France



Excellent hard magnetic properties have been achieved in rare earth transition metal films (Nd-Fe-B, Sm-Co) produced by sputtering, pulsed laser deposition and molecular beam epitaxy. Such films can serve as model systems to probe intrinsic magnetic properties or to study the link between microstructure and extrinsic magnetic properties. They can also be used to produce miniaturized magnetic field sources for applications. In the latter case, the films must be patterned at a length scale comparable to the film thickness, because of the demagnetising field effect. The choice of film thickness will depend on the targeted application, nm-sized field sources require nm-thick films while µm-sized sources require µm-thick films. The film deposition rate becomes very relevant as the film thickness is increased, especially if the ultimate aim is for commercial production. What is more, deposition on large surface areas is needed to allow batch fabrication and integration of micro-magnets. We have previously reported on triode sputtering of 5 µm thick Nd-Fe-B films at deposition rates of up to 18 µm/h [1]. We then demonstrated how such films could be physically patterned at the micro-scale using a topographic approach based on pre-patterning of the substrate or post-deposition etching of the magnetic layer [2]. We also showed that localised heating by laser irradiation through a mask can be exploited to produce magnetisation reversal at the µm-scale in the so-called thermo-magnetic patterning approach [3]. Small arrays of micro-magnets produced using these approaches have already been used in a range of bio-medical experiments [4]. In this work we will demonstrate the potential that triode sputtering holds for batch fabrication of even thicker micro-magnets, for future integration into micro-scaled devices.&lt;br/&gt;Deep Reactive Ion Etching (DRIE) was used to anisotropically etch 55 µm deep trenches into Si substrates of diameter 100 mm and thickness 525 µm. Patterns consisting of squares with lateral size varying from 20 to 400 μm, and 4 mm long stripes with width varying from 20 to 400 μm, were used as test structures (Fig 1). Ta (100 nm) / Nd-Fe-B (50 µm) / Ta (100 nm) trilayers were deposited onto these topographically patterned substrates heated to a temperature of 500°C or 700°C. The NdFeB layer deposited at 500°C was amorphous, while that deposited at 700°C was crystallised. Post-deposition crystallisation of the former was achieved by annealing the full wafer in a Rapid Thermal Annealing (RTA) furnace, under secondary vacuum (10&lt;sup&gt;-6 &lt;/sup&gt;mbar) at 600 °C, with a heating rate of 20°C/s and a dwell time of 10 minutes. Hereafter the samples will be referred to as 1-step processed (T&lt;sub&gt;dep&lt;/sub&gt; = 700°C) or 2-step processed (T&lt;sub&gt;dep&lt;/sub&gt; = 500°C + T&lt;sub&gt;anneal&lt;/sub&gt; = 600°C). Despite the relatively large thickness of the NdFeB layers, film peel-off does not occur. It should be noted that NdFeB films deposited onto non-patterned Si substrates start to peel off the substrate at a film thickness greater than 10 µm. The stress relief afforded by topographic patterning of the substrate depends on the dimensions of the pattern features and the film thickness, and some peel off was observed in 50 µm thick NdFeB layers deposited on square structures of width 500 µm prepared in another study. For the samples detailed here, some cracking of the deposit was observed in expansive regions far from etched features.&lt;br/&gt;SEM images of fractured cross-sections of stripes of two different width (200 µm and 30 µm) of each sample type are compared in Fig 2. Deposition on the sidewalls of the etched trenches leads to the deposition on the “hills” being wider than the underlying Si pillars. A shadowing effect results in the profiles of the deposit in the “valleys” being different to that on the neighbouring “hills”, and the effect becomes stronger as the feature size is reduced. The shadowing effect can be enhanced by increasing the depth of the trenches, as will be shown elsewhere. SEM imaging at higher resolution reveals that the NdFeB grains of the 1-step processed sample are columnar and have widths as large as 1 µm while those of the 2-step processed film are almost equiaxed with diameters in the range of 200 – 500 nm (not shown). Hysteresis loops measured on pieces taken from each sample are shown as insets to Fig 2. The 1-step sample has a coercivity of 1.2 T and an M&lt;sub&gt;0T&lt;/sub&gt;/M&lt;sub&gt;7.5T&lt;/sub&gt; of 0.79 while the corresponding values for the 2-step sample are 2.2 T and 0.85. The higher coercivity of the latter is due to its much finer microstructure and the 2-stage initial magnetization curve may be explained by easy domain wall motion in grains coarser than 300 nm, the single domain particle size of Nd&lt;sub&gt;2&lt;/sub&gt;Fe&lt;sub&gt;14&lt;/sub&gt;B, and domain wall pinning in finer grains. An in-house developed Scanning Hall Probe Microscope (SHPM) equipped with a Hall cross of active area size 4 x 4 µm&lt;sup&gt;2&lt;/sup&gt; [5], was used to measure the stray magnetic field produced at different heights above out-of-plane magnetized pieces of each sample.&lt;br/&gt;In this presentation we will provide full details of structural and magnetic characterization and will compare measured field profiles with simulated profiles. We will finish by discussing future prospects for the fabrication, integration and use of high-performance NdFeB micro-magnets.

**References:**

[1] N.M. Dempsey et al., “High performance hard magnetic NdFeB thick films for integration into Micro-Electro-Mechanical-Systems”, Appl. Phys. Lett. 90 092509 (2007)&lt;br/&gt;[2] A. Walther et al., “Micro-patterning of NdFeB and SmCo magnet films for integration into Micro-Electro-Mechanical-Systems”, J. Magn. Mag. Mat. 321 (2009) 590–594&lt;br/&gt;[3] F. Dumas-Bouchiat et al., “Thermo-magnetically patterned micro-magnets”, Appl. Phys. Lett. 96, 102511 (2010).&lt;br/&gt;[4] N.M. Dempsey, “Magnetism and Biology” in &quot; Handbook of Magnetic Materials&quot;, J.M.D. Coey et al. (eds), Springer, in-press&lt;br/&gt;[5] Gorky Shaw et al., “A Scanning Hall Probe Microscope for high resolution, large area, variable height Magnetic Field Imaging”, Rev Sci Inst 87 (2016) 113702

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/71d2432dd00b4772234c43bc8e6f423d.jpg)
Fig 1: Schematic of the pre-patterned substrates.

![](https://assets.underline.io/uploads/markdown_image/1/image/d17c28d143c41c74d8f313da1a848cdf.jpg)
Fig 2: SEM images of fractured cross-sections of stripes of width 200 µm (top) and 30 µm (bottom) prepared using 1-step (left) and 2-step processing. Insets: M(H) loops of pieces taken from 1-step (left) and 2-step processed samples.

INTERMAG 2021

 Batch fabrication of 50 µm thick anisotropic NdFeB micro-magnets

**Please view our Welcome to MH21 video.**

<center>
<figure class="video_container">
	 <iframe src="https://screencast-o-matic.com/watch/cr1UYHV1pcz?v=6&ff=1&title=0&controls=1" width=826 height=526 frameborder="0" allowfullscreen="true"> </iframe>
</figure>
	</center>


**Walkthrough Video**

Here is a Walkthrough showing how to navigate the conference and network with others

<center>
<figure class="video_container">
	 <iframe src="https://screencast-o-matic.com/watch/cr1vnrV1paE?v=6&ff=1&title=0&controls=1" width=826 height=526 frameborder="0" allowfullscreen="true"> </iframe>
</figure>
	</center>




	 Organized by

<a href="https://mrs.org.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/95d5789689d5f900b90e9fe54ea3cf0d.jpg"</a>



	 In association with

<a href="http://www.ntu.edu.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/334cd171ad2fdee033c635b368e5e160.png"</a>
	<a href="https://www.nus.edu.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/32e6f82c0440f7bb24c590f9f67821bd.png"</a>
		<a href="https://www.a-star.edu.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/72557865b589cfa3d2a0243ffce4a270.png"</a>




	 Supported by

		 <a href="https://www.visitsingapore.com/mice/en/about-us/about-secb/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/6e679842ead62be522ba6a630b82d5c9.png"</a>

To access the MH 21 Conference, [please register](https://mh21.mrs.org.sg/event/da3f9651-429f-4763-81b2-ebd7311b6bc8/websitePage:206f7605-1731-41f9-8421-56d3890f398f)

MATERIALS FOR HUMANITY (MH 21)

MH 21 is arranged around 6 themes that focus attention on pressing needs that should be addressed to enhance the well-being of communities and provide a forum for presenting breakthrough discoveries.

