Amorphous glass-coated microwires are among the excellent material that can be used in sensor and spintronic devices. The magnetization process is realized due to the fast domain wall propagation. The studies on domain wall dynamics showed that additional perpendicular magnetic field changes domain wall velocity [1, 2]. Moreover, after the rotation of the microwire in the perpendicular magnetic field the difference in the domain wall velocity is even more significant [3].&lt;br/&gt;&lt;br/&gt;However, the obtained results are contrary to the expectations based on previous knowledge. Due to the cylindrical shape of the wires, no change in domain wall velocity was expected for different rotations. The results are explained in terms of the gradient of the perpendicular magnetic anisotropy in the cross-section of the wire. The gradient is induced to the microwire during the fabrication process. The water stream causes additional induced stresses due to the cooling of the microwire from one side (Fig. 1a). The direct observation of such stresses in the cross-section of the wire is not possible due to the amorphous structure of the microwires. However, it is clearly visible when the sample is annealed above the crystallization temperature (Fig. 1b).&lt;br/&gt;&lt;br/&gt;In this work, we present the domain wall (DW) dynamics studies on the sample (Fe&lt;sub&gt;76&lt;/sub&gt;Si&lt;sub&gt;9&lt;/sub&gt;B&lt;sub&gt;10&lt;/sub&gt;P&lt;sub&gt;5&lt;/sub&gt;) as-cast and annealed below the crystallization temperature (at 450 °C) (Fig. 2). The DW velocity &lt;i&gt;v&lt;/i&gt; is described by the following relation [4]:&lt;br/&gt;&lt;i&gt;v = S(H - H&lt;sub&gt;0&lt;/sub&gt;)&lt;/i&gt; (1)&lt;br/&gt;where &lt;i&gt;S&lt;/i&gt; is DW mobility, and &lt;i&gt;H&lt;sub&gt;0&lt;/sub&gt;&lt;/i&gt; critical magnetic field.&lt;br/&gt;&lt;br/&gt;The DW velocity of the as cast sample is linearly increasing for different angles of rotation &lt;i&gt;θ&lt;/i&gt; (Fig.2a). For &lt;i&gt;θ&lt;/i&gt; &lt;i&gt;= 180°&lt;/i&gt;, DW velocity increases up to 350 A/m with mobility &lt;i&gt;S = 1.44 m&lt;sup&gt;2&lt;/sup&gt;s&lt;sup&gt;-1&lt;/sup&gt;A&lt;sup&gt;-1&lt;/sup&gt;&lt;/i&gt;. From 350 A/m, the DW mobility is &lt;i&gt;S = 24.9 m&lt;sup&gt;2&lt;/sup&gt;s&lt;sup&gt;-1&lt;/sup&gt;A&lt;sup&gt;-1&lt;/sup&gt;&lt;/i&gt;. However, after annealing, the DW motion is observed &lt;i&gt;from H&lt;sub&gt;axial&lt;/sub&gt; = 550 A/m&lt;/i&gt; with the mobility &lt;i&gt;S = 1.73&lt;/i&gt; &lt;i&gt;m&lt;sup&gt;2&lt;/sup&gt;s&lt;sup&gt;-1&lt;/sup&gt;A&lt;sup&gt;-1&lt;/sup&gt; &lt;/i&gt;up to 700 A/m (Fig.2b). DW mobility from&lt;i&gt; H&lt;sub&gt;axial&lt;/sub&gt; = 700 A/m &lt;/i&gt;is incomparably smaller in comparison to the case before annealing, with the value&lt;i&gt; S = 6.79 m&lt;sup&gt;2&lt;/sup&gt;s&lt;sup&gt;-1&lt;/sup&gt;A&lt;sup&gt;-1&lt;/sup&gt;.&lt;/i&gt;&lt;br/&gt;&lt;br/&gt;When the sample is annealed, it leads to the release of the stresses induced in the cross-section of the microwire. Annealing causes the homogenization of the sample, and as a result, a significant decrease in DW mobility is observed. Thus, an effective mechanism for suppressing the angular dependence of DW mobility in a perpendicular magnetic field is annealing under suitable conditions.&lt;br/&gt;&lt;br/&gt;Acknowledgements:&lt;br/&gt;This work was supported by Slovak Grant Agency VEGA 1/0053/19, VEGA 1/0195/17; Slovak Grant Agency grant number APVV-16-0079, APVV-17-0184, APVV SK-FR-2017-024 and Pavol Jozef Šafárik University internal grant system VVGS-2016-320.

