
* Xiuling Li, The University of Texas at Austin
* Marko Radosavljevic, Intel Corporation
* Siddharth Rajan, The Ohio State University
* Giordano Scappucci, Delft University of Technology
* Fisher Yu, University of Arkansas
* Wenjuan Zhu, University of Illinois at Urbana-Champaign




Registration is required to attend this event. If you have not already done so, please use the link below to register for a ticket to the conference:

https://www.mrs.org/drc-2022/registration

Registration Is Required

DRC 2022

DRC continues to be the world’s premier forum to present innovative semiconductor device research with work on organic thin film transistors, graphene and carbon nanotube transistors, and 2D materials all featuring prominently in the 1990s through to the present day. In 2017, we celebrated DRC’s 75th anniversary with special sessions and an article in the Journal of the Electron Device Society.
DRC technical topics continue to evolve with emerging device trends such as memory devices, quantum devices, optoelectronics/photonics, and wide bandgap power devices to reflect the exciting work being done by a diverse community of device engineers around the globe.

Magnetorheological elastomer (MRE) is a magnetic particle reinforced elastomer composite, which its mechanical properties can be controlled with the application of a magnetic field.1 The magnetorheological effect induces changes in stiffness and damping properties in the composite with the response of the magnetic particles to the external magnetic field.2 Smart sensor and actuator components can be fabricated for adaptive vibration control systems where mechanical properties can be controlled by the application of magnetic field. Typically, composites are prepared by mixing magnetic particles with the uncured rubber matrix and then the mixture is poured into a mold for curing. Recently low-cost 3D printers are widely available, utilizing various polymers. Manufacturability of MRE composites using additive manufacturing (AM) process has gained great attention so the geometrical design of the MRE composite fabrication can be achieved.3 In this research, development of filament of MRE for fused filament fabrication based on additive manufacturing is performed. The magnetorheological effect depends on the particle’s magnetic properties and volume fraction, and distribution, etc. Filament materials are developed by mixing thermoplastic polyurethane (TPU) pellets with the magnetic particles (iron oxide, carbonyl Fe particles), followed by extrusion process to produce rolls of filament. Due to the nature of the mixing process relying on gravity to feed material into the extruder, denser and much smaller magnetic particles (~10 μm) than the TPU pellets (~mm) tend to fall to the bottom of the hopper, leading non-uniform distribution of magnetic particle along the filament thru extrusion process. Therefore, the trickling systems with a screw feeder were developed to provide consistent trickling rate of each TPU and magnetic particles respectability. [Figure 1 (a)] The trickling rate of TPU was fixed at ~4.9 g/min and the trickling rate of iron oxide was varied from 0.0 to 2.5 g/min. Five sets of filaments were produced with different trickling rates of iron oxide.[Figure 1(b)]. Diameter ranges from 1.45 ± 0.01 to 1.55 ± 0.06 mm. The density of filament increases with the higher trickling rate of magnetic powder and the densities change from 1.33 ± 0.05 to 1.46 ± 0.05 g/cc, indicating that the volume fraction control of magnetic particles in the extrusion process was successful. The grayscale level plot [Figure 1 (c)] indicates the iron oxide concentration in each filament in the yellow box region. The grayscale plot profiles the images with each point represents the average pixel intensity. This data shows that the filaments produced with lower trickling rate (0.6 and 1.0 g/min) did not show significant difference but the lower gray scale values of filaments with 1.5 and 2.5 g/min indicate that there are more iron oxide particles. Micro-focus X-ray tomography scans were performed on the produced composite filament (Figure 2). The results show that magnetic particles are well dispersed in the matrix. The small grains are &lt; ~30 mm and the larger grains are ~60 mm. The iron oxide volume fraction ranges from 9.31% to 12.95%. This demonstrates that MRE filament feedstock materials can be successfully manufactured for use in fused filament deposition processes.

**References:**

1. S. S. Kang, K. Choi, and J. D. Nam, Materials., Vol.13, p.4597 (2020) 2. O. Padalka, H. J. Song, N. M. Wereley, J. A. Filer, IEEE Transactions on Magnetics, Vol. 46, p.2275 (2010) 3. A. K. Bastola, M. Paudel, L. Li, Smart Materials and Structures, Vol. 29, p.123002 (2020)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/b3aba021d44c39dfd0f2da3a1c22aa82.jpg)
Figure 1 (a) Schematic drawing and image of developed trickling system. (b) coils of TPU filaments produced with different amount of iron oxide. (c) image of extruded filaments and plot profile of the yellow box.

![](https://assets.underline.io/uploads/markdown_image/1/image/f2f413611412f4c079a9eb2b2e621762.jpg)
Figure 2 X-ray tomography scan performed on the produced composite filament. Iron oxide particles are highlighted with color coding by volume. The TPU matrix is colored in light gray to easily visualize the pores and iron oxide dispersions.

technical paper