Excellent hard magnetic properties have been achieved in rare earth transition metal films (Nd-Fe-B, Sm-Co) produced by sputtering, pulsed laser deposition and molecular beam epitaxy. Such films can serve as model systems to probe intrinsic magnetic properties or to study the link between microstructure and extrinsic magnetic properties. They can also be used to produce miniaturized magnetic field sources for applications. In the latter case, the films must be patterned at a length scale comparable to the film thickness, because of the demagnetising field effect. The choice of film thickness will depend on the targeted application, nm-sized field sources require nm-thick films while µm-sized sources require µm-thick films. The film deposition rate becomes very relevant as the film thickness is increased, especially if the ultimate aim is for commercial production. What is more, deposition on large surface areas is needed to allow batch fabrication and integration of micro-magnets. We have previously reported on triode sputtering of 5 µm thick Nd-Fe-B films at deposition rates of up to 18 µm/h [1]. We then demonstrated how such films could be physically patterned at the micro-scale using a topographic approach based on pre-patterning of the substrate or post-deposition etching of the magnetic layer [2]. We also showed that localised heating by laser irradiation through a mask can be exploited to produce magnetisation reversal at the µm-scale in the so-called thermo-magnetic patterning approach [3]. Small arrays of micro-magnets produced using these approaches have already been used in a range of bio-medical experiments [4]. In this work we will demonstrate the potential that triode sputtering holds for batch fabrication of even thicker micro-magnets, for future integration into micro-scaled devices. Deep Reactive Ion Etching (DRIE) was used to anisotropically etch 55 µm deep trenches into Si substrates of diameter 100 mm and thickness 525 µm. Patterns consisting of squares with lateral size varying from 20 to 400 μm, and 4 mm long stripes with width varying from 20 to 400 μm, were used as test structures (Fig 1). Ta (100 nm) / Nd-Fe-B (50 µm) / Ta (100 nm) trilayers were deposited onto these topographically patterned substrates heated to a temperature of 500°C or 700°C. The NdFeB layer deposited at 500°C was amorphous, while that deposited at 700°C was crystallised. Post-deposition crystallisation of the former was achieved by annealing the full wafer in a Rapid Thermal Annealing (RTA) furnace, under secondary vacuum (10-6 mbar) at 600 °C, with a heating rate of 20°C/s and a dwell time of 10 minutes. Hereafter the samples will be referred to as 1-step processed (Tdep = 700°C) or 2-step processed (Tdep = 500°C + Tanneal = 600°C). Despite the relatively large thickness of the NdFeB layers, film peel-off does not occur. It should be noted that NdFeB films deposited onto non-patterned Si substrates start to peel off the substrate at a film thickness greater than 10 µm. The stress relief afforded by topographic patterning of the substrate depends on the dimensions of the pattern features and the film thickness, and some peel off was observed in 50 µm thick NdFeB layers deposited on square structures of width 500 µm prepared in another study. For the samples detailed here, some cracking of the deposit was observed in expansive regions far from etched features. SEM images of fractured cross-sections of stripes of two different width (200 µm and 30 µm) of each sample type are compared in Fig 2. Deposition on the sidewalls of the etched trenches leads to the deposition on the “hills” being wider than the underlying Si pillars. A shadowing effect results in the profiles of the deposit in the “valleys” being different to that on the neighbouring “hills”, and the effect becomes stronger as the feature size is reduced. The shadowing effect can be enhanced by increasing the depth of the trenches, as will be shown elsewhere. SEM imaging at higher resolution reveals that the NdFeB grains of the 1-step processed sample are columnar and have widths as large as 1 µm while those of the 2-step processed film are almost equiaxed with diameters in the range of 200 – 500 nm (not shown). Hysteresis loops measured on pieces taken from each sample are shown as insets to Fig 2. The 1-step sample has a coercivity of 1.2 T and an M0T/M7.5T of 0.79 while the corresponding values for the 2-step sample are 2.2 T and 0.85. The higher coercivity of the latter is due to its much finer microstructure and the 2-stage initial magnetization curve may be explained by easy domain wall motion in grains coarser than 300 nm, the single domain particle size of Nd2Fe14B, and domain wall pinning in finer grains. An in-house developed Scanning Hall Probe Microscope (SHPM) equipped with a Hall cross of active area size 4 x 4 µm2 [5], was used to measure the stray magnetic field produced at different heights above out-of-plane magnetized pieces of each sample. In this presentation we will provide full details of structural and magnetic characterization and will compare measured field profiles with simulated profiles. We will finish by discussing future prospects for the fabrication, integration and use of high-performance NdFeB micro-magnets.

**References:**

[1] N.M. Dempsey et al., “High performance hard magnetic NdFeB thick films for integration into Micro-Electro-Mechanical-Systems”, Appl. Phys. Lett. 90 092509 (2007) [2] A. Walther et al., “Micro-patterning of NdFeB and SmCo magnet films for integration into Micro-Electro-Mechanical-Systems”, J. Magn. Mag. Mat. 321 (2009) 590–594 [3] F. Dumas-Bouchiat et al., “Thermo-magnetically patterned micro-magnets”, Appl. Phys. Lett. 96, 102511 (2010). [4] N.M. Dempsey, “Magnetism and Biology” in " Handbook of Magnetic Materials", J.M.D. Coey et al. (eds), Springer, in-press [5] Gorky Shaw et al., “A Scanning Hall Probe Microscope for high resolution, large area, variable height Magnetic Field Imaging”, Rev Sci Inst 87 (2016) 113702

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/71d2432dd00b4772234c43bc8e6f423d.jpg)
Fig 1: Schematic of the pre-patterned substrates.

![](https://assets.underline.io/uploads/markdown_image/1/image/d17c28d143c41c74d8f313da1a848cdf.jpg)
Fig 2: SEM images of fractured cross-sections of stripes of width 200 µm (top) and 30 µm (bottom) prepared using 1-step (left) and 2-step processing. Insets: M(H) loops of pieces taken from 1-step (left) and 2-step processed samples.

technical paper

INTERMAG 2021 Welcome Video




<figure class="video_container">
 <iframe src="https://screencast-o-matic.com/player/crflqFVnUpZ?v=6&ff=1&title=0&controls=1" width=640 height=360 frameborder="0" allowfullscreen="true"> </iframe>
</figure>

Want to buy a ticket?

Register for INTERMAG 2021 here

[![](https://assets.underline.io/uploads/markdown_image/1/image/17ce76e7960db633258024eef8d6da7f.png)](https://intermag.org/register)

Got your ticket, but still can’t access the event?

Contact us and our team will look into it.

