Signal processing, conditioning, filtering and are becoming critical parts of RF communications. We have designed a magnonic Bragg filter with a tailored frequency response. A systematic procedure for arriving at the period of Bragg grating, excitation, probe region etc., has been formulated to simulate the expected spectral response. We simulate and analyze a 1D magnonic Bragg narrow band rejection filter at 28 GHz, the frequency allotted to India, in the 5G spectrum. The magnonic filter with 10 grooves has a pass band from 12 GHz to 50 GHz and a tuneable band gap with attenuation as high as 36 dB. Modulating the depth and the duty cycle of the magnonic crystal, we demonstrate that we could tune parameters like, the bandgap, rejection ratio and group velocity of the spin waves. The rejection efficiency of the filter at the frequency of 28 GHz is 90% higher compared to a signal of 40 GHz, in the pass band.&lt;br/&gt;INTRODUCTION&lt;br/&gt;5G mobile telecommunications operate above 24 GHz band and these signals suffer much higher path loss [1]. Magnons, or quanta of spin waves (SW) have been explored as information carriers and for computing [2] with the help of magnonic crystals (MCs). Experimental demonstrations show tuning of bandgaps in MCs, by varying parameters such as the applied magnetic field (H&lt;sub&gt;DC&lt;/sub&gt;), width, thickness [3, 4] etc. With extensive experimental investigations being pursued, we arrive at an optimized set of design procedures to estimate different simulation parameters. A magnonic Bragg filter (MBF) is designed to operate at 28 GHz and simulated using the micromagnetic simulation tool, MuMax&lt;sup&gt;3&lt;/sup&gt;. The tunability of bandgaps, rejection and group velocity with modulations of duty cycle and depth of the gratings are studied extensively to finally realize an optimized and highly efficient 1D MBF.&lt;br/&gt;DESIGN PROCEDURE&lt;br/&gt;The nonlinear dispersion relation between frequency(ω) and wavenumber(&lt;i&gt;k&lt;/i&gt;&lt;sub&gt;SW&lt;/sub&gt;) introduces a constraint in the filter design. We must invert ω(&lt;i&gt;k&lt;/i&gt;&lt;sub&gt;SW&lt;/sub&gt;), find &lt;i&gt;k&lt;/i&gt;&lt;sub&gt;SW &lt;/sub&gt;for a given excitation geometry, and then pick the Bragg wavelength(Λ). We must also use a broadband excitation to capture the full spectrum. Micromagnetics thus become computationally intensive, and a simple MBF simulation occupies terabytes of storage. Hence, we developed custom Go routines to extract the relevant spatially averaged and temporally sampled data from MuMax&lt;sup&gt;3&lt;/sup&gt; simulations [5]. For our purposes, we assume a strip of permalloy, with saturation magnetization 800 kA/m, exchange constant 1.3×10&lt;sup&gt;−11&lt;/sup&gt;J/m and damping constant α= 0.006 [6]. The backward volume spin waves configuration excites SWs along &lt;i&gt;x&lt;/i&gt;, parallel to H&lt;sub&gt;DC&lt;/sub&gt;, as in Fig.1(a). At ω=28 GHz, and with H&lt;sub&gt;DC&lt;/sub&gt;=54.9 kA/m (a convenient field value chosen for our future experiments), we obtained &lt;i&gt;k&lt;/i&gt;&lt;sub&gt;SW &lt;/sub&gt;= 0.145 rad/nm from the dispersion relation [7, Eqn(18)]. This corresponds to a wavelength λ&lt;sub&gt;SW &lt;/sub&gt;= 43.33 nm, and we choose Λ=21.6 nm to match this at normal incidence. A broadband small signal excitation of &lt;i&gt;h&lt;/i&gt;&lt;sub&gt;y&lt;/sub&gt;(x,t) with cut off values of &lt;i&gt;k&lt;/i&gt;&lt;sub&gt;c &lt;/sub&gt;= ±0.3 rad/nm and &lt;i&gt;f&lt;/i&gt;&lt;sub&gt;c &lt;/sub&gt;= ±50 GHz is applied using sinc pulses in space and time. This yields sinc pulses with a peak centered at 100 ps and spread over 108 nm. In the probe region, the magnetization component &lt;i&gt;m&lt;/i&gt;&lt;sub&gt;y&lt;/sub&gt; is collected for post processing. We chose a probe region 6×λ&lt;sub&gt;SW&lt;/sub&gt; long, and locate it sufficiently far away from gratings to minimize transient interferences. Absorbing boundary regions are defined at either boundaries with a parabolic variation of &lt;i&gt;α&lt;/i&gt; from 1 to 0.006 to absorb the reflections from edges[8]. With all these estimated parameters, the dimensions of the MC with 10 grooves on an 8 nm thick permalloy film is 1843.2×8×100 nm&lt;sup&gt;3&lt;/sup&gt;.&lt;br/&gt;DUTY CYCLE &amp; DEPTH MODULATIONS&lt;br/&gt;While the grating period decides the reflected &lt;i&gt;k&lt;/i&gt;&lt;sub&gt;SW&lt;/sub&gt;, the duty cycle (DC) of the grating affects the bandgap. We simulated gratings with depths of 2 nm and DCs of 50%, 33.3% and 16.7%. 1D spectral plots in Fig.1(b) show sharp dips of the order of 20 dB consistently, at &lt;i&gt;k&lt;/i&gt;&lt;sub&gt;SW&lt;/sub&gt;= 0.145 rad/nm for all MCs except the plain film, indicating that this wavevector is rejected irrespective of the DC variation. We also study the effect of depth modulation for gratings of depths 1 nm, 2 nm and 4 nm, all with a DC of 50%. The 1D-FFT plot in Fig.1(c), shows the occurrence of bandgaps in the designed frequency range. The effective thickness of the film allows propagation of both exchange and dipolar coupled SWs. From Fig.2(a), we observe a narrower bandgap, a reduced group velocity of the SWs, and an increase in frequency rejection ratio with increasing groove depth thickness. Based on these studies, the MBF is optimized to have 2 nm depth and a DC of 50%. Finally, to confirm the performance, a single frequency sinusoidal excitation at 28 GHz (in the bandgap), is compared with that of 40 GHz (not in bandgap) and observed that the rejection efficiency is about 90% higher at 28 GHz, as in Fig.2(b).&lt;br/&gt;CONCLUSION&lt;br/&gt;For a given frequency response of a magnonic device, we developed a systematic set of procedures to plan out various simulation parameters. The magnonic Bragg filter is designed and realized to reject frequency of 28 GHz efficiently. This study highlights the effect of variations, in duty cycle and depth, of MCs with sub-micron features, and assists in the fabrication process. We also expect that the outlined design procedure, and the computational routines, will be helpful to the magnonic community.

