 Strain and ferromagnetic proximity induced spin reorientation transition in NiO

Ability to control the spin orientation in antiferromagnets (AFMs) has recently attracted a lot of attention [1]. In our recent work we performed systematic studies on magnetic properties of NiO in Fe/NiO/Cr/MgO multilayers for various Cr thicknesses [2]. We proved existence of a continuous strain-induced spin reorientation transition (SRT) in NiO from nearly out-of-plane direction in Fe/NiO/MgO to the in-plane direction in Fe/NiO/Cr. For ultrathin NiO layers the in plane direction of AFMs spins was determined to be perpendicular to Fe spins due to spin-flop interaction. In this contribution we studied magnetic properties of NiO in NiO/MgO(dMgO)/Cr(20 nm)/MgO(001) for different MgO thicknesses, dMgO. We also investigated how the adjacent ferromagnetic coverage layer influence the spin structure in NiO. X-ray Magnetic Linear Dichroism (XMLD) technique was used to determine magnetic ordering in NiO. The XAS spectra were collected using a linearly polarized x-ray beam for the Ni2+ L2 edge at normal (γ = 0°) and grazing (γ = 60°) x-ray incident angles. The XAS spectra were measured as a function of MgO buffer layer thickness for NiO/MgO/Cr, MgO/NiO/MgO/Cr and Fe/NiO/MgO/Cr. Figure 1 shows L2 ratio difference, defined as ΔRL2= RL2(γ = 0°) – RL2(γ = 60°), as a function of dMgO for NiO with different capping layers. For both, capped and non-capped NiO layers we noted an increase in ΔRL2 with an increase in dMgO. According to the previous studies [3] increase of ΔRL2 can be interpreted as enhancement of the out-of-plane component of NiO spins. Thus, our results show that insertion of MgO layer between NiO and Cr leads to development of out-of-plane NiO spin direction, which can be understand in terms of tensile strain exerted by MgO buffer layer on NiO. Interestingly, while there are no significant differences between ΔRL2(dMgO) dependences for MgO-capped and uncapped NiO layers (Fig. 1, circles, triangles), a change of ΔRL2 as a function of MgO thickness is much more pronounced for Fe/NiO/MgO/Cr (Fig. 1, stars). Moreover, only for Fe/NiO/MgO/Cr ΔRL2 changes a sign with an increase of dMgO which indicates that NiO spins undergo an SRT from in-plane to out-of-plane direction. To investigate the influence of Fe/NiO interactions on SRT in NiO a dedicated sample was prepared. Wedge-shaped Fe layer was grown on NiO(2 nm)/MgO(8.5 nm)/Cr(20 nm)/MgO(001), where the dMgO layer was chosen to be near the critical thickness of MgO for which SRT in NiO was observed. To elucidate if modulation of magnetic structure in NiO is influenced by magnetic properties of Fe or rather by strains from capping layer, half of the sample was capped with wedge-shaped Cr. Due to the small lattice mismatch between Cr and Fe (1.5%) strain-induced changes in magnetic properties of NiO should be similar for Cr/NiO/MgO and Fe/NiO/MgO. Prior to XAS measurement the sample was magnetized along the Fe[001] (NiO[110]) in-plane direction (φ = 0°) to study the influence of Fe magnetization on NiO spin structure. Figure 2(a) shows ΔRL2 dependence on dFe(Cr) for two azimuthal angles, φ. In case of Cr/NiO, for both φ = 0° and φ = 90° we noted no considerable ΔRL2 changes as a function of Cr thickness (dCr) (Fig. 2(a) circles, triangles). For Fe/NiO we noted a drastic difference in ΔRL2(dFe) dependence for φ = 0° and φ = 90°. Strong ΔRL2 dependence on dFe observed for φ = 90° and a lack of change in ΔRL2 as a function of dFe for φ = 0° was noted for Fe/NiO/MgO/Cr, which brings two conclusions. First, a change of sign in ΔRL2(dFe) obtained for φ = 90° proves that SRT from in-plane to out-of-plane direction in NiO can be obtained as a function of Fe thickness. Dependence of ΔRL2(dFe) on azimuthal angle in Fe/NiO/MgO together with a lack of ΔRL2 dependence on dCr in Cr/NiO/MgO prove that reorientation of NiO spins is not related to the strains exerted by capping layer, but to the magnetism of Fe layer. Second, a difference between ΔRL2(dFe) for φ = 0° and φ = 90° indicates that together with an increase in Fe thickness an in-plane anisotropy of NiO is developed. This conclusion was confirmed in XAS measurements collected as a function of φ (γ was set to 0) for different Fe thicknesses (Fig. 2(b)). While for dFe= 2 Å no change in the RL2(φ) was observed, for dFe≥8 Å we noted well-pronounced extrema in the RL2(φ) dependence for the NiO[110] and [1–10]. According to the previous studies [3], if the RL2 reaches an extremum when the polarization vector is parallel to the [110] NiO direction, the AFM spin alignment is determined from the maximum of the RL2. Thus, an in-plane component of NiO spins is perpendicular to the spins of Fe. Our results show that spin structure of antiferromagnet can be modulated by strain induced by the buffer layer and emphasize the role of adjacent ferromagnetic layer on the magnetic structure in AFM. This work was supported by the “Antiferromagnetic proximity effect and development of epitaxial bimetallic antiferromagnets – two routes towards next-generation spintronics” project, which is carried out within the Homing programme of the Foundation for Polish Science co-financed by the European Union under the European Regional Development Fund.

**References:**

[1] C. Song, Y.You and X.Chen, Nanotechnology, Vol.29, p.112001(2018) [2] A. Koziol-Rachwal, M. Slezak, M. Zajac, APL Mater., Vol.8, p.061107 (2020) [3] W. Kim, E. Jin, J. Wu, Phys. Rev. B., Vol.81, p.174416 (2010)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/3eb02b9b080b4178806eb96c5dd60035.jpg)
Fig. 1. XLD magnitudes of NiO in the NiO/MgO/Cr, MgO/NiO/MgO/Cr, Fe/NiO/MgO/Cr.

![](https://assets.underline.io/uploads/markdown_image/1/image/b44441a561c3ec343508212ae55e0015.jpg)
Fig. 2. a) XLD magnitudes of NiO in the Fe/NiO and Cr/NiO as a function of dFe(Cr), b) Ni RL2 (φ) as a function of polarization angle φ for Fe(2 Å)/NiO ,Fe(8 Å)/NiO, Fe(18 Å)/NiO and Fe(30 Å)NiO.