Accelerated materials development has gained interest in the research community as this approach can generate large amount of data in short period of time, and models built from this data can optimize the properties of the material for specific engineering applications. One such material is soft magnetic material which are widely used in electric motors, generators, transformers, inductors, etc. To model and optimize the properties, machine learning can be deployed. We present preliminary findings of the data mining of the literature for the Fe-Co-Ni alloy system. The processing conditions, properties, and compositions were obtained from the literature. The use of a machine learning tool to predict the properties based on composition, processing parameters, and structural information is described. Introduction: Globally, in the past two decades, total energy consumption has increased exponentially and electric motors account for a significant fraction of the total power consumption[1]. Soft magnetic materials play an important role in energy conversion and are widely used in electric motors, transformer cores, electric vehicles, inductors, etc [2]. However, commercially available soft magnetic materials do not have the optimum balance of properties needed in high frequency electric motors operating in extreme environments. Hence, machine learning based magnetic property prediction, optimization and design of soft magnetic materials has gained attention [3-5]. We build a Fe-Co-Ni based metallic soft magnetic materials database from literature and use a neural network algorithm [6, 7] to optimize properties. Database and Machine Learning: A database of 891 data entries comprising magnetic, mechanical, and electrical properties of various composition of Fe-Co-Ni alloys processed at various conditions was compiled from relevant literature. To curate this database, 55 references were compiled, including standard books, handbooks, and relevant publications. The atomic % of other elements in the alloys was restricted to maximum of 10%. Further, the database was preprocessed to convert the weight % to atomic % of the elements, to convert alphanumeric type of material and processing condition entries to numerical, and to calculate grain size from coercivity and yield strength of the alloys. This preprocessed database was used to train the machine learning tool with input variables: (a) composition, (b) type of material (categorical), (c) processing parameters like treatment temperature and time, cooling rate, % reduction in area (% r.a.) either by cold rolling or hot rolling, reheating temperature and time, etc., (d) grain size, and (e) volume fraction of phases (FCC, BCC, HCP). The output properties were saturation magnetization, log(coercivity), log(maximum permeability), log(electrical resistivity), yield strength, tensile strength, log(elongation), Vickers hardness, and cost of the material. The quality of fit, coefficient of determination (R2) values was determined through cross-validation. Using the trained model, properties of various compositions were predicted. Results and Discussion: Figure 1 shows the R2 values from cross-validation and the uncertainty in prediction for the output parameters. The algorithm was able to predict the properties in good agreement with the literature data. However, the prediction for electrical resistivity and elongation were not as good as that of other properties. This can be attributed to the lack of the data and complex behavior of the properties with the input parameters. The trained model was used to predict the properties of various Fe-Co-Ni alloys with the following conditions: cold rolled sheets with 95% r.a., annealed at 1000oC for 2 hours, and furnace cooled. The predicted saturation magnetization for the above specified conditions reveals a complex interplay between the properties, hence there it could be possible to design a soft magnetic material with improved mechanical strength. Conclusion: Using this robust neural network model and data mining, preliminary results relevant to the development of a Fe-Co-Ni based soft magnetic material with optimal combination of properties could be obtained. Acknowledgement: This work is supported by the AME Programmatic Fund by the Agency for Science, Technology and Research, Singapore under Grant No. A1898b0043, and the Royal Society.

**References:**

[1] R. Saidur, Renewable and Sustainable Energy Reviews, vol. 14, no. 3, p. 877-898 (2010) [2] V. Chaudhary, S.A. Mantri, R.V. Ramanujan, et. al., Progress in Materials Science, vol. 114, p. 100688 (2020) [3] Y. Wang, Y. Tian, T. Kirk, et. al., Acta Materialia, vol. 194, p. 144-155 (2020) [4] J. Nelson, and S. Sanvito, Physical Review Materials, vol. 3, no. 10, p. 104405 (2019) [5] J. Konieczny, L. Dobrzañski, B. Tomiczek, et. al., Archives of Materials Science, vol. 106, p. 106 (2008) [6] B.D. Conduit, N.G. Jones, H.J. Stone, et. al., Scripta Materialia, vol. 146, p. 82-86 (2018) [7] B. Conduit, N.G. Jones, H.J. Stone, et. al., Materials & Design, vol. 131, p. 358-365 (2017)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/0143b4b4607cd37cafeda7e308e49281.jpg)
Figure 1: Coefficient of determination (R2) values and the uncertainty in prediction of the properties, i.e., saturation magnetization (Ms), coercivity (Hc), Curie temperature (Tc), maximum permeability (m), tensile strength (T.S.), yield strength (Y.S.), elongation (El.), Vickers hardness (Hv), and cost (from left to right).

 Data Mining based development of Fe-Co-Ni soft magnetic material

There has been renewed interest in recent years to accelerate materials development beyond traditional approaches. A combination of both machine learning and high-throughput experiments can be used for predicting material properties and designing compositions beyond what is currently known. Herein we report the use of a computational tool, Alchemite™, to mine for important processing parameters of Fe-Si-Al alloys from a data set curated from published experimental results. The preliminary calculations suggest that this is a viable method to develop new Fe-Si based alloys. Introduction: Silicon steels (Fe-Si) are an important class of materials as they are widely used in applications like electric motors and transformers. Currently, 3.2 wt.% Si is widely used due to (i) good balance of electrical and magnetic properties, and (ii) ductility requirements in traditional processing methods.1 Recent trends have pointed to higher Si content of up to 10 wt.%, with an addition of small amounts of aluminum (Al) to improve material performance. Due to the small literature, it is imperative that we use machine learning to explore higher Si compositions and their processing methods to obtain a good balance of soft magnetic properties, electrical properties and mechanical properties. Data Set and Machine Learning Model: A typical machine learning model comprises three parts: training data, attributes for describing the material, and the machine learning algorithm to map the attributes to properties. The Fe-Si-Al data set was compiled of reported experiment values from 40 references (IEEE Ferromagnetism Handbook2 and 39 journal references, published between 2000 – 2020), resulting in a total of 572 entries. The attributes that were selected as input parameters to describe the material were (i) Composition, (ii) Type of material – like ingots, sheets or powder etc., (iii) Final thickness of the material, heat treatment conditions (iv) Treatment temperature, (v) Treatment time and (vi) Cooling rate, (vii) Frequency and (viii) Magnetic flux density. The output parameters comprised various soft magnetic, electrical and mechanical properties. Alchemite™ is a machine learning technology commercialized for materials and industrial chemicals design through Intellegens.3 The artificial neural network trains from the data set provided and predicts the selected material properties. The coefficient of determination (R2) values was obtained to determine the consistency of the data and predictions. Results and Discussion: Figure 1 shows the R2 values for the input parameters. The machine learning tool showed good predictions for most properties, although mechanical properties were not as well predicted (R2&lt;0.8). This is expected as there is a gap in the reported literature. More work will be done to address this gap, by means of improving the data set through theoretical calculations and high-throughput experimental methods. We studied the machine learning model parameters to reveal the most important variables for each output parameter: The frequency of operation affects total core loss greatly, like observations in alternating current (AC) applications – core loss is higher at increased operating frequency. To mitigate such effects, electrical resistivity must be increased – by controlling material thickness, grain size, and composition. Next, the type of material strongly affects the coercivity. The coercivity is affected by the grain size and composition, and this is in turn is affected by the method of fabrication and subsequent processing. The tensile strength is sensitive to the cooling rate because it affects the formation of different phases (A2, B2, and D03). It is reported that the ordering of phases (in B2 and D03) can interact with dislocations, resulting in a strengthening effect which decreases ductility.1 The phases formed also depend on the Si content, as reflected by the correlation between yield strength and Si content. The above highlights how the various input attributes are interrelated in affecting the output properties, and physical insights this can deliver. This underpins the main difficulty in traditional trial and error experiments and the mammoth task to undertake if it is to be done manually. Conclusions: The results show that the use of Alchemite™ for the development of Fe-Si-Al alloys are robust and promising, as it can capture property-processing relationships and highlight gaps in the data set. More work will be focused on improving the data set and high-throughput experiments performed to compare the results obtained with the predicted values. This will enable us to add to knowledge on achieving optimized and balanced properties in Fe-Si based alloys. This work is supported by the AME Programmatic Fund by the Agency for Science, Technology and Research, Singapore under Grant No. A1898b0043 and the Royal Society.

**References:**

[1] G. Ouyang, X. Chen, and Y. Liang, Journal of Magnetism and Magnetic Materials, Vol. 481, p.234–250 (2019) [2] RM Bozorth, Ferromagnetism. (IEEE Press, 1993) [3] https://intellegens.ai/ (accessed January 2021)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/55c12021610e152d25b771cea3e2a50e.jpg)
Fig. 1: Coefficient of determination values of output properties from machine learning predictions. The properties from left to right are: W – Total core loss, μ – Permeability, Hc – Coercivity, Ms – Saturation magnetisation, Tc – Curie temperature, ρ – Electrical resistivity, T.S – Tensile strength, Y.S. – Yield strength, El. – Elongation, Hv – Hardness and Cost.