**References:**

&lt;br/&gt;[1] Jack Browne, https://www.mwrf.com/technologies/systems/article/21120263/surveying-the-status-of-5g-technology, (2020)&lt;br/&gt;[2] A. Mahmoud, F. Ciubotaru and F. Vanderveken, J. Appl. Phys., Vol. 128,p. 161101 (2020)&lt;br/&gt;[3] P. Frey, A. A. Nikitin and D. A. Bozhko, Commn. Phys., Vol. 3, p.17(2020)&lt;br/&gt;[4] A. V. Chumak A. A. Serga and S. Wolff, Appl. Phys. Lett, Vol. 94,p.172511 (2009)&lt;br/&gt;[5] https://github.com/LekhaRam/Mumax310AveragedSampling (2020)&lt;br/&gt;[6] Y. Zhao, Q. Song and S. H. Yang, Sci. Rep., Vol. 6, p.22890 (2016)&lt;br/&gt;[7] B. A. Kalinikos, IEE Proc.H.,Vol. 127, p.4 (1980)&lt;br/&gt;[8] G. Venkat and A. Prabhakar, J. Magn. Magn. Mater., Vol. 450, p.34 (2018)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/5fbbbf88907c50bb875d36f1018d0bb3.jpg)
(a) Structure of MBF with dimensions in nm (b) Variation of &lt;i&gt;m&lt;/i&gt;&lt;sub&gt;&lt;i&gt;y&lt;/i&gt;&lt;/sub&gt; in &lt;i&gt;k&lt;/i&gt; space with DC (c) Spectrum of depth modulated SW

![](https://assets.underline.io/uploads/markdown_image/1/image/67db7f859951c9d5171facd2890a6a12.jpg)
(a) Results of depth modulated MC (b) Sinusoidal excitation at 28 GHz &amp; 40 GHz for the optimized 1D MBF

INTERMAG 2021

 Magnonic Bragg Filter Design for India&#39;s 5G Spectrum
