The typical timescale for material discovery is remarkably long, taking between 10 – 20 years to propagate through idea conception, experimentation, optimisation, and deployment&lt;sup&gt;1&lt;/sup&gt;. Existing global challenges such as the climate emergency require rapid development of new materials on timescales that are incompatible with the traditional &lt;i&gt;linear &lt;/i&gt;material discovery approach. High-throughput approaches can be applied as a &lt;i&gt;parallel&lt;/i&gt; material discovery methodology, for which a single sample contains a library of different material compositions that can be rapidly screened for the realisation of new magnetic materials.&lt;br/&gt;&lt;br/&gt;We apply the high-throughput material discovery approach to the new class of materials known as High Entropy Alloys (HEAs). HEAs often consist of five or more constituent elements mixed in near equal quantities. The name is owed to the resulting high configurational entropy of the alloy, which contributes to suppressing the formation of intermetallic phases and stabilises simple FCC and BCC solid solutions. HEAs occupy the unexplored central regions of phase diagrams, and as such, have potential to provide disruptive materials. Already HEAs have exhibited promising soft magnetic properties such as high saturation magnetisation alongside high electrical resistivity, as well as obtaining nanocrystalline textures&lt;sup&gt;2,3&lt;/sup&gt;. However, the number of constituent elements and the various chemical compositions mean HEAs can be found in a very broad parameter space making it difficult to localise the search for useful compositions.&lt;br/&gt;&lt;br/&gt;This work has used combinatorial sputtering, to fabricate sample libraries containing composition variations of up to 35 at.% on a single Silicon wafer (Figure 1a). We investigate the (CoFeNi)&lt;sub&gt;1-x-y&lt;/sub&gt;A&lt;sub&gt;x&lt;/sub&gt;B&lt;sub&gt;y&lt;/sub&gt; series, where A and B are 3d/4d transition metals (with the addition of Si and Al). Systems studied include CoFeNiMnAl, CoFeNiMnSi, and CoFeNiMnV. We implement a program to model the composition variation across a 3” Silicon wafer with three sputter sources at different incidence angles with concurrent deposition (Figure 1b). The resulting sample library is characterised using a high-throughput magneto-optical Kerr effect (MOKE) magnetometer which has been developed to automatically map the Kerr voltage (which is proportional to the magnetic moment) and coercive field across this sample library as function of HEA composition (Figure 1c). These can then be combined to achieve magnetic property mapping within the chemical composition space (Figure 1d). Following this, XRD, SQUID magnetometry, FMR and magneto-transport are used to generate a complete structural and functional property description of selected compositions.&lt;br/&gt;&lt;br/&gt;The resulting methodology not only provides a scalable process for magnetic HEA fabrication and characterisation, but can also be paired with data driven machine learning material discovery strategies such as Materials 4.0&lt;sup&gt;4&lt;/sup&gt;. The large datasets necessary for machine learning are costly to procure and so far lacking in functional magnetic properties (e.g. &lt;i&gt;M&lt;/i&gt;&lt;sub&gt;s&lt;/sub&gt;, &lt;i&gt;H&lt;/i&gt;&lt;sub&gt;c&lt;/sub&gt;)&lt;sub&gt; &lt;/sub&gt;for which these high-throughput methods could provide.

**References:**

1. Y. Liu, T. Zhao, W. Ju and S. Shi, &lt;i&gt;J. Materiomics&lt;/i&gt; 3, 159–177 (2017).&lt;br/&gt;2. Y. Zhang, T. Zuo, Y. Cheng and P. K. Liaw,&lt;i&gt; Sci. Rep.&lt;/i&gt; 3, 1455 (2013).&lt;br/&gt;3. T. Zuo &lt;i&gt;et al.&lt;/i&gt;, &lt;i&gt;Acta Mater.&lt;/i&gt; 130, 10–18 (2017).&lt;br/&gt;4. R. Jose and S. Ramakrishna, &lt;i&gt;Appl. Mater. Today&lt;/i&gt; 10, 127–132 (2018).

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/646e3021d243cac1b425ee3cb6de2f04.jpg)
Schematic representation of the high-throughput thin film methodology applied to magnetic material discovery, including (a) combinatorial sputtering, (b) modelling the composition across the wafer, (c) a measured Kerr Voltage map, and (d) mapping of magnetic properties as a function of chemical composition.