 Data Mining Approach to Development of Iron-Silicon Soft Magnetic Alloys

1Introduction Manufacturing of electrical machines, in general, involves cutting of electrical steel sheets to appropriate sizes. Different cutting techniques such as punching, electrical discharge machining (EDM) and laser cutting are popular. These methods cause damage inside the material close to the cutting edge, which results in deterioration of magnetic properties [1]. Existing studies are based on measurement result by Epstein frame, Ring sample and single-sheet tester. However, these methods do have problems, causing error when analyzing influence of manufacture on material properties[2]. For example, the such non-ideal factors as overlapping joint causes significant eddy current loss especially at high frequency, which may make effect of manufacture effect negligible. In order to obtain more accurate measurement results, this paper aims to propose a new method to clarify the cutting effect on magnetic properties of silicon steel, eliminating those non-ideal factors, and to find out mechanism behind the deterioration of magnetic properties based on macroscopic magnetic measurement and microstructure observation. 2Effect of Cutting Methods on Magnetic Properties of Electrical Steel 2.1Macroscopic Magnetic Measurement The effect of cutting on the electrical steel sheets is analyzed by magnetic measurement on steel strips of different widths. The magnetic test samples were 35WW270 electrical steel lamination (300 mm×30 mm×0.35 mm). Half of the samples were cut along rolling direction while the other half were in the transverse direction. Then the samples have been cut along their length into different width by shearing, EDM, laser cutting, and glued up with polyimide tapes. Magnetic measurements are usually performed on electrical steel samples with Epstein frame. Nevertheless, the Epstein frame has some intrinsic weaknesses. One of them is that the flux density and specific total loss is uneven near the corners. The Epstein frame can be divided as uniform area, transitional area and overlapping area. In order to eliminate the impact of overlapping area and transitional area, two Epstein frames were designed as Fig 1, E(25), 25cm (standard) and E(12.5), 12.5cm (non-standard) Epstein frames, which have identical corner areas and transitional areas. The only difference in size is that the uniform area of E(12.5) is shorter than E(25). The same steel sheet (300mm length *30mm width) were used in both Epstein frames and their total absolute loss was measured. Magnetic measurement are performed following standard IEC: 604004-2. It can be assumed the absolute loss of corner and affected area of E(25) and E(12.5) is equal because of the identical corners and affected area. Then the only difference in absolute power loss between the two Epstein frames is due to the difference in absolute loss of the different uniform areas. The magnetic properties of the samples were measured at 50-800 Hz, and the results at 50 Hz were shown in Fig 2. When B = 1 T and frequency is 50 Hz, compared with EDM, the iron loss of samples with shearing increased by 5.6% and that with laser cutting increased by 32.6%. It can be found that the difference decreased at a higher frequency.The iron loss can be divided into static loss and dynamic loss. With the frequency increasing, dynamic loss takes more share of total iron loss[3]. Therefore, it can be assumed that the effect of cutting stresses on static loss is greater than that on dynamic loss. 2.1.1Microstructure Observation The steel samples were prepared by grinding on 400, 800, and 1200 grit SiC papers and polishing using 3μm diamond paste to obtain a mirror-like surface. Specimen microstructure was examined by scanning electron microscopy (SEM). Fig 2 shows the microstructure of the samples with different cutting methods observed by SEM. There are different contrast effects due to the plastic deformation near the cutting edge. It can be seen that the width of damaged area of EDM is about 20 μm, smaller than that of shearing (83 μm). And it is obvious that there is melting or heat affect zone (108 μm) in the immediate proximity of the cut edge due to laser cutting procedure, which leads to the worst magnetic properties of samples with laser cutting. 3Conclusion This paper has compared and analyzed the effect of different cutting methods on the magnetic properties of electrical steel by double Epstein frames. It is found that EDM has the least influence on the sample, followed by shearing, and laser cutting has the greatest influence. The laser cutting effect is the worst, that is becacuse that there is no cooling in the cutting process, while EDM has coolant flow. The microstructure of the samples was observed by SEM. The results show that the macro measurement results are consistent with the micro observation results.

**References:**

&lt;!--[if supportFields]&gt;&lt;spanlang=EN-US&gt;&lt;span style='mso-element:field-begin'&gt;&lt;/span&gt;&lt;spanstyle='mso-spacerun:yes'&gt; &lt;/span&gt;ADDIN EN.REFLIST &lt;span style='mso-element:field-separator'&gt;&lt;/span&gt;&lt;/span&gt;&lt;![endif]--&gt;[1] H. Naumoski, "Investigation of the influence of different cutting procedures on the global and local magnetic properties of non-oriented electrical steel," Journal of Magnetism and Magnetic Materials, vol. 392, pp. 126-133, 2015. [2] Z. Xiaoyang, "Study on Measurement and Simulation Method of Magnetic Properties of Electrical Steel Sheets Considering Influence of Cutting Method," Shenyang University of Technology, 2016. [3] W. D. Chen J, Cheng S, "Modeling of Temperature Effects on Magnetic Property of Nonoriented Silicon Steel Lamination," IEEE Transactions on Magnetics, vol. 51, no. 11, pp. 1-4, 2015. &lt;!--[if supportFields]&gt;&lt;span lang=EN-US style='font-size:12.0pt;font-family:"Times New Roman",serif;mso-fareast-font-family:宋体;mso-bidi-theme-font:minor-bidi;mso-ansi-language:EN-US;mso-fareast-language:ZH-CN;mso-bidi-language:AR-SA'&gt;&lt;spanstyle='mso-element:field-end'&gt;&lt;/span&gt;&lt;/span&gt;&lt;![endif]--&gt;

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/4befe7ab34ce100a7257c4a4004b0ad8.jpg)

![](https://assets.underline.io/uploads/markdown_image/1/image/a40e5a0db3f0e78ca813dc19a706c8a2.jpg)

 Effect of Cutting Methods on Magnetic Properties of Electrical Steel

CoFeB is one of the most extensivity studied magnetic materials due to its atypical properties such as structurally smooth growth [1], soft magnetic properties [2], high spin polarization [3], and very low Gilbert damping [4], which makes it especially suitable for magnetic tunnel junction devices [5]. Numerous researches have proclaimed that thermal annealing is a decisive measure for a high performance of CoFeB based magnetic tunnel junction devices. Therefore, it is of utmost importance to understand the influence of thermal annealing on this alloy. In this work, the crystallisation of Co-Fe-B alloys triggered by thermal annealing was investigated by X-ray diffraction techniques and scanning electron microscopy, as well as spectroscopic ellipsometry and magneto-optical Kerr effect spectroscopy for annealing temperatures ranging from 300°C to 600°C. The transformation of ~100 nm thick CoxFe(80-x)B20 films from amorphous to polycrystalline was revealed by the sharpening of spectral features observed in optical and magneto-optical dielectric function spectra. These features are ascribed to direct inter-band transitions due to the hybridization of p- and d orbitals of Co-Fe alloys in bcc crystalline phase. Cross-sectional scanning electron microscopy of Co-Fe-B layers annealed at 600°C further confirmed that in the case of a Pt capping layer, the crystallization starts at the interface of CoFeB and Pt, and expands for a thickness, which is consistent with the vertical coherence length of the crystallites determined from XRD. The influence of B on the dielectric function was assessed both experimentally and by optical modelling. By analysing the Drude component of the optical dielectric function, a consistent trend between the charge carrier scattering time/resistivity and the annealing temperature was observed, in agreement with the electrical investigations by means of the four-point-probe method. The result obtained from this study were recently published in ref. [6].

**References:**

1. D. D. Djayaprawira, K. Tsunekawa, M. Nagai, H. Maehara, S. Yamagata, N. Watanabe, S. Yuasa, Y. Suzuki, and K. Ando, Appl. Phys. Lett. 86, 92502 (2005). 2. H. Hauser and R. Grössinger, J. Appl. Phys. 85, 5133 (1999). 3. S. X. Huang, T. Y. Chen, and C. L. Chien, Appl. Phys. Lett. 92, 242509 (2008). 4. C. Bilzer, T. Devolder, J.-V. Von Kim, G. Counil, C. Chappert, S. Cardoso, and P. P. Freitas, J. Appl. Phys. 100, 053903 (2006). 5. T. Devolder, J.-V. Kim, L. Nistor, R. Sousa, B. Rodmacq, and B. Diény, J. Appl. Phys. 120, 183902 (2016). 6. A. Sharma, M. A. Hoffmann, P. Matthes, O. Hellwig, C. Kowol, S. E. Schulz, D. R. T. Zahn, and G. Salvan, Phys. Rev. B 101, 054438 (2020).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/c0dc6dc54b8645942697748105c792f5.jpg)
The polar Kerr effect measured polarisation rotation (θK) spectra for a Pt capped 100 nm thick Co40Fe40B20 film before and after annealing at various temperatures.