**References:**

[1] R. Varga et al., Physica Status Solidi A, Vol. 213, p. 356–362 (2016).&lt;br/&gt;[2] K. Richter et al., Applied Physics Letters, Vol. 96, 182507 (2010).&lt;br/&gt;[3] L. Fecova, K. Richter, and R. Varga, Acta Physica Polonica A, Vol. 137 (5), p. 849-851 (2020).&lt;br/&gt;[4] V. Zhukova et.al, Journal of Applied Physics, Vol. 111, 07E311-1 (2012).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/70d8ab1607609771a6973e4fac77b8eb.jpg)
Fig.1 Taylor-Ulitovski method of drawing the glass-coated microwire Fe&lt;sub&gt;76&lt;/sub&gt;Si&lt;sub&gt;9&lt;/sub&gt;B&lt;sub&gt;10&lt;/sub&gt;P&lt;sub&gt;5&lt;/sub&gt;, which is quenched by the water jet from one side in order to obtain the amorphous structure (a), and the stress distribution in the section of the amorphous wire annealed above crystallization temperature (b).

![](https://assets.underline.io/uploads/markdown_image/1/image/d4ca30e3a4acdb9987c890d60d17e064.png)
Fig.2 Domain wall velocity as a function of the axial magnetic field in the perpendicular magnetic field for the as-cast sample (a) and sample annealed below the crystallization temperature (b).

INTERMAG 2021

 The annealing effect on domain wall dynamics in wires with induced gradient of the perpendicular anisotropy

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

Amorphous glass-coated microwires are among the excellent material that can be used in sensor and spintronic devices. The magnetization process is realized due to the fast domain wall propagation. The studies on domain wall dynamics showed that additional perpendicular magnetic field changes domain wall velocity [1, 2]. Moreover, after the rotation of the microwire in the perpendicular magnetic field the difference in the domain wall velocity is even more significant [3]. However, the obtained results are contrary to the expectations based on previous knowledge. Due to the cylindrical shape of the wires, no change in domain wall velocity was expected for different rotations. The results are explained in terms of the gradient of the perpendicular magnetic anisotropy in the cross-section of the wire. The gradient is induced to the microwire during the fabrication process. The water stream causes additional induced stresses due to the cooling of the microwire from one side (Fig. 1a). The direct observation of such stresses in the cross-section of the wire is not possible due to the amorphous structure of the microwires. However, it is clearly visible when the sample is annealed above the crystallization temperature (Fig. 1b). In this work, we present the domain wall (DW) dynamics studies on the sample (Fe76Si9B10P5) as-cast and annealed below the crystallization temperature (at 450 °C) (Fig. 2). The DW velocity v is described by the following relation [4]: v = S(H - H0) (1) where S is DW mobility, and H0 critical magnetic field. The DW velocity of the as cast sample is linearly increasing for different angles of rotation θ (Fig.2a). For θ = 180°, DW velocity increases up to 350 A/m with mobility S = 1.44 m2s-1A-1. From 350 A/m, the DW mobility is S = 24.9 m2s-1A-1. However, after annealing, the DW motion is observed from Haxial = 550 A/m with the mobility S = 1.73 m2s-1A-1 up to 700 A/m (Fig.2b). DW mobility from Haxial = 700 A/m is incomparably smaller in comparison to the case before annealing, with the value S = 6.79 m2s-1A-1. When the sample is annealed, it leads to the release of the stresses induced in the cross-section of the microwire. Annealing causes the homogenization of the sample, and as a result, a significant decrease in DW mobility is observed. Thus, an effective mechanism for suppressing the angular dependence of DW mobility in a perpendicular magnetic field is annealing under suitable conditions. Acknowledgements: This work was supported by Slovak Grant Agency VEGA 1/0053/19, VEGA 1/0195/17; Slovak Grant Agency grant number APVV-16-0079, APVV-17-0184, APVV SK-FR-2017-024 and Pavol Jozef Šafárik University internal grant system VVGS-2016-320.

**References:**

[1] R. Varga et al., Physica Status Solidi A, Vol. 213, p. 356–362 (2016). [2] K. Richter et al., Applied Physics Letters, Vol. 96, 182507 (2010). [3] L. Fecova, K. Richter, and R. Varga, Acta Physica Polonica A, Vol. 137 (5), p. 849-851 (2020). [4] V. Zhukova et.al, Journal of Applied Physics, Vol. 111, 07E311-1 (2012).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/70d8ab1607609771a6973e4fac77b8eb.jpg)
Fig.1 Taylor-Ulitovski method of drawing the glass-coated microwire Fe76Si9B10P5, which is quenched by the water jet from one side in order to obtain the amorphous structure (a), and the stress distribution in the section of the amorphous wire annealed above crystallization temperature (b).

![](https://assets.underline.io/uploads/markdown_image/1/image/d4ca30e3a4acdb9987c890d60d17e064.png)
Fig.2 Domain wall velocity as a function of the axial magnetic field in the perpendicular magnetic field for the as-cast sample (a) and sample annealed below the crystallization temperature (b).