![](https://assets.underline.io/uploads/markdown_image/1/image/c008b8812afe925d41bc890b4fc5cea1.jpg)
SEM micrograph collage of substrate/ Co40Fe40B20/ Pt before and after annealing at 600°C, recorded in a FIB trench at 36° stage tilt.

 Crystallisation of optically thick films of CoxFe(80-x)B20: evolution of the (magneto-) optical and structural properties

Fe-Ga alloy is an advanced magnetostrictive material for actuators and sensors in terms of combining excellent mechanical and magnetostrictive properties. It is desirable to produce η(&lt;100&gt;//RD) textured Fe-Ga sheets due to the magnetostriction anisotropy with the largest coefficient along &lt;100&gt; direction and the serious eddy current loss in high-frequency use 1,2. The secondary recrystallization Goss ({110}&lt;001&gt;) texture and large magnetostriction coefficient were mainly achieved in Fe-Ga aaloy thin sheet with the thickness of 0.3~0.5mm, by the combination of micron-sized NbC particles and surface energy effect in high-temperature annealing 3,4, as well as the initial sharp &lt;100&gt;-oriented columnar grains by directional solidification 5. Since the eddy current loss is proportional to the square of the sheet thickness, the thinning of the sheet thickness can improve the energy conversion efficiency significantly. However, the secondary recrystallization of Goss texture significantly deteriorated in the Fe-Ga alloy sheet with a thickness of less than 0.3 mm due to the insufficient pinning force from the micron-sized NbC particles 6. The introduction of surface energy effect from H2S or S element, as well as the initial columnar crystals by directional solidification 7, cannot guarantee the complete secondary recrystallization in Fe-Ga alloy sheet with the thickness less than 0.3 mm. Qi et al 8 supposed the 0.10-mm Fe-Ga alloy ultra-thin sheets were prepared by rolling the 0.3 mm secondary recrystallized sheets, the strong cube texture and magnetostriction of 140 ppm were obtained after annealed for 2 h at 1200 °C under a flowing argon–hydrogen mixture. However, the preparation process is complicated and the incomplete secondary recrystallization restricts the magnetostriction coefficient. Therefore, it is necessary for the realization of complete secondary recrystallization in the Fe-Ga alloy sheet with a thickness of less than 0.3 mm. In the present study, the Fe-Ga ultra-thin sheets with the thickness of 0.10–0.25 mm were prepared via two-stage cold rolling method. The composite inhibitors composed of nanometer-sized sulfide and carbonitride are dispersedly precipitated during hot rolling and subsequent annealing, which provides effective pinning force for the normal growth of matrix grains. The gradually dissipated inhibition force during high-temperature annealing promotes a few exact Goss grains to grow abnormally by consuming primary recrystallized matrix grains textured by γ-fiber. Centimeter-sized secondary recrystallization Goss grains and large magnetostriction coefficient as high as 240 ppm is obtained in Fe-Ga alloy ultra-thin sheet without surface energy effect. The result indicates that complete secondary recrystallization can be realized based on the precise design and control of nano-sized composite precipitates and primary recrystallization microstructure/texture in Fe-Ga alloy ultra-thin sheet by conventional rolling and annealing methods.

**References:**

1. S. M. Na and A. B. Flatau, Scripta Mater. Vol., 66, p.307-310 (2012). 2. J. H. Li, X. X. Gao, J. Zhu, T. Xia and M. C. Zhang, Scripta Mater. Vol., 63, p.246-249 (2010). 3. C. Yuan, J. H. Li, X. Q. Bao and X. X. Gao, J Magn Magn Mater. Vol., 391, p.145-150 (2015). 4. S. M. Na, K. M. Atwater and A. B. Flatau, Scripta Mater. Vol., 100, p.1-4 (2015). 5. C. Yuan, J. H. Li, X. G. Bao and X. X. Gao, J Magn Magn Mater. Vol., 374, p.459-462 (2015). 6. S. M. Na and A. B. Flatau, AIP Adv. Vol., 7, p.056406 (2017). 7. J. H. Li, C. Yuan, Q. L. Qi, X. Q. Bao and X. X. Gao, Metals. Vol., 7, p.36 (2017). 8. Q. Qi, J. Li, X. Mu, Z. Ding, X. Bao and X. Gao, J Mater Sci. Vol., 55, p.2226–2238 (2019).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/326557a3327ec6e86a0e54601fff5ed3.jpg)
Orientation image maps of Fe-Ga ultra-thin sheets annealed at 950°C (a), 1000°C (b), 1100°C (c), and macrostructure after final annealing (d), as well as the variation of magnetostriction coefficients (λ//, λ⊥) with magnetic field annealed at 1000°C and 1100°C (e)

 The secondary recrystallization texture and magnetostriction in Fe-Ga alloy ultra-thin sheet

Grain-oriented (GO) steel sheets increasingly face novel applications, like the ones enforced by the emerging smart grid technologies and the related medium-to-high frequencies conversion devices and those connected with the development of highly efficient low-noise rotating machines [1-3]. Comprehensive knowledge of the material behavior, going beyond the standard assessment of its properties at power frequencies along the rolling direction (RD), is therefore appreciated in the practice of machine design. This requires both experiments made upon broader than usual range of frequencies [4] and the investigation of the complex anisotropic response of the GO sheets and the related 2D magnetization process [5]. Such a process is shown to consists in the balanced contributions by moving [001] directed 180° domain walls (dws) and 90° dw transitions towards the [100] and [010] phases. It is then observed that, with the applied field leaving the RD, not only the magnetic losses suffer a sharp increase, but also a strong geometry dependent effect, under both static and dynamic regimes. This descends from the interference of the demagnetizing field, invariably arising in Fe-Si single crystals, but for closed samples cut along the &lt;100&gt;, &lt;110&gt;, and &lt;111&gt; axes. Consequently, the popular approach to GO characterization using Epstein strips cut at different angles θ to RD can provide the intrinsic properties of the material only for θ = 0° (RD) and θ = 90° (TD). This is ill-suited to straightforward use in those cases, like the rotating machine cores, where directions other than RD and TD are involved. However, the experimental knowledge of the geometry-independent RD and TD magnetization curves can be usefully exploited, following the lines of the Néel’s phase theory, to reconstruct the same curves measured on Epstein strips cut along a generic angle θ [6]. The same applies to the DC hysteresis loops and their area, once the fundamental role of the demagnetizing field is recognized. One can also emulate an infinitely extended sheet, the ideal configuration leading to the intrinsic material response, by adopting an X-stacked sheet configuration, where flux continuity across the sheet edges can be achieved, resulting in a net magnetization variation both along the applied field (i.e., the strip edges) and orthogonal to it. Also in this case the DC properties become predictable by starting from the RD and TD magnetic properties [6]. Any other sample geometry will then be fully represented by or will be intermediate between the Epstein and the X-stack configurations. In this work, we provide a general approach to DC and AC (1 Hz - 200 Hz) magnetic hysteresis loop and losses in Epstein and X-stacked HGO sheets. The experiments are made using either the standard Epstein frame or a single sheet tester, where 120 mm wide 300 mm long X-stacked sheet samples are inserted in a laminated flux-closing yoke. A phenomenological predicting method is devised, which relies on the pre-emptive knowledge of the behavior of hysteresis loop and energy loss independently measured under sinusoidal induction in the RD- and TD-cut Epstein strips. We treat, in accordance with magneto-optical observations, the magnetization process unfolding for generic angle θ as the result, dictated by applied, demagnetizing, and eddy current fields, of two mechanisms: 1) Displacement of the 180° dws, the process pertaining to the RD cut sheets and strips; 2) Motion of 90° dws, converting the antiparallel slab-like [001] domains into [010] and [100] domains, and vice versa. The frames in Fig. 1 qualitatively show an example of domain structure in an X-stacked sheet at two instants of time along a major hysteresis loop (peak polarization Jp = 1.45 T). The antiparallel [001] domain structure observed at J = 0, largely disappears upon attaining J = 0.87 T. With this configuration, only a faint demagnetizing field is expected to arise at the sample edges and a net 2D magnetization variation is observed. By taking then, for a given Jp, the experimental energy loss and the hysteresis loops pertaining to the RD and TD samples, obtained at JpRD = Jp cos(θ) and JpTD = Jp sin(θ), and realizing that the fractional sample volume v180(t) occupied by the [001] phase is related to the same quantity v90(t) = √2 JTD /Js associated with the [010] and [100] domains as v180(t ) = 1 – v90(t), we calculate loss and loop for any given θ value. An example of so-obtained energy loss W(f) at 50 Hz across a range of Jp values on 0.288 mm thick high-permeability GO Epstein strips cut at different angles θ to RD is provided in Fig. 2. The experiments show that W(θ) peaks around θ = 75°. The predicting approach to W(θ) is based on the experimental knowledge of the energy loss measured at the same frequency in the RD and TD strips for JpRD = Jp cos(θ) and JpTD = Jp sin(θ). This associates with the calculation of the hysteresis loop. A more involved approach is required by the W(θ) prediction in the X-stacked samples, where the simplifying assumption of zero magnetization across the sheet width does not hold.

**References:**

[1] T. Belgrand, R. Lemaître, A. Benabou, J. Blaszkowski et C. Wang, AIP Advances 8, 047611 (2018). [2] G. Parent, R. Penin, J. P. Lecointe, J. F. Brudny, and T. Belgrand, IEEE Trans. Magn. 49, 1977 (2013). [3] S. Lopez, B. Cassoret, J. Brudny, L. Lefebvre, and J. Vincent, IEEE Trans. Magn. 45, 4161(2009). [4] M. A. Shamsuddin, F. Rojas, R. Cardenas, J. Pereda, M. Diaz, and R. Kennel, Energies 13, 2319 (2020). [5] W. Pluta, IEEE Trans. Magn. 52, 6300912 (2016). [6] F. Fiorillo, L. R. Dupré, C. Appino, and A. M. Rietto, IEEE Trans. Magn. 38, 1467 (2002).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/6b5cb05f0e84b50643df6d3ceb985c44.jpg)
Fig. 1. X-stacked GO sheet, cut at 75° with respect to the RD. The [001] antiparallel slab-like domain structure found in the demagnetized state (J = 0) is converted by 90° dw motion into symmetric [100] and [010] structures under increasing applied field (Jp = 1.45 T).

![](https://assets.underline.io/uploads/markdown_image/1/image/853d1d39b26e5ad4a2c3c620a36c162b.jpg)
Fig. 2. Energy loss at 50 Hz measured versus Jp and θ in Epstein strips. Solid lines and symbols: experiments. Dashed lines: prediction by a weighted combination of the 50 Hz RD and TD loss figures.

 The 2D Magnetization Process in HGO Fe-Si Sheets

Increasing the efficiency of electrical machines is a global objective. One way to contribute to its fulfilment is to reduce iron losses of soft magnetic materials within their magnetic circuits (stator, rotor, core, …). Improvement of soft magnetic material properties, especially Grain-Oriented Electrical Steels (GOES) based on iron and 3% silicon, is possible using surface laser treatments through the magnetic domain refinement technic and introduction of favorable stress [1-2]. These improvements are classically obtained for unidirectional excitation fields parallel to the rolling direction, the pronounced easy magnetic axis of GOES. However, in appliances such as rotating electrical machines, the flux lines are not always parallel to this preferred configuration (ex: in the teeth) and can also rotate (ex: in the yoke). In the literature, papers address the development of the expression and measurements of 2-D-magnetic properties [3], but the behavior of laser treated GOES under rotational and parallel to transverse direction fields remains slightly explored [4] and can be investigated further. Indeed, advanced pulsed laser technologies have been proven to improve magnetic [5-6] and magneto-mechanical [7] properties significantly under unidirectional field along the rolling direction. They include irradiation and scribing processes but also a new laser process called ablation with ultra-short laser pulses [5]. Therefore, in this research work, the effects of pulsed laser irradiation, scribing and ablation on GOES under transverse and rotational fields are presented. The objective is to optimize the vector behavior of GOES. The study focuses on power losses and B-H curves. The considered material is a laboratory grade of 0,28mm thickness with a CARLITE coating of 3-4µm thickness. The experimental plan includes 6 laser sets of parameters. The selection was made to enable comparisons between the types of laser processes (irradiation, scribing or ablation) and regarding the power loss reductions in the rolling direction. The main configurations were based on reference [5] in which the study was conducted with unidirectional excitation field parallel to the rolling direction on 150x150mm2 samples. In the present work, power losses have been measured in both rolling and transverse directions with a Single Sheet Tester (SST) and in rotational field with a Rotational Power loss Tester (RPT). An accuracy study will be detailed in the extended paper. So as to avoid any sample dispersion, measurements were carried out systematically on the same samples before and after laser treatment with the same setups (SST for 150x150mm2 samples and RPT for 60x60mm2 samples). The rotational power losses were obtained by considering the average of Clock-Wise (CW) and Counter-Clock-Wise (CCW) measurements and compared to the sum of unidirectional power losses. Thanks to loss model and B-H curve representation, while separating each direction but also the static and dynamic contributions, the impact of various laser parameters will be analyzed separately on scalar and vector magnetic properties as a function of working conditions. Additionally, all samples have been observed at each step (before and after laser treatment) with a Magneto-Optic Indicator Film technic (MOIF), which is very adapted for GOES’s magnetic domains observations. This will be illustrated in the final paper. Both macroscopic and microscopic analysis will be helpful to understand the reasons for opposite or simultaneous improvements in case of unidirectional or rotational fields. Concerning RPT measurements, rotational power losses reductions are reported for several laser sets of parameters (to be compared) and for several Polarization/Frequency couples as shown in figures 1 and 2. By using the pre-selected laser treatments, magnetic properties have been improved with iron losses reduction rate up to -12% at 50Hz&1T and up to -7% at 500Hz&0.5T in comparison with non-laser treated material for one of the selected sets of parameters. Further measurements will be carried out by the authors by improving the laser parameters (laser power and patterns), which might enhance the actual results and reduce even more significantly power losses. In the extended paper, measurement results (SST, RPT) will be presented with more details. Comparisons and discussions about the impact of considered laser treatments on GOES measured in both unidirectional and rotational fields on magnetic properties will be proposed as well. Acknowledgments: This work was supported by JEUMONT Electric and was carried out with the help of financing from the Association Nationale Recherche Technologie (ANRT). It was carried out in parallel with the ESSIAL project, which the authors would like to thank. The ESSIAL project is funding from the European Union’s Horizon 2020 research and innovation program under grant agreement No 766437. The authors would also like to thank the Aperam-Brazil company for having supplied the samples.

**References:**

[1] Y. Huang, W. Ming, M. Li et al., The International Journal of Advanced Manufacturing Technology, vol. 70, p. 1–9 (2014) [2] I. Petryshynets, F. Kováč, V. Puchý et al., AIP Advances, vol. 8, p. 047604 (2018) [3] Y. Maeda, H. Shimoji, T. Todaka and M. Enokizono, Journal of Magnetism and Magnetic Materials, vol. 320, p. e567–e570 (2008) [4] T. Kajiwara and M. Enokizono, IEEE Transactions on Magnetics, vol. 50, p. 1-4 (2014) [5] M. Nesser, O. Maloberti, J. Dupuy et al., Journal of Magnetism and Magnetic Materials, vol. 504, p. 166696 (2020) [6] E. Salloum, O. Maloberti, M. Nesser et al., Journal of Magnetism and Magnetic Materials, vol. 503, p. 166613 (2020) [7] E. Salloum, M. Nesser, O. Maloberti et al., conference MMM2019, Las Vegas, USA (2019)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/a2ce0b6b2f6b9c37b7f5c444b51e925b.jpg)
Fig.1 - Rotational power loss variation [%] after laser treatment at 50Hz for various polarizations (0.1T, 0.5T, 1T and 1.4T)

![](https://assets.underline.io/uploads/markdown_image/1/image/58aea06788288312a5bfb3fb25ed90e4.jpg)
Fig.2 - Rotational power loss variation [%] after laser treatment at 1T for various frequencies (50Hz, 150Hz, 500Hz and 1500Hz)

 Impact of Pulsed Laser Irradiation, Scribing and Ablation on 2-D Scalar and Vector Magnetic Losses and General Properties of Grain-Oriented Electrical Steels

Due to their texture, the magnetic characteristics of grain oriented (GO) steels depend on the angle between the applied magnetic field and the rolling direction RD. These GO steels exhibit advantageous magnetic characteristics, such as high permeability in the RD and relatively poor properties in the transverse direction TD. In order to obtain a better electromagnetic modeling of the electrical energy conversion systems using GO steels, the dissipative phenomena and the anisotropy must be reliably represented. One example is the case of the GO electrical steels used in stators of turbo-generators. In order to create an appropriate model, the associated magnetic losses have to be taken into account for any angle between the applied field and the RD. However, the problem of computing iron losses whatever the angle between the applied field and the RD has remained unsolved especially within the finite element method (FEM) framework. In this paper, a phenomenological iron loss model, recently proposed in [1], taking into account the anisotropy and nonlinearity of GO sheets has been successfully implemented in the L2EP FEM software baptized code_Carmel [2]. The model relies on the ‘loss separation’ approach. In this approach, which is based on the traditional decomposition proposed by Bertotti [3], the total losses are decomposed into three terms (hysteresis, classical and excess losses). The originality of the model concerns the first loss term i.e., the quasi-static losses dissipated per magnetization cycle, depending on the polarization level Jp and on the angle θ between the applied field and RD. The proposed quasi-static loss model considers the magnetization process and the evolution of the domain wall structure (dws) with the angle θ [4]. It is built from the two sets of W-Jp quasi-static experimental data obtained in the principal directions RD and TD and is based on the interactions between the main classes of magnetic domains, 180° and 90° dws, known as “Néel phases” [5] through a single analytical relationship involving the volumic fraction occupied, for any direction of the magnetic field, by these classes. This same principle is applied for the determination of the excess losses. At this stage, the corresponding input data are the excess losses measured in both RD and TD. Concerning the classical loss term, it simply takes the expression resulting from the classical eddy current theory which is independent of the angle θ. Indeed, the case of an infinite sheet of thickness e, with a linear constitutive law (µ independent of H) and conductivity σ, under a sinusoidal field of frequency f, allows an entirely analytical resolution of the magnetic diffusion equation. Finally, we get a description of the total losses W(f,Jp) as a function of the angle θ, without any adjustable parameter. The model has been validated on industrial sheets of EDF turbo-generators by means of simple study cases under periodic (cyclic) waveforms. Thus, we dispose of an efficient and reliable tool for modeling the magnetic losses of GO sheets within the FEM simulation environment. In order to validate the implementation of the developed model, a finite element analysis (FEA) has been performed using code_Carmel. A 3D linear magnetostatic simulation has been done using the magnetic vector potential formulation. A diagonal permeability tensor has been used to represent the anisotropic properties of the GO material. This tensor is formed assuming non-diagonal terms. The values of the tensor for the axes x and y were obtained from the characterization of the industrial GO steel C150-35S in the RD and TD, while for the axis z a very low relative permeability of ≈ 30 is assumed, as measured in [6]. Furthermore, the analyzed geometry corresponds to a GO sheet with dimensions of 10 cm x 10 cm and a thickness of 0.35 mm, surrounded by a coil along the x-axis. The iron loss calculation is performed in a section at the center of the sheet with an area of 1 cm x 1 cm. The elements at the center are subjected to a sinusoidal waveform of Jp of 0.5 T. Thirteen values of θ have been evaluated in this study (0°, 5°, 10°, 15°, 20°, 25°, 30°, 42°, 54.7°, 65°, 75°, 82.5° and 90°). They correspond to the angles characterized experimentally using the Epstein frame method with Epstein strips cut at different angles from the industrial GO steel sheet. Finally, from the distribution of H and J obtained in the FEA, the iron losses have been calculated in post-treatment. The main entries for the iron loss model were the hysteresis and excess losses in the RD and TD. In Table 1, an example comparing the static and dynamic losses obtained from the FEA against the experimental losses is given for some angles at 0.5 T. Further validations, analysis and discussions are envisaged in the extended version of the paper.

**References:**

[1] Carlo Appino, Enzo Ferrara, Fausto Fiorillo, et al., Journal of Magnetism and Magnetic Materials, vol. 500, (2019). [2] code_Carmel. [Online]. Available: https://code-carmel.univ-lille.fr/?q=fr/ node/15, accessed 2021 [3] G. Bertotti, IEEE Transactions on Magnetics, vol. 24, no. 1, pp. 621–630, (1988) [4] F. Fiorillo, L. R. Dupré, IEEE Trans. on Mag., vol. 38, no. 3, (2002) [5] L. Néel, J. Phys. Rad., vol. 5, pp. 241, (1944) [6] N. Hihat, J. P. Lecointe, O. Ninet, et al., International Journal of Applied Electromagnetics and Mechanics, vol. 46. pp. 349 - 354, (2014)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/0e5efc22699b2e5d1252a3fef02af167.png)
Table 1. Comparison of computed and experimental losses at 0.5 T

 Iron Loss Modeling of Anisotropic Soft Magnetic Steels in FEM Simulation Environment

Additive manufacturing (AM) via 3-D printing technologies have become a frontier in materials research, including its application in the development and recycling of permanent magnets1,2. The increasing criticality in availability of the rare earth minerals in magnets present a demanding challenge to the losses from conventional or subtractive manufacturing. AM allows for a minimal waste production and re-utilization of recovered rare earths in the magnet processing. In-situ alignment during 3D printing of magnetic materials has opened new horizons for manufacturing of complex permanent magnets3,4. The introduction of functionalized magnetic 3D printing (Fig. 1a) as an AM process yields several unique advantages including rapid prototyping of multi-directionally aligned magnetic systems, and reduced energy requirement due to the elimination of post-production alignment3. In this work, we have developed a mechanism to align magnetic materials using fused filament 3D printer with a novel magnetic field source architecture (Fig. 1b). The work addresses opportunities to integrate magnetic field into 3D printing process to enable printing, and alignment of anisotropic permanent magnets, without requiring further processing. The principle behind the analysis is rotation of magnetic particles in a molten matrix under low magnetic field. The alignment architecture was designed and optimized for weight and applied field. An in-depth finite element modeling and CAD was performed followed by prototyping of the magnetic field source (Fig. 1c-d). Several electromagnetic core models were developed using finite element modeling to obtain a field strength of &gt; 1 T with a magnetic material in the nozzle. The electromagnetic simulations were coupled with thermal analysis to obtain realistic transient thermal profiles. Design modifications were incorporated to improve the thermal performance of the models without compromising the electromagnetic output. The results predict models that could be operated over prolonged durations (&gt; 10 hours) at less than the rated temperature (80 oC) and at the rated current (5 A), while producing field strength of &gt; 1 T. As a future prospective, the model would be implemented as a prototype to be incorporated with the 3D printer. Magnetization vs. field measurements of extruded and printed Sm-Co (15 vol.%) in PLA and Nd-Fe-B/Sm-Fe-N composite (65 vol.%) in Nylon-12, prepared with and without magnetic field, confirmed alignment of magnetic particles (Fig. 2a-b). Field vs. alignment and printer temperature vs. alignment analyses were performed to understand the effects of process variables on the degree of alignment of the samples. Finally, a multiphysics model was developed, that couples fluid dynamics and electromagnetic interactions, to predict the degree of alignment (DoA) of a polymer bonded magnet printed under applied field. The model predicts the flow of magnetic particles in a viscous fluid through a nozzle under applied magnetic field. A particle-fluid interactive flow simulation was performed to model the flow regime of molten bonded magnet. The interactions between the drag, inertial, and magnetophoretic forces were analyzed to predict the particle trajectory. A torque balance was performed between the drag torque, magnetic torque on particles from the applied field, and torque from particle-particle interactions. The analysis was used to predict the degree of rotation of magnetic particles during printing. The simulated DoA of 0.68 compares well with the experimentally obtained for 65 vol.% NdFeB+SmFeN in Nylon-12. For 15 vol.% Sm-Co in PLA, the simulated DoA of 0.86 also compared well with 0.83 obtained experimentally (Fig.2c-d). This process can be used for any permanent magnet composition or hybrid magnets and presents a benchmark for application of this technology in industrial and commercial applications. This work is supported by the Critical Materials Institute (CMI), an Energy Innovation Hub funded by the U.S. Department of Energy (DOE), Office of Energy Efficiency and Renewable Energy, Advanced Manufacturing Office. Ames Laboratory is operated for the U.S. Department of Energy by Iowa State University of Science and Technology under Contract No. DE-AC02-07CH11358.

**References:**

1. C. Huber et al., Appl. Phys. Lett., 109, 162401 (2016) http://arxiv.org/abs/1605.07309. 2. L. Li, B. Post, V. Kunc, A. M. Elliott, and M. P. Paranthaman, Scr. Mater. (2017). 3. A. Sarkar et al., Addit. Manuf., 34, 101289 (2020) https://linkinghub.elsevier.com/retrieve/pii/S2214860420306618. 4. Y. Kim, H. Yuk, R. Zhao, S. A. Chester, and X. Zhao, Nature, 558, 274–279 (2018) http://www.nature.com/articles/s41586-018-0185-0.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/0f1fa7ee3edeb633b194223095ca2154.jpg)
Figure 1. a) Schematic of in-situ alignment mechanism for magnetic 3D printing, b) Representation of the prototyped 3D printer, c) Novel EM-core design with advanced cooling technology, and d) FEM simulation of c-core @ 5A current.

![](https://assets.underline.io/uploads/markdown_image/1/image/a0cec09893008e380b67cbc258cb5916.jpg)
Figure 2. a-b) MH loop for aligned magnetic samples, and c-d) Simulation validation.

 Advancing Additive Manufacturing of Bonded Permanent Magnets via in-situ Magnetic Field Alignment During 3D Printing

Today, the 3D-printing technology faces a new challenge - the Additive Manufacturing (AM) of functional magnetic materials, especially permanent magnets. AM should provide very good functional properties of the printed magnets, namely locally tailored remanent magnetization Mr and coercivity Hc. The highest magnetic performance is reached for Nd-Fe-B magnets based on the hard magnetic Nd2Fe14B phase, and on extrinsic properties (micro and nanostructure) mastered during the production. Ideal microstructure consists of magnetically decoupled grains of the hard magnetic RE2Fe14B (RE = Rare earth element) phase. The main challenge for Nd-Fe-B magnets, which arises during direct AM techniques, consists of an unsuitable microstructure appearing after re-melting of Nd-Fe-B precursor by the laser, followed by a fast solidification of the alloy. This usually leads to a very low coercivity in magnets made from commonly used commercial Nd-Fe-B alloy powders. Thus, one of the main obstacles in successful 3D printing of full-dense hard magnetic materials, is the engineering of a desired phase composition and the mastering of an appropriate microstructure. In the contrast to conventional Nd-Fe-B-based bulk alloys, a large HC has been found in annealed Pr-Fe-Cu-B compounds. The Pr2Fe14B phase is isostructural to Nd2Fe14B and the Pr-Fe-B and Nd-Fe-B ternary phase diagrams exhibit the same phases. By doping the system with Cu, additional phases can be formed in the sample and some of them affecting drastically the hard-magnetic properties of the magnet. Kajitani et al. [4] found a new grain-boundary phase with tetragonal structure (space group I4/mcm) and Pr6Fe13Cu stoichiometry in hot-pressed Pr17Fe76B5.5Cu1.5 alloys. Annealing at 500 °C leads to an increase in HC of 50 % compared to the hot-pressed state, which was associated to the formation of the antiferromagnetic grain-boundary phase. Further investigations by Marcondes et al. [5] proved the occurrence of the antiferromagnetic Pr3Fe13Cu phase and it was found that annealing at 500 °C improves the HC drastically due to the formation of the Pr3Fe13Cu phase at the expense of the Pr,Cu-rich grain-boundary phase. Recently, the occurrence of the RE6(Fe,Ga)14 within the grain boundary [6]–[8] of Nd-Fe-B permanent magnets was reported. The magnets show good hard- magnetic properties, but the role of the RE6Fe13(Cu,Ga) phase is not clear yet. Our studies explore the applicability of Pr-Fe-Cu-B based alloys for the use in Additive Manufacturing (AM) techniques to produce fully dense permanent magnets. Induction molten Pr17Fe76B5.5Cu1.5 alloys were annealed at high temperature (1000 °C for 5 hours), followed by a low temperature annealing (500 °C for 3 hours). The samples show the formation of soft magnetic Pr2Fe17 phase at high temperature accompanied by low coercivity. After a low temperature annealing, the mentioned Pr6Fe13Cu is forming (see Fig. 1) and an increase of coercivity can be observed. Based on these experiments, the composition has been optimized regarding the coercivity. For this, three pre-alloys (Pr6Fe13Cu, Pr2Fe14B, FeB) were prepared by induction melting and two compositional series by mixing the Pr6Fe13Cu with FeB or Pr2Fe14B were prepared by arc melting. The heat treatments were the same for all samples and the development of coercivity was characterized. The shape of the hysteresis is drastically changing within the sample series. High amount of the Pr6Fe13Cu phase leads to a shoulder and decreasing saturation magnetization, which indicates the non-ferromagnetic properties of the phase. The combination of Pr6Fe13Cu + FeB shows the largest coercvity of ~1250 kA/m which is comparable to a sintered magnet (without heavy Rare Earth elements). In both sample series, the formation of the reported Pr6Fe13Cu phase could be observed by SEM-EDX. The large coercivity in the bulk state makes this material interesting to use as stable precursors for AM of fully dense magnets. The material needs to be in powder form for techniques like SLM. Therefore, the hydrogen decrepitation (HD) process was successfully applied on high coercive samples. Afterwards, the material was suction casted which simulates the remelting and rapid solidification during the SLM process. After the aforementioned annealing, the coercivity is equal to the as-cast condition which demonstrates that the magnetic hardening mechanism is stable throughout the different preparation steps and the material will exhibit large coercivity after SLM. We thank the German Research Foundation (DFG) and the Collaborative Research Center/Transregio 270 HoMMage, Project ID No. 405553726, TRR 270, for making this work possible.

**References:**

[1] O. Gutfleisch, “Controlling the properties of high energy density permanent magnetic materials by different processing routes,” J. Phys. D. Appl. Phys., vol. 33, no. 17, pp. R157–R172, Sep. 2000. [2] T. G. Woodcock et al., “Understanding the microstructure and coercivity of high performance NdFeB-based magnets,” Scripta Materialia, vol. 67, no. 6. pp. 536–541, 2012. [3] G. Hrkac et al., “Impact of different Nd-rich crystal-phases on the coercivity of Nd-Fe-B grain ensembles,” Scr. Mater., vol. 70, no. 1, pp. 35–38, 2014. [4] T. Kajitani, K. Nagayama, and T. Umeda, “Microstructure of Cu-added Pr-Fe-B magnets: Crystallization of antiferromagnetic Pr6Fe13Cu in the boundary region,” J. Magn. Magn. Mater., vol. 117, no. 3, pp. 379–386, Dec. 1992. [5] P. V. P. Marcondes and R. N. Faria, “Microstructural studies on Pr-Fe-B-Cu magnets produced by upset forging of cast ingot,” Mater. Sci. Eng. A, vol. 272, no. 2, pp. 245–249, 1999. [6] K. Niitsu et al., “Magnetization measurements for grain boundary phases in Ga-doped Nd-Fe-B sintered magnet,” J. Alloys Compd., vol. 752, pp. 220–230, 2018. [7] G. Ding et al., “Coercivity enhancement in Dy-free sintered Nd-Fe-B magnets by effective structure optimization of grain boundaries,” J. Alloys Compd., vol. 735, pp. 795–801, 2018. [8] T. T. Sasaki et al., “Formation of non-ferromagnetic grain boundary phase in a Ga-doped Nd-rich Nd-Fe-B sintered magnet,” Scr. Mater., vol. 113, pp. 218–221, 2016.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/254a76c7d50f328f1a476ac33e1bda97.jpg)
Fig. 1: Microstructural evolution during the annealing treatment of Pr-Fe-Cu-B alloys. The sample is shown in as-cast condition (top) and annealing (bottom).

Batch fabrication of 50 µm thick anisotropic NdFeB micro-magnets
